HP Adaptive Rack Cooling System System Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HPE Adaptive Rack Cooling System
Installation Guide
Abstract
This document is for the person who installs racks and rack products. This procedure should
only be performed by trained personnel. Hewlett Packard Enterprise assumes you are
qualified in performing installations and trained in recognizing hazards in rack products.
Part Number: P07978-001
Published: December 2018
Edition: 1

Advertisement

Table of Contents
loading

Related Manuals for HP Adaptive Rack Cooling System

Summary of Contents for HP Adaptive Rack Cooling System

  • Page 1 HPE Adaptive Rack Cooling System Installation Guide Abstract This document is for the person who installs racks and rack products. This procedure should only be performed by trained personnel. Hewlett Packard Enterprise assumes you are qualified in performing installations and trained in recognizing hazards in rack products.
  • Page 2 © Copyright 2018 Hewlett Packard Enterprise Development LP Notices The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Configuration..................16 Configuring the unit ........................16 Baying the racks together......................18 Integrating the HPE Adaptive Rack Cooling System and IT Rack ..........20 HPE Adaptive Rack Cooling System pressure tube connections ........20 Installing the pressure sampling tubes................21 Installing the side panel blanks on the IT racks................25 Installing side panel blanks on a 42U IT rack..............26...

  • Page 4: About This Guide

    Through the top of the HPE Adaptive Rack Cooling System Safety information The HPE Adaptive Rack Cooling System is rated at a maximum facility pressure of 8 bar (116 PSI). If valves are installed on the external pipe work that could potentially trap fluid inside the HPE Adaptive Rack Cooling System, special precautions must be taken.

  • Page 5: Installation

    Listed materials are subject to change. Accessory Kits HPE ARCS Accessory Kit The HPE ARCS Accessory Kit comes with the HPE Adaptive Rack Cooling System. Use the parts included in this kit to properly install the HPE Adaptive Rack Cooling System. Item...
  • Page 6 Aluminum end cap, 1/8" diameter • Barbed, threaded NPTF hose end, 1/8" diameter • Pipe clamp, galvanized, 3/8"ID X 9/16" long (for HPE Adaptive Rack Cooling System) • Pipe clamp, galvanized, 3/8"ID X 11/16" long (for HPE ARCS 42U/48U 600x1600mm Racks) •...
  • Page 7 Hewlett Packard Enterprise recommends using the HPE Adaptive Rack Cooling SystemWater Hook-Up Kit to connect the HPE Adaptive Rack Cooling System to a facility water supply. Each kit includes two hose assemblies with 2-inch sanitary flange connections that are required for connecting the facility supply and return lines to the main inlet and outlet connections of an HPE Adaptive Rack Cooling System.
  • Page 8 Item Description Large side panel blank for the rear extension (4) Small side panel blank for the rear extension (4) Rack side panel blank (24) Side panel blank for the front extension, Panel B (10) Side panel blank for the front extension, Panel D (2) Side panel sealing tape Screws, 6-32, 3/8"...
  • Page 9 Item Description Rack side panel blank, 48U (8) Rack side panel blank (8) Side panel blank for the front extension, Panel C (4) Side panel blank for the front extension, Panel A (4) Screw, 6-32, 3/8" long (80) Grounding screw (1) Screw, 5.5 X1.81X10 Pan Torx T25 (3) Facade, 6U (1) Left and right extension brackets...
  • Page 10 Item Description Striker assembly with Southco R4-90-121-10 (1) Front door latch assembly with bracket (1) Rear door latch assembly (2) Auto door cable harness assembly (1) Screws, rear lock mount (8) Screws, 1/4-20 button head (2) Screws, M5.5X10 Torx pan head tap (3) HPE ARCS Auto Controller Kit Installation...

  • Page 11: Required Tools

    Custom mounting bracket (1) Zip ties (50) C13/14 power cord, 12 ft (1) CanBus cable, 5 meters (1) HPE Adaptive Rack Cooling System IO Module cable (1) Required tools The following tools are required for installation: • Flat blade screwdriver •...

