Summary of Contents for Wildix W-AIR
- Page 1 Quick Start Guide Wildix W-AIR...
-
Page 2: W-Air System
Wildix - Discover New Ways To Communicate This brief guide will allow you to set up your W-AIR Network and connect your cordless phones. W-AIR SYSTEM Wildix W-AIR Base station Wildix W-AIR Repeater Wildix W-AIR cordless phone HOW TO INSTALL... -
Page 3: Wildix W-Air Base Station
It's the basic component serving to create the wireless network. It's possible to register up to 200 cordless phones (only Wildix W-AIR phones). Base station allows up to 10 calls at the same time. Connecting other Base stations increases the number of calls (up to 40). -
Page 4: How To Install
Wildix - Discover New Ways To Communicate Up to 3 Repeaters connected in chain Wildix W-AIR cordless phone XML phone book Synchronization of the settings with the CTIconnect (DND etc) 2'' TFT display with graphic interface 176 x 220 pixel 262K color... - Page 5 Configuring the W-AIR Network Detect a gateway Go to Devices on WMS page, find the network to which W-AIR is connected and search for devices. An unconfigured device will appear in grey → select it and press Configure / Sync device button to associate it with the system.
-
Page 6: Configure The Cordless Phone
● the LED blinks purple when the base is rebooting ● the LED blinks red when the base reports a configuration error ● the LED remains solid blue if the base is configured and registered to the Wildix PBX Configure the cordless phone ●... -
Page 7: Set Up Repeaters
Wildix - Discover New Ways To Communicate The phones can be registered manually (e.g. if a phone belongs to another network) ● Verify that there is only one active W-AIR Network ● Press the Settings key ● Select Connectivity ● Select Deregister, enter 0000 as PIN then press Yes ●... -
Page 8: Technical Notes
Wildix - Discover New Ways To Communicate Technical Notes How to check the Radio Coverage Cordless phone ● Press the Settings key ● Type *service* (*7378423*). ● Select the line Site survey mode on the administrator menu ● The phone will show up to 5 bases (RPN) and the coverage value. - Page 9 Wildix - Discover New Ways To Communicate The following radio related issues must be considered before deploying a typical WILDIX W-AIR VoIP System. They include: ● Building Penetration: when a signal strikes on a building it is diffracted or absorbed;...
- Page 10 Before starting the deployment measuring make sure the cordless phone is fully charged, then follow the steps below: ● place the W-AIR base station exactly at the desired position and power on the base. ● use the building plan drawing and check the base station coverage using the phone and Site survey mode of the phone.
- Page 11 Contacts Wildix srl WILDIX sarl Località le Basse 3, 6, rue de la Grande Ourse 38123 Trento (TN) - Italy 95000 Cergy Pontoise - France T. +39 0461.1715112 T. + 33 176 747 980 support@wildix.com support@wildix.fr...
