3. Printer registration
3-1. Press the MENU key on the logger to open the OTHER menu.
3-2. Under the printer registration, set the interface to use to wireless LAN.
The logger needs to be set to access point mode in advance in step 1-3.
3-3. The printer name will be displayed when you perform a printer search. Press ENTER to
select the printer and complete the registration.
※ Check
If the printer name does not appear, check the SSID, encryption method, encryption key, and so
on set in "2. Printer configuration." Moreover, check the IP address and network mask to verify
that the printer is in the same segment as the logger's wireless LAN.
4. Test print
4-1. Perform a test print, and check that it is printed properly.
※ Check
If the test print fails, check the following.
- Check that the wireless connection between the logger and printer is established. You can
check whether a wireless connection is established with the WIFI setting of the printer.
- Check the printer's IP address and network mask to verify that the printer is in the same
segment as the logger's wireless LAN.
- Turn the logger and printer off and then back on.
※ If the communication speed decreases due to the communication environment, print data
may be lost.
※ When the printer is connected with the logger's wireless LAN setting set to access point
mode, the WL sensor (GL100-WL) cannot be connected.
※ If you want to connect the logger as a client to an off-the-shelf wireless LAN router, set the
wireless LAN setting to station, and set the same SSID and key as the off-the-shelf wireless
LAN router. Then, refer to the procedure for the wired LAN connection.
※ Only a single logger can be connected to a printer.
10
