Wildix W-AIR Series User Manual

Dect handset
Hide thumbs Also See for W-AIR Series:

Advertisement

Table of Contents

W-AIR DECT Handset - User Guide
Sep 10, 2019 03:48
W-AIR DECT Handset – W-AIR Basic/ W-AIR 100 (End Of Life)/ W-AIR
LifeSaver/ W-AIR Med/ W-AIR Office
The manual provides you with the necessary information about your DECT handset W-AIR basic (ex W-
AIR 70)/ W-AIR 100 (End Of Life) / W-AIR LifeSaver (ex W-AIR 150) / W-AIR Med / W-AIR Office. Please
read this guide to ensure the proper installation and operation of the DECT handset.
Useful links:
W-AIR Headset - User Guide
W-AIR Network Admin Guide - Sync over the air
W-AIR Network Admin Guide - Sync over LAN
W-AIR Small Business Admin Guide
W-AIR System Datasheet
W-AIR - End User Brochures
Updated: July 2019
Permalink:
https://confluence.wildix.com/x/jQSIAQ
Important: W-AIR 100 is End Of Life.
Before using the handset
Unboxing
Safety information
Put into operation
Phone Overview
W-AIR Basic
W-AIR 100 (End Of Life)
W-AIR DECT Handset - User Guide
Page 1 of 23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W-AIR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Wildix W-AIR Series

Summary of Contents for Wildix W-AIR Series

  • Page 1 W-AIR Network Admin Guide - Sync over LAN W-AIR Small Business Admin Guide W-AIR System Datasheet W-AIR - End User Brochures Updated: July 2019 Permalink: https://confluence.wildix.com/x/jQSIAQ Important: W-AIR 100 is End Of Life. Before using the handset Unboxing Safety information Put into operation...
  • Page 2 W-AIR DECT Handset - User Guide W-AIR LifeSaver W-AIR Med W-AIR Office Main Menu Register a handset Multi registration (W-AIR 100 (End Of Life) / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Login (Assign to user) Local contacts Assign a Speed Dial number to a local contact Call list Call Control Incoming call...

  • Page 3: Before Using The Handset

    Unboxing Examine the package for evidence of physical damage prior to opening. If there is a proof of mishandling, report it to your certified Wildix Partner. Make sure that all the components are present in the shipping package/box: W-AIR Basic:...
  • Page 4 1 x belt clip and belt clip cover Compatible headsets: Wildix headsets: http://www.wildix.com/voip-phones-and-headset/#headsets Third party headsets integrated with Wildix: Wildix Compatible Headsets – Jabra, Plantronics, Sennheiser, JPL, Axtel Safety information Using the battery Never dispose of the battery in fire, otherwise it could explode...
  • Page 5 W-AIR DECT Handset - User Guide Remove the protective foil from the battery contacts Reinsert the battery and close the battery compartment (make sure the latch is fully locked) Connect the A/C adapter to the charger Place the phone into the charger and fully charge the battery (this may take up to 5 hours) The blue LED of the charger is on when the phone is properly placed into the charger and charging W-AIR LifeSaver: Open the battery compartment by turning the lock lever...

  • Page 6: Phone Overview

    W-AIR DECT Handset - User Guide W-AIR LifeSaver W-AIR Med W-AIR Office The serial number and IPUI number of each handset is situated either on a label behind the battery, or on the package label. Phone Overview W-AIR Basic W-AIR DECT Handset - User Guide Page 6 of 23...
  • Page 7 W-AIR DECT Handset - User Guide 1- LED indicator Indicates Missed call / New Voicemail / Low battery. LED behavior can be configured in Settings. 2- 2 Soft keys Select different options indicated in the lower part of the screen. From the idle used to access Contacts / Central directory menu.
  • Page 8 W-AIR DECT Handset - User Guide W-AIR 100 (End Of Life) 1- LED indicator Missed call / New Voicemail / Low battery. LED behavior can be configured in Settings. 2- Volume Up / Down key (on the side panel) 3- Mute key (on the side panel) 4- 3 Soft keys Select different options indicated in the lower part of the screen.
  • Page 9 W-AIR DECT Handset - User Guide When enabled, no sounds are played on the handset. W-AIR LifeSaver 1- LED indicator Missed call / New Voicemail / Low battery. LED behavior can be configured in Settings 2- Volume Up / Down key (on the side panel) 3- Mute key (on the side panel) 4- 3 Soft keys Select different options indicated in the lower part of the screen.
  • Page 10 W-AIR DECT Handset - User Guide 11- Headset jack (3.5 mm) (on the side panel) 12-Pull cord jack (on the side panel) 13- Navigation keys 14- Menu key 15- On-hook / hangup key / back key 16- Silent mode key (long press) When enabled, no sounds are played on the handset.
  • Page 11 W-AIR DECT Handset - User Guide 7- Off-hook / answer key 8- Voicemail key (long press) 9- Key lock (long press) 10- Emergency button 11- Headset jack (3.5 mm) (on the side panel) 12- Menu key 13 - Navigation keys 14- On-hook / hangup key / back key 15- Silent mode key (long press) When enabled, no sounds are played on the handset.
  • Page 12 W-AIR DECT Handset - User Guide 4- 3 Soft keys Select different options indicated in the lower part of the screen. From the idle used to access Contacts / Central directory / Calls menu. 5- Speaker key 6- Confirmation / Selection key 7- Off-hook / answer key 8- Voicemail key (long press) 9- Key lock (long press)

