Summary of Contents for Sanyo Denki SANUPS A11J
- Page 1 M0012255 Power Distribution Box Instruction Manual...
-
Page 2: Table Of Contents
§8.2 Circuit system drawing ..................*Service technicians This term is used to indicate service technicians from SANYO DENKI or entrusted from SANYO DENKI with knowledge of this UPS. Maintenance work must not be performed by other than a qualified service technician. -
Page 3: Before Using The Product
Before Using the Product § § This is Power Distribution Box for 10 kVA type of A11J Series UPS. See “§1.1 Checking combination of UPS and the Power Distribution Box”, check the available UPS model name. Be sure to follow the procedures described in this instruction manual to ensure safe and proper Power Distribution Box use. ⇒... -
Page 4: Safety Precautions
3. This warranty is void in the event of any modifications or changes to the product supplied by SANYO DENKI. 4. This warranty is void in the event of any improper use of the product supplied by SANYO DENKI, or failure to use the product as specified in this instruction manual. -
Page 5: Checking The Contents Of The Package
Is there any external damage or anomaly? □ Place a check mark in the boxes to confirm. Contact your sales representative or SANYO DENKI if anything is missing. Each figure is a rough indication. The actual shapes of the UPS and accessories may differ. -
Page 6: External Dimensions And Part Names
Dimensions and Part names § § 2 3 6 . 7 ① O U T P U T 1 O U T P U T 2 O U T P U T 3 ③ ② M C C B 1 M C C B 2 M C C B 3 I N P U T... -
Page 7: Installation And Wiring
Installation and Wiring § § § § Installation should be performed only by service technicians. ！ Installation of the Power Distribution Box must be carried out following the instructions in this instruction manual. CAUTION Improper installation may result in an electric shock, bodily injury, and/or a fire. §... - Page 8 Installation and Wiring ④ Install the Power Distribution Box on the rear of the UPS Unit 1 using the four screws prepared in step ②. Refer to the figure for installation. When installing the Power Distribution Box, ！ take care not to get your fingers caught, and not to drop the Power Distribution Box.
-
Page 9: Wiring Input / Output
Installation and Wiring § § Wiring should be performed only by service technicians. The Power Distribution Box wiring must be carried out following the instructions in this instruction manual. Incorrect wiring may result in electric shock and/or fire. ！ Make sure that connection of input cable is not loose. Failure to do so may result in electric shock, injury, and/or a fire. -
Page 10: Connecting To Output Outlet
Installation and Wiring § § ① Connect the load devices to the output outlets on the Power Distribution Box. ② Set the output outlet breakers MCCB 1 , MCCB 2 , and MCCB 3 corresponding to the output outlets that connect the load devices to “ON.”... -
Page 11: Characteristics
Characteristics § § § § Item Standard or performance Model PDBA11J103B02C Rated capacity 10 kVA * Number of phases Single-phase 2-wire Rated voltage 200/208/220/230/240V Rated frequency 50/60Hz Number of phases Single-phase 2-wire 200/208/220/230/240V Rated voltage (Same as AC input) Rated frequency 50/60Hz Outlet, NEMA L6-20R ×...
