- Page 1 HP A5830AF-48G Fan Trays (JC692A & JC693A) User Guide 5998-2056 Part number: 5998-2056 Document version: 6PW102-20111103...
- Page 2 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
-
Page 3: Table Of Contents
Front-to-back airflow fan tray specifications·······························5 Installing and replacing a fan tray ·························································6 Installing a fan tray ············································································6 Replacing a fan tray ··········································································8 Support and other resources································································ 11 Contacting HP·················································································· 11 Subscription service··································································· 11 Related information ········································································· 12 Documents ·················································································· 12 Websites····················································································· 12... -
Page 4: Fan Tray Overview
Back-to-front airflow fan tray Introduction to back-to-front airflow fan tray The HP A5830AF-48G back (power side) to front (port side) airflow Fan Tray (JC692A), referred to as back-to-front airflow fan tray hereafter, is a fan tray with blowing fans that blow air to the inside of the device. It comprises four separate fans. - Page 5 Figure 1 Back-to-front airflow fan tray structure (1) Captive screw (2) Status LED (3) Handle (4) Airflow direction label (5) Airflow...
-
Page 6: Back-To-Front Airflow Fan Tray Specifications
Front-to-back airflow fan tray Introduction to front-to-back airflow fan tray The HP A5830AF-48G front (port side) to back (power side) airflow Fan Tray (JC693A), referred to as front-to-back airflow fan tray hereafter, is a fan tray with drawing fans that draw air from the inside of the device. - Page 7 The fan tray provides a status LED to indicate the operating status of the module. When the switch is running, the LED can have the following statuses: The LED displays green—The fan tray operates properly. • The LED displays red—The fan tray has a fault. •...
-
Page 8: Front-To-Back Airflow Fan Tray Specifications
Front-to-back airflow fan tray specifications Table 2 Front-to-back airflow fan tray specifications Model Item Specification Four 40 × 40 × 28 Fans mm (1.57 × 1.57 × 1.10 in) fans Max fan speed 9500 rpm Front-to-back airflow Max airflow 40 CFM fan tray Max power 8.42 W... -
Page 9: Installing And Replacing A Fan Tray
Installing and replacing a fan tray You can install and replace the back-to-front airflow fan tray and front-to-back airflow fan tray in the same way. For more information, see “Installing a fan tray“ and “Replacing a fan tray.” Installing a fan tray IMPORTANT: Before installing a fan tray, make sure that the airflow direction of the module meets the ventilation requirement at the installation site. - Page 10 Figure 3 Install a fan tray (1) Remove the blank filler panel (2) Install a fan tray...
-
Page 11: Replacing A Fan Tray
NOTE: If you insert the fan tray with the upside facing downward, you • cannot completely insert the module into the slot. If this happens, pull the fan tray out and then insert it again with the upside on top. If you cannot fix the captive screws, check whether the fan tray is •... - Page 12 Step4 As shown in callout 2 of Figure 4, holding the handle of the fan tray, pull the module out of the chassis. Step5 Put the removed fan tray into the antistatic bag. Step6 Install a new fan tray. For more information, see “Installing a tray.”...
- Page 13 NOTE: If you replace a fan tray from a running switch, and the airflow direction of the new fan tray is different from the former one, the alarm message System fan airflow direction is not preferred on slot X, please check it. appears. To eliminate the alarm, replace another fan tray with the same airflow direction, or use the fan slot-number prefer-direction slot...
-
Page 14: Support And Other Resources
Operating system type and revision level • Detailed questions • Subscription service HP recommends that you register your product at the Subscriber's Choice for Business website: http://www.hp.com/go/wwalerts After registering, you will receive email notification of product enhancements, new driver versions, firmware updates, and other... -
Page 15: Related Information
Related information Documents To find related documents, browse to the Manuals page of the HP Business Support Center website: http://www.hp.com/support/manuals For related documentation, navigate to the Networking section, • and select a networking category. For a complete list of acronyms and their definitions, see HP •... - Page 16 Convention Description Italic text represents arguments that you Italic replace with actual values. Square brackets enclose syntax choices (keywords or arguments) that are optional. Braces enclose a set of required syntax { x | y | ... } choices separated by vertical bars, from which you select one.
- Page 17 GUI conventions Convention Description Window names, button names, field names, Boldface and menu items are in bold text. For example, the New User window appears; click OK. Multi-level menus are separated by angle > brackets. For example, File > Create > Folder. Symbols Convention Description...
- Page 18 Network topology icons Represents a generic network device, such as a router, switch, or firewall. Represents a routing-capable device, such as a router or Layer 3 switch. Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports Layer 2 forwarding and other Layer 2 features.