  • Page 12: Installing The Hpe Adaptive Rack Cooling System

    Read the unpacking instructions on the HPE Adaptive Rack Cooling System packaging material. WARNING: The HPE Adaptive Rack Cooling System is shipped on a pallet and weighs approximately 645 kg (1,423 lb) by itself or 732 kg (1,614lb) including packaging. Hewlett...
  • Page 13 WARNING: To avoid tipping the HPE Adaptive Rack Cooling System over, be sure that the leveling feet are lowered when the HPE Adaptive Rack Cooling System is equipped, serviced, and operated. Connect the network cable to the RJ-45 connector (labeled "ETH") on the transfer switch at the top right on the rear of the HPE Adaptive Rack Cooling System.
  • Page 14 If you are using a secondary power cord, plug it into the power connector on the right. CAUTION: Do not force installation of power cords. Power cords are keyed and can only be installed in one direction. Forcing cables into plugs can permanently damage the cable or the plug.
  • Page 15 NOTE: If no secondary power is connected, the transfer switch will indicate a fail status for the secondary power supply. Guide the other ends of the power cords through the HPE Adaptive Rack Cooling System, and then plug them into an appropriate power source.

  • Page 16: Configuration

    Serial console interface on the CMC unit on the front of the HPE Adaptive Rack Cooling System The network connection for the HPE Adaptive Rack Cooling System is located on the rear of the unit at the top of the unit next to the transfer switch.
  • Page 17 The Users menu under Security allows the admin to change user access levels and passwords. 2. If the HPE Adaptive Rack Cooling System Ethernet interface is not enabled or the network port cannot be accessed, access the HPE Adaptive Rack Cooling System serially through the mini-USB port on the front of the CMC to set up the Ethernet port for web access.

  • Page 18: Baying The Racks Together

    For more information on accessory and option kits, see Accessory and option kit contents. On the HPE Adaptive Rack Cooling Unit: 1. If the HPE Adaptive Rack Cooling System is on the end of a row, to seal around the panels, apply sealing tape as indicated.
  • Page 19 On HPE ARCS 42U 600x1600mm Racks: 1. If the HPE Adaptive Rack Cooling System is on the end of a row, to seal around the panels, apply sealing tape as indicated. 2. If the HPE Adaptive Rack Cooling System is bayed to an adjacent rack, apply the foam gasket in the corners of the frame.

  • Page 20: Integrating The Hpe Adaptive Rack Cooling System And It Rack

    On HPE ARCS 48U 600x1600mm Racks: 1. If the HPE Adaptive Rack Cooling System is on the end of a row, to seal around the panels, apply sealing tape as indicated. 2. If the HPE Adaptive Rack Cooling System is bayed to an adjacent rack, apply the foam gasket in the corners of the frame.

  • Page 21: Installing The Pressure Sampling Tubes

    IT rack from different HPE Adaptive Rack Cooling Systems. In the specific case of an HPE Adaptive Rack Cooling System mounted at the end of an aisle with no IT racks to one side, join the two pressure tubes for that HPE Adaptive Rack Cooling System with a tee and route it to the farthest IT rack on the side of the HPE Adaptive Rack Cooling System that is cooled by that HPE Adaptive Rack Cooling System, up to two racks away.
  • Page 22 HPE Adaptive Rack Cooling System configured at one end of two IT racks NOTE: For this special installation, join hose barbs together and install them only on the farthest rack from the HPE Adaptive Rack Cooling System (left rack in this illustration). Purchase an extra Y- connection for this installation.
  • Page 23 Use two hose clamps to install each tube. • Orient the hose barb toward the HPE Adaptive Rack Cooling System that is cooling that rack. NOTE: The barbs on the hose must face toward the HPE Adaptive Rack Cooling System.
  • Page 24 3. Connect the HPE Adaptive Rack Cooling System to the pickups in the IT racks with flexible tubing. When facing the HPE Adaptive Rack Cooling System from the front (fans showing), the pressure reference ports are located in the upper-left side of the control box at the top of the HPE Adaptive Rack Cooling System.

  • Page 25: Installing The Side Panel Blanks On The It Racks

    6. On the rear of the HPE Adaptive Rack Cooling System, join the two reference ports with a section of the tubing and a Y-connector. 7. Connect the HPE Adaptive Rack Cooling System reference ports to the pressure pickup tube.

  • Page 26: Installing Side Panel Blanks On A 42U It Rack

    Installing side panel blanks on a 42U IT rack The HPE ARCS 42U Air Rack Installation Kit is for 42U racks and includes the following side panel blanks. Item Description 4 small side panel blanks for the rear extension 4 large side panel blanks for the rear extension 24 rack side panel blanks 2 "Panel D"...
  • Page 27 3. Repeat steps 1 and 2 for each additional rear extension blank. To install the side panel blanks: NOTE: If the HPE Adaptive Rack Cooling System is at the end of the row, side panel blanks must be installed from the outside, as shown in the previous illustration.

