Sanyo Denki Sanups A11J Instruction Manual

Sanyo Denki Sanups A11J Instruction Manual

On line ups 10 kva
Hide thumbs Also See for Sanups A11J:
Table of Contents

Advertisement

Quick Links

Download this manual
M0011851
10 kVA
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sanups A11J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sanyo Denki Sanups A11J

Summary of Contents for Sanyo Denki Sanups A11J

  • Page 1 M0011851 10 kVA Instruction Manual...

  • Page 2: Table Of Contents

    §7.3 Power Outage Simulation Test..............Service technicians This term is used to indicate service technicians from SANYO DENKI or entrusted from SANYO DENKI with knowledge of this UPS. Maintenance work must not be performed by other than a qualified service technician.
  • Page 3 Notes about UPS Models This instruction manual is for the UPS model numbers in the table below. Check the model number and type of your UPS. Output Unit Type* Model Number TYPE Capacity Without terminal block UPS unit 1 (Unit with I/O connector only) 10 kVA A11J103U002T A11J103A002TU...

  • Page 4: Before Using The Product

    Before Using the Product § § This chapter describes the procedures for using the UPS. Be sure to follow the procedures described in the instruction manual to ensure safe and proper use of the UPS. Check the safety precautions ⇒ Pages 2 to 5 Check the operating precautions ⇒...

  • Page 5: Safety Precautions

    Safety Precautions § PRECAUTIONS (IMPORTANT SAFERY INSTCUTIONS) This manual contains important instructions for operating and maintaining the A11J Series and the batteries to protect the safety of the customers and the service technician. Before installing, operating, performing maintenance or inspecting the UPS, be sure to read this manual and accompanying documents carefully to obtain a clear understanding of the information related to its operation, safety and important precautions.
  • Page 6 Safety Precautions 1. Relocation, Transportation, and Moving Precautions CAUTION Be careful to avoid falling or dropping the UPS during relocation and transportation. It may cause injury. Place the UPS horizontally during relocation or transportation, and protect the UPS so that not subjected to impact or strong physical shock.
  • Page 7 Devices which serve applications related to the above Contact your sales representative or SANYO DENKI if you need to use the UPS in an application like the above. Special equipment, such as redundant devices or an emergency generator, must be incorporated when operating, maintaining, and controlling systems in which a UPS is used with loads affecting life-support or public infrastructure-dependent applications.
  • Page 8 Safety Precautions 6. Radio Frequency Interference CAUTION This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 9: Operating Precautions

    Operating Precautions § § § § (1) Input Power Supply and Power Supply Capacity The following table shows the rated AC input power of this UPS. For the voltage and frequency variation ranges, see “§12.4 Specifications.” AC Input Frequency Input Input Distribution Model Number AC Input Voltage Rating...

  • Page 10: Installation Precautions

    (6) L-type rails (support rails) are required to mount the UPS on a rack. For more information, contact the manufacturer of your rack, your sales representative, or SANYO DENKI. (7) When disposing the UPS, treat it appropriately as industrial waste. The batteries in this UPS are lead type batteries.

  • Page 11: Checking The Contents Of The Package

    □ Place a check mark in the boxes to confirm. Contact your sales representative or SANYO DENKI if anything is missing. Figure is a rough indication. The actual shapes of the UPS and accessories may differ. UPS unit 1 □...

  • Page 12: External Dimensions And Part Names

    Part Names § § § § Unit: mm 261.6 UPS unit 1 (321.6) UPS unit 1 UPS unit 2 UPS unit 2 External Dimensions when Fixed to Floor 321.6 301.6 4- Φ 10 Cable cover The following table shows the weight and depth. Weight (kg) Depth (mm)* UPS Unit...
  • Page 13 *1. The forced bypass switch Forced Bypass is used when using the maintenance bypass breaker MAINTENANCE MCCB . Normally, leave the switch set to “Inverter” and do not change the setting. *2. For the various optional devices, contact your sales representative or SANYO DENKI. *3. In this manual, breakers and switches are displayed enclosed in...

  • Page 14: Lcd Panel

    Part Names § § ② UNINTERRUPTIBLE POWER SUPPLY ① ③ ⑤ ⑥ ⑩ ⑧ ⑦ ⑨ ④ Name Label Color Function When input power is normal. ① Input LED Green INPUT Blinking When input power is abnormal. ② Backup LED Green When the battery is operating.

