All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our web site
(www.microchip.com) to obtain the latest documentation available.
Documents are identified with a "DS" number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
"DSXXXXXA", where "XXXXX" is the document number and "A" is the revision level of the
document.
For the most up-to-date information on development tools, see the MPLAB
Select the Help menu, and then Topics to open a list of available online help files.

INTRODUCTION

This chapter contains general information that will be useful to know before using the
USB4712/USB4912. Items discussed in this chapter include:
•

Document Layout

• Conventions Used in this Guide
• The Microchip Web SiteThe Microchip Web Site
• Development Systems Customer Change Notification Service
• Customer Support
• Document Revision History
DOCUMENT LAYOUT
This document describes how to use the EVB-USB4x12 Evaluation Board as a
development tool for the USB4712/USB4912 1-Port USB 2.0 automotive hubs. The
manual layout is as follows:
• Chapter 1. "Overview"
Evaluation Board.
• Chapter 2. "Getting Started"
with the EVB-USB4x12 Evaluation Board.
• Chapter 3. "Hardware Configuration Options"
about the EVB-USB4x12 Evaluation Board battery charging features.
Appendix A. "PCB Layers"
•
tion Board PCB layers.
Appendix B. "Schematics"
•
tion Board schematics.
• Appendix C. "Bill of Materials"
Evaluation Board Bill of Materials (BOM).
