PROFIBUS PA
Manual
ST100 Series
Thermal Mass Flow Meter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for FCI ST100 Series

Summary of Contents for FCI ST100 Series

  • Page 1 PROFIBUS PA Manual ST100 Series Thermal Mass Flow Meter Fluid Components International LLC (FCI). All rights reserved.
  • Page 2 Any other use is strictly prohibited without the prior written consent of FCI. © Copyright 2011 by Fluid Components International LLC. All rights reserved. FCI is a registered trademark of Fluid Components International LLC. Information subject to change without notice.

  • Page 3: Table Of Contents

    ST100 Series Profibus PA 06EN003407 Rev. - Table of Contents Introduction............................................1 Definition ............................................1 Installation............................................2 General ............................................2 Electrical Wiring..........................................2 Topology and Network Configuration....................................2 Operation ............................................3 Functional Description........................................3 Cyclic Operation Description......................................3 Cyclic Operation Setup........................................3 Acyclic Operation Description.......................................4 System Blocks Description......................................5 Physical Block Parameters ......................................5 Service Transducer Block Parameters...................................6...
  • Page 4 06EN003407 Rev. - ST100 Series Profius PA INTENTIONALLY LEFT BLANK Fluid Components International LLC...

  • Page 5: Introduction

    Totalizer Blocks: The TOTALIZER block integrates (accumulates) the rate (i.e. Flow rate) to the corresponding integral. For example the ST100 offers two ways of providing the Totalize output of the Flow Rate; the FCI internally calculated “TOATLIZER” , or the PA Totalizer Function Block. The user can choose one or the other.

  • Page 6: Installation

    Release the cover locking screw and remove the cover. Cable access to wiring connections is obtained thru one of the conduit ports. FCI recommends the use of PROFIBUS PA and FOUNDATION Fieldbus-H1 cable compliant with the “H1 Cable Test Specification FF-844” JUMPERS SET...

  • Page 7: Operation

    4 bytes (float) 4 bytes (float) Flow, or velocity). Temperature 4 bytes (float) 4 bytes (float) One type only. One of two (FCI internal, or Profile Total­ Totalizer 4 bytes (float) 4 bytes (float) izer) Pressure 4 bytes (float) 4 bytes (float) One type only.

  • Page 8: Acyclic Operation Description

    ST100 Series Profibus PA When configuring the ST100 it is very important to follow the Slot sequence described below. If a module is not needed make sure to load an “EMPTY MODULE” in its place. In the example above the two “EMPTY_MODULE” modules are taking the place of the PRESSURE AI that is not offer in this model, and the profile TOTALIZER.

  • Page 9: System Blocks Description

    ST100 Series Profibus PA System Blocks Description Physical Block Parameters This block contains general PROFIBUS PA instrument information. This information helps to identify the device in the network, it’s software version, hardware version as well as control some of it instrument level functions.

  • Page 10: Service Transducer Block Parameters

    It also allows the user to change flow type from Volumetric, Mass Flow, and Velocity. This block also allows activation and deactiva­ tion of the ST100 FCI TOTALIZER. And finally for the multi-point models of the ST100, this block allows viewing of each individual sensor variables for the purpose of troubleshooting.

  • Page 11: Transducer Blocks Description

    ST100 Series Profibus PA Transducer Blocks Description There are 3 Process Data Transducer blocks in the ST100, one for each of the process variables that the ST100 can measure, flow, temperature, and pressure. Note: Not every process variable is available in every ST100 model.
  • Page 12 ST100 Series Profibus PA Temperature Transducer Block Parameters The ST100 uses RTDs to measure flow, one of the RTDs measure process temperature. This block provides the measured temperature. REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE PRIMARY_VALUE...
  • Page 13 The ST100 has the totalizer function built in. This function is made available through the PROFIBUS PA protocol in addition to providing the PROFIBUS PA profile TOTALIZER. When needing a TOTALIZER function, FCI recommends the use of this TOTALIZER function.

  • Page 14: Analog Input Blocks Description

    ST100 Series Profibus PA Analog Input Blocks Description There are 4 AI blocks; three of those blocks will be described in this section the fourth one will be described in the Totalizer Blocks Description section. The three blocks described in this section are Flow, Temperature and Pressure.
  • Page 15 ST100 Series Profibus PA Temperature Analog Input (AI) Block The Temperature AI block is the secondary parameter of the ST100 instrument. This block gets its input from the Temperature Transducer Block. REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE...
  • Page 16 ST100 Series Profibus PA Pressure Analog Input (AI) Block The instruments equipped with a pressure sensor will make use of the Pressure AI block. This block gets its input from the Pressure transducer Block. REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH)

  • Page 17: Totalizer Blocks Description

    Totalizer Blocks Description The ST100 PROFIBUS PA offers two ways of getting the totalized value of the flow for Volumetric and Mass flow. The FCI Internal TOTALIZER is computed internally by the ST100 system. The other TOTALIZER is computed by the PROFIBUS PA profile TOTALIZER module. The recommended TOTALIZER module to use is the FCI internal TOTALIZER.

  • Page 18: Profibus Pa Profile Totalizer Block

    ST100 Series Profibus PA PROFIBUS PA Profile Totalizer Block This function implements the PROFIBUS PA Profile specified TOTALIZER function. For additional information see the PROFIBUS PA standard. Totalizer Analog Input Block This block takes the input data from the Process Data Transducer Block, selected by the “Totalizer Average Channel” and makes it available to other function blocks at its output.

  • Page 19: Configuration

    Configuring Process Parameters in the TB modules The “Flow Transducer TB “ and the “Totalizer (FCI) TB” have a number of process related parameters that can be set within them. Theses parameters include “Pipe” size under the NOMINAL_SIZE parameter; three flow engineering unit types and the ability start and stop the ST100 internal FCI TOTALIZER.

