Keysight P Series Installation Manual
Modular power meter
Hide thumbs
Also See for P Series:
- Technical overview and self-manuald demonstration (12 pages) ,
- User manual (287 pages) ,
- Operating and service manual (49 pages)
Related Manuals for Keysight P Series
Summary of Contents for Keysight P Series
- Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com Keysight N8262A P-Series Modular Power Meter Installation Guide...
- Page 2 DFARS and are set forth specifically in the indicated conditions are fully writing else-where in the EULA. understood and met. Keysight shall be under no obligation to update, revise or otherwise modify the Software. With respect to any WARNING technical data as defined by FAR 2.101, pursuant to FAR 12.211 and...
-
Page 3: Certification
Keysight shall not be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or performance of this document or any information contained herein. -
Page 4: Limitation Of Warranty
Buyer. Keysight does not warrant the Buyer’s circuitry or malfunctions of Keysight products that result from the Buyer’s circuitry. In addition, Keysight does not warrant any damage that occurs as a result of the Buyer’s circuit or any defects that result from Buyer-supplied products. -
Page 5: Restricted Rights Legend
(Jun 1987) (or any equivalent agency regulation or contract clause), whichever is applicable. You have only those rights provided for such Software and Documentation by the applicable FAR or DFARS clause or the Keysight standard software agreement for the product involved. -
Page 6: Safety Symbols
‘Stand-by’ mode. Note, the instrument is NOT isolated from the mains when the switch is pressed. Three-phase alternating current. To isolate the instrument, the mains coupler (mains input cord) should be removed from the power supply. Equipotentiality. Keysight N8262A Installation Guide... -
Page 7: Safety Considerations
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards for design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability for the customer’s failure to comply with these requirements. - Page 8 REMOVE POWER and do not use the product until safe operation can be verified by service-trained personnel. If necessary, return the product to a Keysight Technologies Sales and Service Office for service and repair to ensure the safety features are maintained.
-
Page 9: General Specifications
Net weight ≤ 3.5 kg (7.7 lb) approximately Shipping weight ≤ 7.7 kg (17.0 lb) approximately 44.2 mm H x 212.6 mm W x 420.3 mm D Dimensions (1.75 in x 8.5 in x 19.63 in) Keysight N8262A Installation Guide... -
Page 10: Power Requirements
– For continue protection against fire hazard, replace the line fuse only with the same type and line rating (250V, F3.15A, 20mm fast blow fuse with high breaking capacity, Keysight Part Number 2110-0957). The use of other fuses or materials is prohibited. -
Page 11: Compliance And Markings
– Australia/New Zealand: AS/NZS 2064.1 – Canada: ICES-001:1998 Safety This product conforms to the requirements of the following safety standards: – EN61010-1: 2001 / IEC 61010-1:2001 – Canada: CSA C22.2 No. 61010-1:2004 – USA: UL: 61010-1:2004 Keysight N8262A Installation Guide... -
Page 12: Regulatory Markings
WEEE Directive (2002/96/EC) marking The RCM mark is a registered requirement. This affixed product label trademark of the Australian indicates that you must not discard Communications and Media Authority. this electrical or electronic product in domestic household waste. Keysight N8262A Installation Guide... -
Page 13: Regulatory Information
Manufacturers Declaration This statement is provided to comply with the requirements of the German Sound DIN 45635 T. 19 (Typprufung). Sound Pressure LpA < 70 dB. At operator position. Normal operation. According to ISO 7779 (Type Test). Keysight N8262A Installation Guide... -
Page 14: Waste Electrical And Electronic Equipment (Weee) Directive 2002/96/ Ec
With reference to the equipment types in the WEEE directive Annex 1, this instrument is classified as a “Monitoring and Control Instrument” product. The affixed product label is as shown below. Do not dispose in domestic household waste. Keysight N8262A Installation Guide... -
Page 15: Responsibilities Of The Customer
– Access to and use of all information and facilities determined necessary by Keysight to service and/or maintain the products. (Insofar as these items may contain proprietary or classified information, the customer shall assume full responsibility for safeguarding and protection from wrongful use.) –... - Page 16 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight N8262A Installation Guide...