  • Page 28: Installing Side Panel Blanks On A 48U It Rack

    3. Repeat steps 1 and 2 for each additional front extension blank. Installing side panel blanks on a 48U IT rack The HPE ARCS 48U Air Rack Installation Kit is for 48U racks and includes the following side panel blanks. Item Description 8 rack side panel blanks...
  • Page 29 3. Repeat steps 1 and 2 for each additional front extension side panel blank. To install the side panel blanks: NOTE: If the HPE Adaptive Rack Cooling System is at the end of the row, side panel blanks must be installed from the outside, as shown in the previous illustration.

  • Page 30: Installing The Hpe Arcs Auto Door Release Kit And Hpe Arcs Auto Door Controller Kit

    3. Repeat steps 1 and 2 for each additional side panel blank. To install the top 6U blanks: 1. From the inside of the HPE Adaptive Rack Cooling System, place the blank against the IT rack, and line up the screw holes.
  • Page 31 For more information on the HPE ARCS Auto Door Release Kit and HPE ARCS Auto Door Controller Kit contents, see Accessory and option kit contents. NOTE: To install these option kits, a rack PDU plug must be available for a C13/C14 power cable to be installed.
  • Page 32 Remove the existing striker plates from the top and bottom of the rear door. Install the lower rear door latch assembly: • Route the auto door harness cable through the hole and connect it to the rear door latch assembly. •...
  • Page 33 Install the upper rear door latch assembly: • Route the auto door harness cable through the hole and connect it to the rear door latch assembly. • Align the rear door latch assembly with the screw holes. • Use four rear lock mount screws to install the rear door latch assemblies. •...
  • Page 34 Align the power supply with the screw holes on the top of the mounting bracket. Then use four screws to install the power supply. Align the CMC III I/O ARCS Rack Module with the screw holes on the mounting bracket underneath the power supply.
  • Page 35 10. To connect the HPE Adaptive Rack Cooling System to the IT controller, connect the 5m CAN bus cable harness included in the HPE ARCS Auto Controller Kit to the CMC, and then route the cable as shown. Connect the other end to the I/O module.
  • Page 36 12. Connect the controller cable bundle to the I/O module as labeled on the harness. Item Description HPE Adaptive Rack Cooling System Harness coming from IT rack (part number P06225-001) Power supply I/O module Configuration...
  • Page 37 13. To connect the auto door opening kit cables: a. Plug the cable into the IT controller. b. Route the cable across the top of the IT rack door and down to the door latch assembly. c. Route the cable across the top of the IT rack and to the upper door latch assembly. d.

  • Page 38: Installing The 6U Facade

    HPE Apollo Air 48U Rack Installation Kit. For more information on the kit contents, see Accessory and option kit contents. To install the 6U Facade: 1. Unscrew and remove the two screws on the top front of the HPE Adaptive Rack Cooling System. Set the screws aside in a safe place. Configuration...
  • Page 39 2. To attach the left and right mounting brackets to the 6U facade, use the four screws included with the kit. 3. Place the 6U Facade on top of the HPE Adaptive Rack Cooling System, lining up the screw holes. Use the screws you set aside in step 1 to screw the 6U Facade into place.

  • Page 40: Connecting To The Facility Water

    HPE Adaptive Rack Cooling System warranty. Before attaching the hoses to the HPE Adaptive Rack Cooling System, verify that the water supply and return are closed. Water that leaks into the unit can cause significant damage.
  • Page 41 Attach the 2-inch female hose coupling to the 2-inch cam and groove male coupling on the HPE HPE Adaptive Rack Cooling System. Lock into place. Route the condensate pan gravity drain and condensate pump outlet hoses to an appropriate facility drainage system.
  • Page 42 3º (pitch of 0.6 inch per 12 inches), without loops, and away from the HPE Adaptive Rack Cooling System cabinet. All hoses must be routed to a floor drain or reclamation system. The two overflow hoses are located in the HPE ARCS Accessory Kit.
  • Page 43 Select the Device Settings button on the System Control group. Change System Control.Fans.Control Mode to Manual and System Control.Valves.Control Mode to Manual. Configuration...
  • Page 44 Change System Control.Valves.Manual.Facility [0..100 %] to 100 and click Write. Return to the Visualization screen on the System menu. Configuration...
  • Page 45 10. Verify that flow is shown in the Visualization screen. Be sure that flow rate is greater than 60 gpm. 11. Repeat steps 5-10, but return valves and fans to automatic operation instead of manual. 12. If there are any manual valves on the facility lines, be sure that they are open. 13.
  • Page 46 The installation is complete. Configuration...
