Getting to Know Your ComPack

Controls & Indicators
Mic Input Level
1.
Adjusts the signal level that you are sending down the telephone line,
through the female XLR input. The <Clip> LED indicates clipping on the
input channel if the level is set too high. If you see this red LED flashing,
you should decrease the <Mic Input>.
Line Input Level
2.
Adjusts the signal level that you are sending down the telephone line,
through the 3.5mm mini jack input.
Headphone Level
3.
Adjusts the signal level coming from the ¼" headphone jack.
2 ComPack™ Universal Telephone Audio Interface
1 2 3
8 9
4
5
6
7
10
