Attaching/detaching the gooseneck

Use of the device

Switching the endoscope camera on and off

Press the on/off switch [3] for approximately 2 seconds to switch the
endoscope camera on or off. The power indicator [2] lights up green and, after
a short delay, the image is shown on the screen [1].
Proceed as follows:
To ensure the tightness of the screw connection,
remove any impurities on the rubber ring (a.)
and on the screw thread (b.) with a slightly
damp cloth. To maintain the flexibility of the
rubber ring,
occasionally, for example, with Vaseline. The
gooseneck can only be attached in one
direction due to the polarity protection feature.
Insert the polarity protection for this purpose
into the slot provided (c.).
The gooseneck can then be screwed on. Turn
the screw connection to the right until it is firmly
secured.
To detach the gooseneck, turn the screw
connection towards "Remove" until it is
released. The gooseneck can then be pulled off
by exerting a little force.
PowerFix PEK 2.3 A2
you should lubricate it
English - 31
