  • Page 1 Configuration Software Manual ST100 Series Thermal Mass Flow Meter Fluid Components International LLC (FCI). All rights reserved.
  • Page 2 Any other use is strictly prohibited without the prior written consent of FCI. © Copyright 2015 by Fluid Components International LLC. All rights reserved. FCI is a registered trademark of Fluid Components International LLC. Information subject to change without notice.
  • Page 3: Table Of Contents

    ST100 Series Configuration Software 06EN003403 Rev. B Table of Contents Introduction ............................................1 Installation ............................................1 Running the PC Configuration Application via USB ................................1 Basic Setup Tab Screens ........................................3 Advanced Setup Tab Screens ......................................6 Configuration Tab Screens ........................................8 Diagnostics Tab Screens ........................................10 Factory ............................................12...
  • Page 4 06EN003403 Rev. B ST100 Series Configuration Software INTENTIONALLY LEFT BLANK Fluid Components International LLC...
  • Page 5: Introduction

    Introduction The ST100 Configuration software is a PC application that lets the user easily set up and configure the ST100 Series Thermal Mass Flow Meter products. Use this tool for all instrument commissioning activity. This manual covers ST100 Configuration software v2.2.0.0.
  • Page 6: Figure 3 - Usb Connect Button, Welcome Screen

    Calibration Group number and Group name • Alarm and Fault indicators The ST100 Series is set up using the configuration menu on the left side of the screen. The menu is displayed in a hierarchical tree structure: Fluid Components International LLC...
  • Page 7: Basic Setup Tab Screens

    ST100 Series Configuration Software Basic Setup Tab Screens Select the Basic Setup branch on the menu tree. The Groups Tab is the first of several tabs across the top of the screen. Each tab provides a particular menu within the Basic Setup branch.
  • Page 8: Figure 6 - Example Units Screen

    ST100 Series Configuration Software Figure 6 – Example Units Screen Figure 7 – Example Pipe Size Screen Figure 8 – Example Alarms Screen Fluid Components International LLC...
  • Page 9: Figure 9 - Example Sd Card Logging Screen

    ST100 Series Configuration Software Figure 9 – Example SD Card Logging Screen Figure 10 – Example Totalizer Screen Figure 11 – Example Pressure Offset Screen Fluid Components International LLC...
  • Page 10: Advanced Setup Tab Screens

    Set Clock date and time. User Lets users download a full calibration to their ST100 via a text file. Download Calibration Contact FCI to obtain the .txt file that was generated by the factory User linearization software (Cal2). [User password 2772] To verify the current configuration of any setup parameter, click the Get from Device button on any of the Setup menus.
  • Page 11: Figure 13 - Example Ethernet Tab (Advanced Setup)

    ST100 Series Configuration Software Figure 13 – Example Ethernet Tab (Advanced Setup) Figure 14 – Example Data and Time Tab (Advanced Setup) Figure 15 – Example Download Calibration Tab (Advanced Setup) Fluid Components International LLC...
  • Page 12: Configuration Tab Screens

    ST100 Series Configuration Software Configuration Tab Screens Select the Configuration branch on the menu tree. The Output Tab is the first of several tabs across the top of the screen. Each tab provides a particular menu within the Configuration branch.
  • Page 13: Figure 17 - Example 4-20Ma User Tab (Configuration)

    ST100 Series Configuration Software Figure 17 – Example 4-20mA User Tab (Configuration) Figure 18 – Example Modbus Tab (Configuration) Figure 19 – Example Extended Op. Mode Tab (Configuration) Fluid Components International LLC...
  • Page 14: Diagnostics Tab Screens

    ST100 Series Configuration Software Figure 20 – Example Group Switch Tab (Configuration) Diagnostics Tab Screens Select the Diagnostics branch on the menu tree. The Status Tab is the first of several tabs across the top of the screen. Each tab provides a par- ticular menu within the Diagnostics branch.
  • Page 15: Figure 22 - Example Fault Log Tab (Diagnostics)

    ST100 Series Configuration Software Figure 22 – Example Fault Log Tab (Diagnostics) Figure 23 – Example Scheduled Tests Tab (Diagnostics) Figure 24 – Example Test Logs Tab (Diagnostics) Fluid Components International LLC...
  • Page 16: Factory

    ST100 Series Configuration Software Factory Table 5 – Factory Tabs Tab Name Tab Description Password Level Factory Parameters For Factory use only. Factory Identification For Factory use only. Factory 4-20mA Factory For Factory use only. Factory Options For Factory use only.
  • Page 17: Figure 27 - Example 4-20Ma Factory Tab (Factory)

    ST100 Series Configuration Software Figure 27 – Example 4-20mA Factory Tab (Factory) Figure 28 – Example Options Tab (Factory) Figure 29 – Example HART Tab (Factory) Fluid Components International LLC...
  • Page 18: Fe1 Process Data

    ST100 Series Configuration Software Figure 30 – Example Memory Tab (Factory) FE1 Process Data The FE1 description refers to Flow Element 1 of the system. The system is capable of supporting multiple flow elements but for the purpose of this manual we will discuss a single point system with one flow element.
  • Page 19: Parameter Reports

    Parameter Reports A Parameter Reports screen displays the calibration information saved in the ST100 Series unit for a particular calibration group numbered 1-5. Selecting a parameter report for a particular calibration group displays that group’s info/data. Similar to other setup menus there are Get and Send buttons to receive (from ST100) and transmit (to ST100) a calibration parameter.
  • Page 20: Customer Service/Technical Support

    Attn: Customer Service Department By Phone Contact the area FCI regional representative. If a field representative is unable to be contacted or if a situation is unable to be resolved, contact the FCI Customer Service Department toll free at 1 (800) 854-1993.
  • Page 21 ST100 Series Configuration Software NOTES Fluid Components International LLC...
  • Page 22 (and does not include manufacture or processing uses). Any other use is strictly prohibited without the prior written consent of FCI. © Copyright 2015 by Fluid Components International LLC. All rights reserved. FCI is a registered trademark of Fluid Components International LLC. Information subject to change without notice.
