Table 2-12 JP6 LED Header Connections (XPW100100K-01 and XPCW1002100K)

Jumper Position
Pins 1 to 2
Pins 3 to 4
Pins 5 to 6
Pins 7 to 8
Jumper Position
Pins 1 to 2

Additional Headers

The table below lists the pin functionality of the additional evaluation board headers.
J1 Pin Header Pin
36 JP3 pin 1
38 JP4 pin 1
14 JP16 pin 1
35 JP5 pin 1
26 JP5 pin 2
28 JP5 pin 3
30 JP5 pin 4
32 JP5 pin 5
34 JP5 pin 6
27 JP5 pin 7
3 JP5 pin 8
xPico® Wi-Fi® Embedded Device Server Evaluation Kit User Guide
Description
Install to connect module Ethernet link/WLAN status signal to LED2
Install to connect module Ethernet Speed signal to LED3
Install to connect module Ethernet Activity signal to LED4
Install to connect module Ethernet Duplex signal to LED5.
Remove when using xPico Wi-Fi module to prevent conflict with module wake up
signal.
This jumper is not stuffed by default.

Table 2-13 JP6 LED Header Connections (XPW100300K)

Description
Install to connect module WLAN status signal to LED2

Table 2-14 Additional Headers

Signal
Module reset to defaults
(active low)
Module hardware reset
(active low)
Module wake up (rising edge
triggered)
CP1, configurable pin
CP2, configurable pin
CP3, configurable pin
CP4, configurable pin
CP5, configurable pin
CP6, configurable pin
CP7, configurable pin
CP8, configurable pin
Function
Install jumper (JP3 pins 1 to 2) to use SW1
for asserting default function.
Install jumper (JP4 pins 1 to 2) to use SW2
for asserting hardware reset.
Install jumper (JP16 pins 1 to 2) to use SW4
for asserting module wake up.
Do not install when using xPico (wired)
Ethernet Duplex LED signal.
Test point
Test point
Test point
Test point
Test point
Test point
Test point
Test point
2: Evaluation Kit