-
Page 17: Table Of Contents
..........24 Keysight N8262A Installation Guide... - Page 18 ... . 37 1. Installing the Keysight IO Libraries ......37 2.
- Page 19 .......51 Opening Keysight Connection Expert ......53 Selecting the LAN network type .
- Page 20 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight N8262A Installation Guide...
- Page 21 ......48 Figure 1-13 Connecting E-Series power sensor to a Keysight N1917A cable ........48...
- Page 22 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight N8262A Installation Guide...
-
Page 23: Getting Started
Keysight N8262A P-Series Modular Power Meter Installation Guide Getting Started Welcome Documentation Information What You will Find in this Guide Networking Terms Determining your PCs Configuration Settings Resetting the LAN Configuration Power Meter and Sensor Capability Step 1. Unpacking the P-Series Modular Power Meter Step 2. -
Page 24: Welcome
– make connection to the rear panel – make connection to the front panel – configuring the modular power meter – use the Keysight IO Libraries Suite to configure the remote programming interface – use Web browser to configure the remote programming interface –... -
Page 25: Documentation Information
– The Installation Guide (this book) - Shows you how to check your modular power meter, install software and instrument drivers, configure it, switch it on, connect it to a Keysight power sensor and connect it using Power Meter GUI application. This information is presented in English and Japanese. -
Page 26: What You Will Find In This Guide
Troubleshooting Connectivity Problems – Rack Mounting the P-Series Modular Power Meter For more detailed operating information, refer to the Keysight N8262A P-Series Modular Power Meter User’s Guide and Keysight N8262A P-Series Modular Power Meter Programming Guide. Keysight N8262A Installation Guide... -
Page 27: Networking Terms
141.121 .84.241 are all IP addresses. A device’s IP address can be assigned to it manually (See Static IP address), assigned to it by another computer (See Dynamic Host Configuration Protocol (DHCP)) or can be self-determined (SeeAuto-IP Keysight N8262A Installation Guide... -
Page 28: Ip Address Conflict
However, network using DHCP will often also use DNS, which can allow you to communicate with a device using a hostname that will stay the same, even if the device’s IP address has changed. Keysight N8262A Installation Guide... -
Page 29: Dhcp Server
Auto-IP, it randomly selects an address of the form 169.254.X.X. If another device is already using that address, it selects another random address, and continues to select new addresses until it finds one that is not being used by any other instrument. Keysight N8262A Installation Guide... -
Page 30: Cross-Over Cable
A subnet mask is used to specify how a network is broken down into subnets. Subnet mask look like IP addresses; they are of the form x.x.x.x. Common subnet masks include 255.0.0.0, 255.255.0.0 (use this for private networks), and 255.255.255.0. Keysight N8262A Installation Guide... -
Page 31: Default Gateway
The default gateway is used by a device to communicate with devices that have IP addresses that are on different subnets. This would usually be the IP address of the router that connects the device’s subnet to the rest of the network. Keysight N8262A Installation Guide... -
Page 32: Determining Your Pcs Configuration Settings
– Auto configuration enabled or disabled (displayed when using DOS window, ipconfig command only) – IP address – Subnet Mask – Default Gateway – DHCP server address – Primary Win server – Secondary Win server Keysight N8262A Installation Guide... -
Page 33: Resetting The Lan Configuration
Resetting the LAN configuration will reset the password for accessing the NOTE instrument’s webpage browser as well. The default password is “keysight”. Keysight N8262A Installation Guide... -
Page 34: Power Meter And Sensor Capability