  • Page 20: Configuring The Ai Blocks Of The St100 Instrument

    ST100 Series Profibus PA Configuring the AI blocks of the ST100 Instrument The AI blocks are the ones that make the process variables available to the cyclic DPV0 layer of the PROFIBUS protocol. They are use to configure and set the way that the process data is presented. Each one of the AI blocks has been preset to the designated Transducer Block channel, and the default prescribed by the profile.

  • Page 21: Using The St100 Profibus Pa Service Transducer Block

    TOTALIZER_STATE: This parameter is used to turn the FCI internal TOTALIZER on or off. To turn the TOTALIZER on a value of 1 needs to be entered. To turn the TOTALIZER off a value of 0 needs to be entered.

  • Page 22: General Station Description Files

    There are two GSD files provided in the accompanying CDROM. The first is the Profile 3 specific file created by the PNO; which is the International PROFIBUS Organization, and all profile compliant instrument must meet. The second file is a FCI specific GSD file. This file supports features that are unique to the ST100 Flowmeter.

  • Page 23: Technical Characteristics

    ST100 Series Profibus PA Technical Characteristics Physical Characteristics (PROFIBUS PA Channel) Permitted supply voltage: 9 to 32 V Current Consumption: 10mA Data transmission rate: 31.25 kBaud Bus connection: Non-polarized Signal coding: MBP (Manchester coded Bus Powered) PROFIBUS PA in accordance with IEC 61158 (MBP), galvanically isolated Profile 3 Characteristics PROFIBUS PA Version 3.02...
  • Page 24 ST100 Series Profibus PA INTENTIONALLY LEFT BLANK Fluid Components International LLC...

  • Page 25: Appendix A - Codes And Tables

    ST100 Series Profibus PA Appendix A - Codes and Tables ST100 ENGINEERING UNIT CODES TABLE Description PROFIBUS PA Codes TEMPERATURE UNIT CODES Degrees Celsius 1001 Degrees Fahrenheit 1002 PRESSURE UNIT CODES PSIA 1142 PSIG 1143 in H2O (at 60degrees F)
  • Page 26 (Millimeters) 1013 ST100 PROFIBUS PA (CLASSIC) DIAGNOSIS TABLE PROFIBUS PA PROFIBUS PA Classic ST100 FCI Error or Status Description FCI Fault Type DIAG_EXT DIAG (*2) CORE: If any of these errors occurs: I2C error, UART error, Mutex error, # 0-0...
  • Page 27 ST100 Series Profibus PA ST100 PROFIBUS PA (CLASSIC) DIAGNOSIS TABLE PROFIBUS PA PROFIBUS PA Classic ST100 FCI Error or Status Description FCI Fault Type DIAG_EXT DIAG (*2) CORE reports SD card error. Either initialization (corrupt card) error, or # 0-6...
  • Page 28 (Any) FE reports FE_ARM7_DATA_ABORT_FAULT # 5-1 DIA_HW_ELECTR (Any) FE reports FE_ARM7_FIQ_FAULT # 5-2 DIA_HW_ELECTR (Any) FE reports FE_ARM7_SPURIOUS_INT_FAULT FCI RESERVED (Not used) *** Currently not implemented. CORE: pro­ # 5-3 cess data not updated because (all) FE's in self-test Fluid Components International LLC...
  • Page 29 ST100 Series Profibus PA CLASSIC DIAGNOSIS DEFINITIONS Classic DIAGNOSIS Mnemonic Description DIA_HW_ELECTR Hardware failure of the electronic DIA_HW_MECH Hardware failure mechanics DIA_TEMP_MOTOR Motor- temperature too high DIA_TEMP_ELECTR Electronic temperature too high DIA_MEM_CHKSUM Memory error DIA_MEASUREMENT Failure in measurement DIA_NOT_INIT Device not initialized (No self calibration)
  • Page 30 ST100 Series Profibus PA ST100 PROFIBUS PA (CONDENSED) DIAGNOSIS TABLE PROFIBUS PA PROFIBUS PA Condensed DIAG FCI Fault Type PROFIBUS PA Status DIAG_ EXT # 2-0 # 2-1 # 2-2 # 2-3 DIA_INV_PRO_COND BAD (6) 0,1,2,3,4,5 # 2-4 DIA_INV_PRO_COND BAD (6) 0,1,2,3,4,5...
  • Page 31 ST100 Series Profibus PA CONDENSED DIAGNOSIS TABLE Condensed DIAGNOSIS Mnemonic Description DIA_MAINTENANCE Maintenance required DIA_MAINTENANCE_ALARM Failure of the device or armature DIA_MAINTENANCE_DEMANDED Maintenance demanded DIA_FUNCTION_CHECK Device is in function check mode or in simulation or under ocal control e.g. maintenance DIA_INV_PRO_COND The process conditions do not allow to return valid values.
  • Page 32 ST100 Series Profibus PA INTENTIONALLY LEFT BLANK Fluid Components International LLC...

  • Page 33: Appendix B - Customer Service/Technical Support

    Attn: Customer Service Department By Phone Contact the area FCI regional representative. If a field representative is unable to be contacted or if a situation is unable to be resolved, contact the FCI Customer Service Department toll free at 1 (800) 854-1993.
  • Page 34 ST100 Series Profibus PA NOTES Fluid Components International LLC...
  • Page 35 ST100 Series Profibus PA INTENTIONALLY LEFT BLANK Fluid Components International LLC...
  • Page 36 (and does not include manufacture or processing uses). Any other use is strictly prohibited without the prior written consent of FCI. © Copyright 2011 by Fluid Components International LLC. All rights reserved. FCI is a registered trademark of Fluid Components International LLC. Information subject to change without notice.
