Lighting

The camera head is equipped with 4 LEDs. This lighting can be switched on
with the camera head illumination button [5]. This button can also be used to
gradually increase the brightness of the LEDs by pressing it several times. 8
different levels can be set. When the highest level is reached and the camera
head illumination button [5] is pressed again, the lighting switches itself off. If
the lighting is reset, it reverts to the default setting after the camera has been
switched off and then switched on again.

Screen brightness

The brightness of the screen can be changed with the brightness adjustment
display / zoom function button [7]. The brightness of the screen is gradually
increased when this button is pressed several times. 8 different levels can be
set. When the highest level is reached and the brightness adjustment display /
zoom function button [7] is pressed again, the brightness adjustment is reset to
the default value. A reset to the default setting also occurs when the camera is
switched off and then switched on again.

Zoom function

The zoom function can be activated via the brightness adjustment display /
zoom function button [7]. Keep this switch pressed for approximately 3
seconds to gradually increase the zoom function. There are two zoom levels
available. When the highest zoom level is reached and the brightness
adjustment display / zoom function button [7] is pressed again for
approximately 3 seconds, the zoom function is deactivated again. A reset to
the default setting also occurs when the camera is switched off and then
switched on again.

Changing the display

The camera image can be rotated by 180° and mirrored vertically or
horizontally by pressing the view/rotate image button [4]. This setting enables
you to display four different views of your image. If the display is changed, the
default display is shown after the camera has been switched off and then
switched on again.
