W-AIR Network Admin Guide - Sync over the air
Mar 29, 2020 04:21
W-AIR Network Admin Guide - Sync over the air
This guide leads you through installation of W-AIR Base and W-AIR Base Outdoor and setting up a W-
AIR DECT Network in which the bases sync over the air.
Updated: June 2016
Permalink:
https://confluence.wildix.com/x/IADfAg
W-AIR Base is End Of Life.
Description
System architecture
Multicell network scalability and features
Planning a multicell network
Before you start
Handover and Roaming
Handover
Roaming
Deployment considerations
Capacity planning
Site Survey
Requirements
How to check RSSI level
Placing the first base station
Check the Radio Coverage
Handset
Base station
Repeaters
Base station/ Repeater Placement Strategy
Radiation pattern - base optimal position for optimal coverage
Base station and repeaters connection and overview
Packing lists
Base stations mounting, connection and reset
LEDs of the Base Stations
Mounting instructions
Find Base station IP
Repeaters connection and overview
Repeater connection and reset
LEDs of the Repeaters
W-AIR Network configuration
Step 1. Provision base stations
Step 2. Create a W-AIR Network
W-AIR Network Admin Guide - Sync over the air
Page 1 of 27

Advertisement

loading
Need help?

Need help?

Do you have a question about the W-AIR Base and is the answer not in the manual?

Questions and answers

Related Manuals for Wildix W-AIR Base

Summary of Contents for Wildix W-AIR Base

  • Page 1 Mar 29, 2020 04:21 W-AIR Network Admin Guide - Sync over the air This guide leads you through installation of W-AIR Base and W-AIR Base Outdoor and setting up a W- AIR DECT Network in which the bases sync over the air.
  • Page 2 Base station - an essential component of a DECT system. Wildix W-AIR base stations: Multicell base stations: W-AIR Base (End Of Life), W-AIR Base Outdoor, W-AIR Base Sync Plus (for sync over LAN, refer to W-AIR Network Admin Guide - Sync over LAN Single Cell base station: W-AIR Base Small Business.
  • Page 3 Guide, W-AIR Headset Guide. Multicell network scalability and features Sync over the air with W-AIR Base, W-AIR Base Outdoor or mixed network in which W-AIR Bases Sync Plus are present: Up to 1000 users per system Up to 250 bases...
  • Page 4 W-AIR Network Admin Guide - Sync over the air Intelligent Networking Configuration: Connecting 3 Repeaters in a chain: Base Station and Repeater positioning: For a good conversation and a correct handover between Bases and Repeaters the dBm value must be between -75 and 0.
  • Page 5 W-AIR Network Admin Guide - Sync over the air Handover and Roaming Handover Handover is a process in which a call is transmitted from one base station to another without interrupting the session. When the call is set up, the handset is located at Base 1. Thus, the DECT communication takes place between the handset and Base 1, and the SIP signaling as well as the RTP stream takes place between Base 1 and the PBX: After handover, the handset is located at Base 2, and hence the DECT communication goes on between the...
  • Page 6 W-AIR Network Admin Guide - Sync over the air Since the call control and hence the SIP User Agent remains at the initial base station, the SIP registration is also unaffected by the handover. If the handset makes yet another handover, the RTP stream will still be relayed via the base station at which the call was established (Base 1 in our case): Roaming roaming...
  • Page 7 These interferences can come from the same network or from the outside. For choosing the optimal position of the Base station and Repeaters, these potential interference sources should be considered before installing a Wildix W-AIR system. Radio/ Cell Range: a suggested distance between two base stations depends on the physical path between them.
  • Page 8 Placing the first base station Follow the steps below: place the W-AIR base station exactly at the desired position and power on the base. Check RSSI level on the handset. use the building plan drawing and check the base station coverage using the Site survey mode of the phone.
  • Page 9 W-AIR Network Admin Guide - Sync over the air Handset Press "Menu" key of the W-AIR handset (the phone must be registered to the base station) Type *service* (*7378423*). Select the line Site survey mode The phone will show up to 5 bases (RPN) and the coverage value. Check PP and FP values, they indicate the transmission errors.
  • Page 10 W-AIR Network Admin Guide - Sync over the air Metallic Structures/Objects: base stations and Repeaters should not be deployed near large metallic objects Reinforced Concrete Structures: these structures create a high attenuation factor inside the building. They reduce the radio coverage range of the Base stations and Repeaters thus a higher number of base stations or Repeaters are required in the building.
  • Page 11 Mounting screws x 2 and anchors x 2 Plastic stand x 1 Base station unit x 1 W-AIR Base Outdoor: Enclosure 175x250x75mm with some pre-installed parts: RJ45 cable gland + O-ring + Counter Nut x 1 set Ventilation Device x 1...
  • Page 12 W-AIR Network Admin Guide - Sync over the air LED blinks red when a base reports a configuration error LED remains solid blue if a base is configured and registered to the Wildix PBX Mounting instructions W-AIR Base Mount the base unit as high as possible to clear all nearby objects (e.g. office cubicles and cabinets, etc.). Make sure that when you fix the base stations with screws, the screws do not touch the PCB on the unit.