  • Page 15: Ups Unit Control Panel

    Part Names § § ④ ① ② ③ ⑤ Name Label Color Function When input power is normal. ① Input LED Green INPUT Blinking When input power is abnormal. When supplying power by inverter operation. ② Output LED Green OUTPUT Blinking When supplying power by bypass operation.

  • Page 16: External Interfaces

    8 CTS 9 RI CARD I/F ② Connect the connection cable of an optional SANYO DENKI LAN interface card. When connecting a LAN interface card, set the interface to (work station). For the Card interface interface setting procedure, see “§3.5 Setting PC Interface” in the LCD Panel Operating connector Manual.
  • Page 17 Part Names Name Function SIGNAL I/F Outputs status information of the UPS such as a power outage or voltage drop. ③ Contact signal External Transmission Signals and Shutdown Input Signals interface connector Pin No. Signal Name Description Status when Operating This signal is output when there is a power outage or 1-8: ON AC input error...
  • Page 18 Part Names Name Function REMOTE/EPO Use these terminals for controlling the UPS with a non-voltage contact from an external ⑤ device. External control terminals REMOTE/EPO Terminal Names External Appearance 6 COM terminals 5 EPO 4 COM 3 Remote OFF REMOTE terminals 2 COM 1 Remote ON...

  • Page 19: Ups Installation And Wiring

    50 cm at the back. Using the UPS horizontally requires dedicated brackets. Contact your sales representative or SANYO DENKI. Do not use the UPS in an unsecured state. There is the danger that the UPS will topple or fall.

  • Page 20: Installing The Ups Vertically

    UPS Installation and Wiring § § When installing the UPS vertically, attach the supplied floor mounting brackets. Verify UPS Unit 1 and UPS Unit 2 (with terminal block) on the back of the UPS Units, and arrange them as shown under the “○” in the figure below. Rear view Front view Connector...

  • Page 21: Mounting The Ups On A Rack

    UPS Installation and Wiring § § ！ For safety, use L-type rails (support rails) when mounting the UPS on a rack. For more information on L-type rails, contact your rack manufacturer or sales representative. CAUTION See “§6.1.2 Checking the Installation Space” and make sure you secure enough ventilation space at the front and the back of the UPS.
  • Page 22 UPS Installation and Wiring § § Battery pack A and B have been installed in UPS unit before shipped out. ① Prepare the following items supplied with the product. Screw C: For securing LCD panel M3×6 2 LCD panel 1 Battery pack B LCD panel connection cable 1 Battery pack A...
  • Page 23 UPS Installation and Wiring The weight of one battery pack is 17.5 kg. ⑤ Remove the battery securing bracket. Take care not to drop them. Insert the ⑥ Insert two battery packs into the unit. battery pack on the left side first when ！...

  • Page 24: Wiring The Ups

    UPS Installation and Wiring § § Wiring should be performed only by service technicians. UPS wiring must be carried out following the instructions in this instruction manual. Incorrect wiring may result in electric shock and/or fire. Take precautionary measures when wiring such as wearing insulated gloves. There is danger of ！...

  • Page 25: Wiring To The Terminal Block

    UPS Installation and Wiring § § ① Prepare the following items supplied with the product. Cable cover for UPS unit1 Cable cover for UPS unit2 Screw D for cable cover M4×8 8 ② Check that MAIN MCCB on the front of the two UPS Units are “OFF.” ③...
  • Page 26 UPS Installation and Wiring ⑥ Connect the ground to the terminal of the terminal block. Use class D grounding for the ground. ⑦ Connect the utility power supply to the “INPUT L and N” input terminals. ⑧ Connect the customer's load to the “OUTPUT L and N” output terminals. Notes on terminal block wiring Terminal Connection Procedure 1.

  • Page 27: Connecting Optional Devices

    For details on connector functions, see “§5.4 External Interface,” Section ③. Connect the dedicated communication cable to use the SANYO DENKI power management software. With UPS and computer communication, you can manage the power supply from a computer. For details, see the instruction manual of the power management software.

  • Page 28: Preparation Before Operation

    LEDs have turned off, and then set it to “ON” again. If the LEDs start blinking again even after performing step ②, contact your sales representative or SANYO DENKI. Check the settings in the setting menu of the UPS. ③...

