OVERVIEW
Linēa-pro 4 allows mobile workers to convert their iPod touch and iPhone
handset into a powerful point-of-sale solution. The Linēa-pro 4 includes
optional 1D or 2D barcode scanner, 3-tracks magnetic stripe reader, and a
rechargeable battery extender in a very compact and durable protective case.
FEATURES
Battery:
Rechargeable Li-ion Battery - 1300 mAh,
Charging via USB to computer or Charging Station to Linēa-pro
4, Provides auxiliary power to iPod touch and iPhone
Magnetic Card Reader – 3-Track Head
Swipe Speed: Minimum of 1.97 in/sec
MTBF: 1 million swipes
Bidirectional reading capabilities
Barcode Scanner - Class II - 1D Laser / 2D Imager:
Single / Multi-scan mode
1D - MTBF: 30K hours (Laser Diode & Mirror Unit 10K hours)
2D - MTBF: 50K hours (Imager & Laser Pointer & Focus LED)
Indicators:
Audible: Internal electro-magnetic buzzer
Visual: 3 green LEDs
I/O Connectors:
10-pin female Mini-B USB connector for charging
and synchronization
30-pin plug iPod dock connector
4
USER MANUAL
|