  • Page 13: Register A Handset

    W-AIR DECT Handset - User Guide 6 – Audio settings 7 – Alarms: alarm clock / wake up call setting (W-AIR 100 / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Register a handset Go to Connectivity menu. Register a handset to the base station Select Register (W-AIR 100 / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Select an empty slot Enter the PIN (by default, 0000)

  • Page 14: Local Contacts

    W-AIR DECT Handset - User Guide Login (Assign to user) Press the red On-hook Key to switch on the phone Wait till the signal is found and the phone screen displays “login_x”, “unkown_x” Dial 99 and press the green Off-hook Follow the audio instructions to enter your extension number and your password Press 1 when prompted to use this phone Note: To enter your password, follow these simple rules:...

  • Page 15: Call Control

    W-AIR DECT Handset - User Guide Select Delete contact to delete the selected contact or Delete all contacts to delete all the contacts Confirm by pressing Yes Assign a Speed Dial number to a local contact Prerequisite: There must be at least one contact in the Contacts list. Select a contact that you wish to assign a speed dial number to Press More...
  • Page 16 Colleagues are displayed in the list with their actual presence and activity status (synchronised with Wildix Collaboration): available / offline / do not disturb / away / talking / incoming call. W-AIR DECT Handset - User Guide Page 16 of 23...
  • Page 17 W-AIR DECT Handset - User Guide Call from local contacts Press Menu key and select Contacts / press the Soft key Contacts Select a contact Press Call to call the contact Call from history Press Menu key and select Call list Select a call from the list Press the green Off-hook key Hold / Second call...
  • Page 18 W-AIR DECT Handset - User Guide Enter the number or press Selection key (W-AIR Basic)/ Menu key (W-AIR 100/ W-AIR LifeSaver/ W-AIR Med/ W-AIR Office) to search in Contacts Central directory Press Transfer Soft key Note: As W-AIR Handsets support only 2 calls/ channels, it is impossible to transfer a call to third party since one more channel couldn't be opened.

  • Page 19: General Settings

    W-AIR DECT Handset - User Guide Refer to Feature Codes Admin Guide for detailed information. Adjust volume during a call Press Volume Up / Down keys (W-AIR 100 / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Press Up / Down Navigation keys (W-AIR Basic) Mute the microphone during a call Press Mute key (side key) to mute / unmute the microphone (W-AIR 100 / W-AIR LifeSaver / W-AIR Med / W-AIR Office)
  • Page 20 W-AIR DECT Handset - User Guide missed call new Voicemail low battery Otherwise it is possible to disable the LED signal. Power save Set up the the display to go out after timeout to save the battery (from 5 up to 60 seconds). Security (Auto keylock) Enable / disable auto key lock after timeout (from 15 seconds up to 5 minutes).

  • Page 21: Audio Settings

    WHS, WelcomeConsole-EXT, WPEHS - Quick Start Guide - Phones Accessories Third party headsets integrated with Wildix: Wildix Compatible Headsets – Jabra, Plantronics, Sennheiser, JPL, Axtel Push To Talk (W-AIR 100 (End Of Life) / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Important: enabling this feature reduces the number of available channels on each base station to 6.
  • Page 22 W-AIR DECT Handset - User Guide When the ring volume is set to mute, the “Sound off” icon is displayed in the Status bar and no sound is heard when receiving an incoming call. Ring Melody (for each Call Class) Select the ringtone for each call class (external/ internal/ whitelist/ blacklist/ Alert Volume and Alert Tone (W-AIR 100 (End Of Life) / W-AIR LifeSaver / W-AIR Med / W-AIR Office) Select the Volume and the Ringtone for the alarm clock.
  • Page 23 W-AIR DECT Handset - User Guide Note: When the alarm starts ringing, press Dismiss to disable it, or Snooze to repeat the alarm after the selected timeout. To set up snooze timeout: select Snooze time and select the timeout. Emergency alarms setting (W-AIR LifeSaver / W-AIR Med / W- AIR Office) Note: Emergency settings are defined and controlled from the web interface of the base station.
