- Page 1 Operating instructions Electronic pressure sensor PL205x...
-
Page 2: Table Of Contents
Contents 1 Preliminary note ....................2 1.1 Symbols used ....................2 2 Safety instructions ....................3 3 Functions and features ..................4 3.1 Applications ....................4 4 Function .......................5 4.1 Processing of the measured signals ..............5 5 Installation......................6 6 Electrical connection ....................8 7 Operation ......................8 7.1 Cleaning of the filter cover ................8 8 Parameter setting ....................9 8.1 Adjustable parameters ...................9... -
Page 3: Safety Instructions
2 Safety instructions • The device described is a subcomponent for integration into a system. - The manufacturer of the system is responsible for the safety of the system. - The system manufacturer undertakes to perform a risk assessment and to create a documentation in accordance with legal and normative requirements to be provided to the operator and user of the system. -
Page 4: Functions And Features
3 Functions and features The pressure sensor detects the system pressure of machines and installations. 3.1 Applications Type of pressure: relative pressure Permissible Order no. Measuring range Bursting pressure overload pressure PL2053 -1...25 -15...363 1 450 5 070 PL2054 -0,5...10 -7...145 2 175 PL2056... -
Page 5: Function
4 Function 4.1 Processing of the measured signals The unit converts the system pressure into an analogue output signal (4...20 mA). The measuring range can be scaled to up to 25% of the finalvalue of the measur- ing range. • By setting the parameter ASP you define the measured value at which the output signal is 4 mA. -
Page 6: Installation
5 Installation Ensure that no pressure is applied to the installation while mounting or removing the sensor. Aseptoflex adapters ensure that the sensor can be connected to different process connections. (The adapters have to be ordered separately as accessories.) Mounting operation: ►... - Page 7 ► Screw the sensor into the adapter until it is hand-tight. Do not damage the sealing chamfers. ► Clamp sensor and adapter into a clamping device (D). Tighten the clamping device only slightly so that the adapter does not warp. The sealing chamfers (E) must not be damaged.
-
Page 8: Electrical Connection
Core colours of ifm sockets: 1 = BN (brown), 2 = WH (white), 3 = BU (blue), 4 = BK (black) 7 Operation After power on of the supply voltage the unit is in the Run mode (= normal opera- tion). -
Page 9: Parameter Setting
► Screw the filter cover again tightly. The sensor is sufficiently protected against harsh ambient conditions (protection IP 67). The protection rating can be increased by a special accessory (order no. E30043). 8 Parameter setting Parameters can be set before installation and set-up of the unit or during opera- tion. -
Page 10: Setting Ranges
Setting of the display d1 / d2 / d3 = update of the measured value every 50ms / 200ms / 600ms. The update interval only refers to the display. ph = display of the measured peak value remains for a short time (peak hold). 8.2 Setting ranges ΔP -1,0... - Page 11 More information at www.ifm.com...