Getting Started Power Meter and Sensor Capability Your P-Series modular power meter is compatible with Keysight P-Series, E-Series E9300, E-Series E4410 and the 8480 Series power sensors. However, not all sensor and meter combinations have the same features or capabilities. The... -
Page 35: Step 1. Unpacking The P-Series Modular Power Meter
Keysight Technologies office. Keep the damaged shipping materials (if any) for inspection by the carrier and Keysight representative. If required, you can find a list of Keysight Sales and Service Offices on the last page of this guide. -
Page 36: Minimum Pc Requirements
– Microsoft Windows XP Professional or Home Edition (Service Pack 1 or 2), Windows 2000 (Service Pack 2) – 512 MB of RAM – Up to 40 MB of available hard-disk space – Microsoft Internet Explorer 6.0 (or higher) Keysight N8262A Installation Guide... -
Page 37: Step 2. Installing The Software And Instrument Drivers
– Keysight N8262A product reference CD Installing the Keysight IO Libraries The Keysight IO Libraries Suite must be installed first followed by the N8262A instrument drivers that are located on the product reference CD. 2. Installing the Power Meter GUI 1 Insert the Keysight N8262A P-Series modular power meter product reference CD in the CD-ROM drive. -
Page 38: Using Interactive Io
*TST?), or execute commands from the instrument’s command set Figure 1-1 shows how Interactive IO is started from Keysight Connection Expert. For more information on Interactive IO, refer to the Keysight IO Libraries Suite NOTE Getting Started Guide. The guide is available on-line by clicking on the Keysight IO Control icon and then selecting Documentation >... -
Page 39: Figure 1-1 Selecting An Instrument And Start Interactive Io
– *IDN? *(returns the carrier serial number and firmware revision) This command can be executed from the Interactive IO window. Example of the information returned by the command is as below: *IDN? Keysight Technologies, N8262A, MY46120006,X2.1.86 product carrier firmware carrier serial... -
Page 40: Using The Instrument Web Browser
– determining/changing instrument configuration – troubleshooting and debugging Comprehensive on-line help providing web browser usage information is available with each Web window. The instrument’s web browser can be opened from Keysight Connection Expert as shown in Figure 1-2. Alternatively, the instrument’s web-based interface can also be opened directly NOTE from a web browser by entering the instrument’s IP address or hostname in the... -
Page 41: Figure 1-3 N8262A P-Series Modular Power Meter Web Browser (Welcome Page)
Once communication path to the instrument has been opened, the instrument’s LAN configuration can be viewed and modified using the web browser. On the Welcome Page, click View and Mod ify Configuration. This opens the configuration window shown in Figure 1-4. Keysight N8262A Installation Guide... -
Page 42: Figure 1-4 Viewing Lan Configuration Settings From The Web
Getting Started Figure 1-4 Viewing LAN configuration settings from the web interface To edit parameters shown, click Mod ify Configuration. The window opens as shown in Figure 1-5. Keysight N8262A Installation Guide... -
Page 43: Figure 1-5 Changing The Instrument Lan Interface Configuration
Selecting Help with this Page on any web browser provides information on the NOTE use of the current web browser page. Selecting Help with this Page on the Browser Web Control page provides a listing of the help contents. Keysight N8262A Installation Guide... -
Page 44: Step 3. Turning The Power Meter On
90 VAC to 264 VAC and 47 Hz to 63 Hz and 440 Hz. 1 Connect the power cord. Figure 1-6 Connecting the power cord 2 Check that the PWR LED is solid orange. Figure 1-7 PWR LED before power on Keysight N8262A Installation Guide... -
Page 45: Rear Panel Connections
51. Rear panel connections The following connections are available on the rear panel. To setup the remote interfaces, refer to “Step 4. Remote Interface Configuration” on page 51. LAN connection Figure 1-9 Connecting the LAN cable Keysight N8262A Installation Guide... -