  • Page 13: W-Air Network Configuration

    Sync source base/repeater not found (Manual mode) Timeout during RPN allocation due to busy base/repeater W-AIR Network configuration Step 1. Provision base stations For detailed instructions, refer to Provisioning of Wildix devices - Admin Guide Go to menu Devices of the WMS, click +Add and provision the gateway.
  • Page 14 W-AIR Network Admin Guide - Sync over the air The first base becomes the Main base of the network (M). The gateways make radio sync over the air with each other automatically to extend the work range if possible. Go back to the Devices Menu , select your base/bases and press “...
  • Page 15 W-AIR Network Admin Guide - Sync over the air Admin password is also accepted To unregister the handset: Log out (register to “unknown” account) by calling the Feature Code “Login” (“99” by default) Select “Deregister” in the “Connectivity” menu of the handset Enter the Pin Code “0000”, then press “Yes”.
  • Page 16 W-AIR Network Admin Guide - Sync over the air Find the IP of the base station that you want to repeat (on the WMS devices list) Access the base station's web interface, enter a username “admin” and a password that you can find in the WMS Devices menu in the “Password”...
  • Page 17 W-AIR Network Admin Guide - Sync over the air Bad deployment example: Good deployment example (Secondary Base 1 and 2 are at sync level 1, Secondary Base 3 is at sync level 2) Case 2: Sync chain without alternative sync paths A maximum of 250 base stations can be deployed in one setup (depending on the network requirement not all base stations should be chained).
  • Page 18 W-AIR Network Admin Guide - Sync over the air Case 3. Sync chain with alternative sync paths. The scheme below shows a multicell network with alternative synchronisation paths. A failure of one base unit does not mean handset or users cannot perform handovers to other active cells. If the Secondary Base 2 is down, the majority of user handovers can be performed via 3 other alternative cells (i.
  • Page 19 W-AIR Network Admin Guide - Sync over the air Base 4 and 1 are Primary with alternative sync to the Primary Base. Base 5 is primary sync to Base 4 while alternative sync is Base 1 or 2. Base 3 is primary sync to Base 2 while alternative sync is Base 5 or 6. In the scheme below: Base 24 is the primary sync to Base 25 while alternative sync is Base 20 Base 22 is the primary sync to Base 20 while alternative sync is Base 21 or Base 23...
  • Page 20 W-AIR Network Admin Guide - Sync over the air W-AIR Network Admin Guide - Sync over the air Page 20 of 27...
  • Page 21 W-AIR Network Admin Guide - Sync over the air Verify deployment The actual sync RSSI may be read on the base station web interface. It is recommended to have a RSSI value better than/ equal to -75dBm, and never below 090dBm. Take a look at the DECT Chain Tree to check the solution you have decided to set up.

  • Page 22: Call Features

    Call Features DND, Call forwarding, Paging, Call intrusion, Intercom All the Call Features can be set up in WMS or Wildix Collaborations in User Settings, or otherwise, directly from the handset, by dialing the Feature Codes of the system. Consult the guide...

  • Page 23: Alarms Setting

    W-AIR Network Admin Guide - Sync over the air W-AIR Handsets support only 2 calls/ channels, this means, when you have one active call and one call on hold, you can only transfer perform a transfer of the active call to the party which is on hold, or vice versa. You cannot transfer a call to some third party, because no more channel can be opened.
  • Page 24 W-AIR Network Admin Guide - Sync over the air Pull Cord Alarm The Pull Cord alarm can be triggered by pulling a cord containing a magnet from the pull cord hole on the right side of the handset. Running Alarm To trigger the Running Alarm the handset needs to be shaken up and down for several seconds.
  • Page 25 W-AIR Network Admin Guide - Sync over the air After you have defined the Emergency profiles, click Save to apply. Assign emergency profile to handsets Go to the menu Extensions Click on the field “Idx” or “Extension” of the handset: The following window is displayed, allowing you to set up emergency settings: W-AIR Network Admin Guide - Sync over the air Page 25 of 27...
  • Page 26 W-AIR Network Admin Guide - Sync over the air 4. Modify the parameter “Alarm Number”: Enter the number to be called when the alarm is triggered from the handset You can enter an extension number that must be called or customise the service by modifying the Dialplan in the WMS and to add the “Alarm Number”...
  • Page 27 W-AIR Network Admin Guide - Sync over the air Tick off the Profiles that you wish to enable for this handset Click Save at the bottom of the page Go to Management menu and click Save and reboot to reboot the base station and apply the new parameters W-AIR Network Admin Guide - Sync over the air Page 27 of 27...
