USER MANUAL — INFINEA TAB C
Overview
The Infinea Tab C (ITC) allows mobile employees to convert their iOS devices into powerful solutions for retail, warehousing, supply chain, ticketing,
and hospitality industries. Includes a 3-track magnetic stripe reader (encrypted or unencrypted), optional 2D barcode scanner, optional Bluetooth,
and/or optional contactless payments.
Features
1D/2D Barcode Scanner
Supports one-dimensional (1D) and two-dimensional (2D)
barcode symbols, which can be read in any direction (omni-
directional). The effective reading distance of the barcode reader
varies depending on the barcode size. The barcode scanner is also
capable of reading barcodes on a LCD screen.
Near-Field Communication (NFC)
Built-in NFC tag/card reader with read/write capability at
13.56 MHz. The NFC reader incorporates several NFC formats,
depending on the model of your Infinea Tab C.
Accessories
Visit our website at https://ipcmobile.com or contact your Infinite Peripherals account representative for additional information about our
current and future product accessories.
Technical Specifications
Processor
ARM Cortex® M3 Security
Micro-controller
Compatibility
iPhone
6s Plus/7 Plus/8 Plus
®
iPad
mini 4/Air 2/Pro 9.7/5th/6th Generation
®
Magnetic Stripe Reader (MSR)
Built-in magnetic card reader, which incorporates a 3-track, bi-
directional magnetic read head. With a single swipe all field data
is read from all three tracks.
Smartcard Reader
Smartcard reader supports smart cards with a chip as a standard
feature.
Bluetooth
Available Bluetooth 2.0 SPP compatibility, which allows
connection to a Bluetooth peripheral, such as a printer.
Dimensions (L x W x H)
112.4mm x 88mm x 27mm (4.4" x 3.5" x 1.1")
Weight
168g (5.9 oz.) without iOS device