Page 46: Front Panel Connections
The sensor input connectors. Trigger input (TRIG IN) and output (TRIG OUT) connections are made via SMB connectors. Recorder outputs (RCDR 1 and RCDR 2) connections are made via SMB connectors. Keysight N8262A Installation Guide... -
Page 47: Connecting A Power Sensor
1 Connect the P-Series power sensor cable to the Channel A (CH A) or Channel B (CH B) input connector. Figure 1-10 Connecting the P-Series power sensor 2 Confirm a Read ing Sensor pop-up message appears briefly on the soft front panel. Figure 1-11 Read ing Sensor pop-up window Keysight N8262A Installation Guide... -
Page 48: Figure 1-12 Measurement Display
Measurement display E-Series and 8480 Sensor models Using the N1917A/B/C/D cable, any Keysight 8480 or E-Series power sensor can be connected to the N8262A P-Series modular power meters. The following shows the procedure for power meter configured with front panel mounted PWR REF and channel A (CH A) connectors. -
Page 49: Figure 1-15 Reading Sensor Pop-Up Window
8480 Series power sensor. Figure 1-15 Reading sensor pop-up window 4 Confirm the display has changed to a measurement reading. Figure 1-16 Measurement display 5 Connect the sensor to the PWR REF connector. Keysight N8262A Installation Guide... -
Page 50: Figure 1-17 Zeroing And Calibrating Pop-Up Window
Click as required. Figure 1-17 Zeroing and Calibrating pop-up window The Zeroing pop-up is displayed during the zeroing process, the Calibrating pop-up during calibration. The meter-sensor measurement path is calibrated when the Calibrating pop-up disappears. Keysight N8262A Installation Guide... -
Page 51: Step 4. Remote Interface Configuration
– For more information on configurating the remote interface connectivity, refer to the Keysight Technologies LAN Interfaces Connectivity Guide. From the IO Libraries Suite, you can access the Connectivity Guide via the Keysight IO Libraries Control icon. The power meter has three LAN operating modes which can be configured: –... - Page 52 A-N8262A-XXXXX where “XXXXX” are the last five digits of the instrument serial number. The instrument host name is reported by Keysight Connection Expert for network servers that support DNS. For network servers that support Dynamic DNS, only the IP address is reported.
-
Page 53: Opening Keysight Connection Expert
Opening Keysight Connection Expert With the P-Series modular power meter turned on and connected to a private or site LAN network, start Keysight Connection Expert utility by clicking on the Keysight IO Control icon and selecting Connection Expert from the pop-up menu. -
Page 54: Selecting The Lan Network Type
P-Series modular power meter is independent of the type of network you are using (private or site) and the network devices present (switches or routers). For more information on the Interactive IO, refer to the Keysight IO Libraries Suite Getting Started Guide. The guide is available on-line by clicking on the Keysight IO Control icon and then select Documentation >... -
Page 55: Figure 1-19 Typical Private Lan Network Connections
For private LAN networks that include a switch or router, use standard LAN cables for network connections. Do not use the cross-over cable. Once the LAN cable is connected, power on the P-Series modular power meter. Keysight N8262A Installation Guide... -
Page 56: Dynamic Mode
Refer to “Resetting the LAN Configuration” on page 33 and “Static mode (configuring the LAN manually)” on page 60 for more information. Using this Dynamic Mode does not require a detailed knowledge of your network configuration. Keysight N8262A Installation Guide... - Page 57 Remote Interfaces Ensure that DHCP to ON (ON is the factory default state). 5 To enable DHCP operation using the arrow and Select softkeys to highlight and check DHCP is checked. Keysight N8262A Installation Guide...
