Summary of Contents for JK Audio innkeeper 1x
- Page 1 1x innkeeper 1rx Digital Hybrid User Guide JK Audio...
- Page 2 Introduction Innkeeper 1x and innkeeper 1rx will allow you to send and receive audio over analog telephone lines. While this may seem like a simple task that any telephone can do, the challenge is getting the best quality audio from such a miserable audio path.
- Page 3 Receive LEDs represent the signal level coming from the phone line, after the DSP. 12 AGC - press this switch to allow the innkeeper 1x/1rx to automati- cally adjust the gain of caller audio. 13 Caller Ducking - press this switch to lower the caller’s audio level by 9 dB when local audio is present.
- Page 4 Mic or line level input. 20 Remote Control Jack - 10 pin RJ-50 modular jack for connection to the RS-232 cable, the optional JK Audio RIU-IP remote interface or the optional JK Audio Guest Module 1 Remote Keypad.
- Page 5 Connection—Mix-Minus Setup Auxiliary telephone optional. Used to dial out to set up calls. Caller to any Aux Send to Send 1, line level input Mic/Line button out (Line) Number of mics depends on mixer Use Main Outputs, USB or Firewire connectors to send audio to recording device,...
-
Page 6: Operation
Power - Connect the supplied AC power cord to the back of the innkeeper 1x/1rx and then to an AC power outlet. Your innkeeper 1x/1rx is now ready to take calls. You may want to connect an auxiliary phone to the innkeeper for call setup, or you can simply use Auto-Answer or the Call button to answer an incoming call. - Page 7 When the Drop button is pressed, the phones become active again. Warning! The AC cable must be unplugged from the back of the innkeeper 1x/1rx anytime the case is opened. Failure to follow these instructions could result in injury or death.
- Page 8 When Auto-Answer is enabled, you can still take calls manually using the Call button. When finished, you can either drop the call manually or allow the call to Auto-Disconnect. Innkeeper 1x/1rx will look for a CPC (calling-party-control) disconnect signal or ROH (receiver-off-hook) message from the phone company to determine when a call has disconnected.
- Page 9 Operation (continued) Operation (continued) Remote Jack The RJ-50 type 10-pin Remote jack on the back of innkeeper 1x/1rx is for connection to the RS-232 cable (included), the optional JK Audio Guest Module 1 Remote Keypad or the optional JK Audio RIU-IP interface (see Page 11).
-
Page 10: Serial Port Interface
1x/1rx includes an RS-232 interface for remote control applications. The enclosed CN081 serial port cable connects to the Remote jack on the back of the innkeeper 1x/1rx. The port is configured with baud rate=9600, data bits=8, stop bits=1, parity=none, flow control=none. All commands begin with the ‘/’... - Page 11 RIU-IP This remote control interface was designed for use with innkeeper 1x/1rx as well as JK Audio innkeeper 2 and innkeeper 4 digital hy- brids. This unit contains a web server which allows the user to send and receive control data through their web browser. RIU-IP can be...
- Page 12 FAQ’s Does the innkeeper 1x/1rx send a burst or beep down the phone line at the beginning of the call like our current hy- brid? No. Innkeeper 1x uses the actual transmit signal to evaluate the phone line and tune its algorithm. As you begin to speak, innkeeper 1x is hard at work canceling your voice from the Caller Output jack.
-
Page 13: Specifications
0.5B REN Frequency Response: Telephone side 200 Hz - 3600 Hz Power: Universal AC supply, 120-240 VAC, 50-60 Hz, 25 watts max. Innkeeper 1x Size: 1.75" x 7.3" x 10.5" (4.5 x 18.6 x 26.7 cm) Weight: 4.0 Pounds Innkeeper 1rx Size: 1.75"... -
Page 14: Fcc Part 15 Compliance
Changes or modifications not expressly approved by JK Audio can void the user's authority to operate the equipment. FCC Registration Your new JK Audio product has been registered with the Federal Communications Commission (FCC). This product complies with the standards in Part 68 of the FCC rules. - Page 15 FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your JK Audio product. If such changes are planned, you'll be notified by your telephone company.
-
Page 16: Warranty
Innkeeper 1x and innkeeper 1rx are covered by a 2-year warranty to be free from defective workmanship and materials. In the event that the innkeeper 1x or innkeeper 1rx needs repair, you must call us to get an authorization, and then carefully pack and ship it to us.