-
Page 58: Figure 1-21 Typical Lan Remote Interface
When identifying the instrument, it is easiest to use the IP address that you noted in step 5 above. Refer to Documentation that accompanies the IO Libraries software for more NOTE details. Keysight N8262A Installation Guide... -
Page 59: Auto Ip Mode
, to return to a measurement screen. 5 Use the Connection Expert utility of the IO Libraries Suite to add the power meter and verify a connection. Refer to Documentation that accompanies the IO Libraries software for more NOTE details. Keysight N8262A Installation Guide... -
Page 60: Static Mode (Configuring The Lan Manually)
For the new settings to become effective, you may first power cycle the NOTE instrument and then power cycle the PC. Configure modular power meter after connection Make sure you have connected to the P-Series soft front panel before you NOTE proceed. Keysight N8262A Installation Guide... -
Page 61: Figure 1-23 Typical Manual Entry For Lan Network Interface
Subnet Mask, and Default Gateway. The values can range between 0.0.0.0 and 255.255.255.255. Figure 1-23 Typical manual entry for LAN network interface 3 Click , to return to the remote interfaces settings. 4 Click Restart Network. Keysight N8262A Installation Guide... - Page 62 Configuring the LAN remotely using Skippy command To automatically configure the LAN settings enable DHCP operation using the SYSTem:COMMunicate:LAN:DHCP[:STATe] command. – To individually specify the settings use the following commands: SYSTem:COMMuniucate:LAN:ADDRess – SYSTem:COMMunicate:LAN:SMASk – SYSTem:COMMunicate:LAN:DGATeway – SYSTem:COMMunicate:LAN:AIP[:STATe] – SYSTem:COMMunicate:LAN:RESTart Keysight N8262A Installation Guide...
-
Page 63: Step 5. Connecting To The P-Series Modular Power Meter Using Power Meter Gui Application
“Private network connections” on page 55. – Your Keysight N8262A P-Series modular power meter has been shipped with NOTE a default IP address. You may reset the instrument which enable you to put the LAN configuration of the instrument into a known default state. See “Resetting the LAN Configuration”... -
Page 64: Connecting The Power Meter Using A Private Network
5 Select Copy VISA Address to clipboard (IP Address) or Copy VISA Address to Clipboard (Hostname). 6 From the Windows Desktop, select Start > All programs > Keysight SI Tools > Power Meter GUI. 7 The P-Series soft front panel appears. -
Page 65: Figure 1-25 Open Local Area Network To Change The Internet Protocol Settings
From the Windows Desktop, select Start > Control Panel > Network connections. b Double-click Local Area Connection to open the Local Area Network Properties window. From the General tab, select Internet Protocol (TCP/ IP). Figure 1-25 Open Local Area Network to change the internet protocol settings Keysight N8262A Installation Guide... -
Page 66: Figure 1-26 Enter Pc's Network Settings In Internet Protocol (Tcp/Ip) Properties Window
6 From the SI Finder window, right-click N8262A and select Copy VISA Address to Clipboard (IP Address) or Copy VISA Address to Clipboard (Hostname). 7 From the Windows Desktop, select Start > All programs > Keysight SI Tools > Power Meter GUI. -
Page 67: Troubleshooting Connectivity Problems
– Make sure that no other device is using the same IP address as The instrument is configured to your instrument. use a duplicate static IP address. – Configure your instrument to use a different IP address. Keysight N8262A Installation Guide... -
Page 68: I Cannot Ping The Instrument's Ip Address Or Host Name
No DNS server is available. address. The DNS server has not been Wait several minutes. updates. Your PC cannot communicate “I cannot ping the instrument’s IP address or host name” with the device over your LAN. page 68. Keysight N8262A Installation Guide... -
Page 69: I Cannot View The Instrument Webpage
“I cannot ping the instrument’s IP address or host name” with the device over your LAN. page 68. Someone else is currently Make sure that no one else is connected to the instrument. connected to the instrument. Keysight N8262A Installation Guide... -
Page 70: Rack Mounting The P-Series Modular Power Meter
N8262A-909), which will come seperately as an optional kit upon ordering. You may refer to Test System Development Guide (59889821 TSDG6 Racking, NOTE Application Note 1465-6 ) before rackmounting. This application notes will walk you through important considerations for arranging your test equipment in a rack. Keysight N8262A Installation Guide... - Page 71 Getting Started Keysight N8262A Installation Guide...
- Page 72 Getting Started THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight N8262A Installation Guide...
- Page 73 This information is subject to change without notice. Always refer to the English version at the Keysight website for the latest revision. © Keysight Technologies 2007 - 2017 Edition 5, August 4, 2017 Printed in Malaysia *N8262-90005*...