  • Page 29: Charging The Ups

    Green: Green: Off Red: Off Green: Blink Green: Blink SANYO DENKI Green: Off SANUPS A11J Red: Off After approx. 5 seconds The LEDs of the two UPS Units are in the same state. - STANDBY - Vi=*** Fi=*** of the ①...

  • Page 30: Power Outage Simulation Test

    Green: Green: Off Red: Off Green: Blink Green: Blink SANYO DENKI Green: Off SANUPS A11J Red: Off After approx. 5 seconds The LEDs of the two UPS Units are - STANDBY - in the same state. Vi=*** Fi=*** ① Set...
  • Page 31 Is the OUTPUT” off? “Green ⇒ Steps ② and ③ of “§7.3 Power Outage Simulation Test” ALARM” and/or WARNING” on? Contact your sales representative or SANYO DENKI. “Red “Red ALARM” and/or Red WARNING” Contact your sales representative if “Red “...

  • Page 32: Operation Procedures

    Green: Green: Off Red: Off Green: Off Blink Green: Blink SANYO DENKI Green: Off SANUPS A11J Red: Off After approx. 5 seconds The LEDs of the two UPS units are in - STANDBY - the same state. Vi=*** Fi=*** of the two ②...
  • Page 33 Preparation Before Operation Check that the LCD display and LEDs are in the states shown in the figure below. ④ Green: On Green: Off Red: Off Green: On Green: On Green: On - ONLINE **** Red: Off The LEDs of the two UPS Units are in the same state.

  • Page 34: Shutting Down The Ups

    Preparation Before Operation § § Follow the procedure below to shut down the UPS. Be sure to shut down the load devices before shutting down the UPS. Press any key on the LCD panel to display the screen. ① ② Press ③...

  • Page 35: Operation Using The Ups Unit Control Panel

    Preparation Before Operation § § You can use the control panel on the right side of the front of the UPS to start up and shut down the UPS. The UPS Unit control panel can be used to operate individual UPS Units, so you can use it, for example, to shut down only a UPS that has malfunctioned.

  • Page 36: Inspection And Maintenance

    Service technician *What are service technicians? This term is used to indicate service technicians from SANYO DENKI or entrusted from SANYO DENKI with knowledge of this UPS. Maintenance work must not be performed by other than a qualified service technician.

  • Page 37: Routine Checks By Customer

    Inspection and Maintenance § § Be sure not to inspect the inside of the UPS. Doing so may result in an electric shock, burn, injury, fuming, or fire. Do not touch the fan on the back of the UPS when cleaning the UPS or anywhere around ！...

  • Page 38: Resetting The Main Breaker

    Inspection and Maintenance § § If the total capacity of the load devices connected to the UPS exceeds the rated capacity of the UPS, the UPS enters the overload state and the main breaker MAIN MCCB of the UPS Unit control panel trips. If the main breaker trips, output stops.

  • Page 39: When A Buzzer Sounds

    The buzzer will sound again each time you start the UPS. This will continue until you replace the batteries. Note If any other trouble occurs or you think there is a malfunction, contact your sales representative or SANYO DENKI.

  • Page 40: Troubleshooting

    Troubleshooting § § Internal inspection and maintenance of the UPS should be performed only by service technicians. Electric shock, bodily injury, burns, fuming, or fire may otherwise result. Before beginning inspection, shut down the UPS completely and remove the input power. There is ！...
  • Page 41 Troubleshooting UPS Status LCD Indication LED Status Countermeasure on the LCD panel or on the UPS Unit control panel pressed Green INPUT: On -STANDBY- accidentally and set to “OFF”? Perform the correct procedure to set it to “ON.” tripped? MAIN MCCB The breaker may have tripped by an overload or short circuit.
  • Page 42 Contact your sales representative or SANYO DENKI. Note If the UPS does not operate normally even if you perform the countermeasures above, or if any other trouble occurs or you think there is a malfunction, contact your sales representative or SANYO DENKI.

  • Page 43: Ups Characteristics

    UPS Characteristics § § § § (1) During normal operation During normal periods, the UPS converts AC power from the utility power source into DC power through the rectifier, and Utility Rectifier Inverter Output power (converter) reconverts this DC power back into AC power through the inverter and supplies it to the load.

  • Page 44: Protective Functions

    ⑥ *******･･････*******･････ See “§10. When A Buzzer Sounds” and perform the corresponding countermeasure. If the UPS has malfunctioned, contact your sales representative or SANYO DENKI. *3. In the following cases, the UPS switches to bypass operation when a serious failure occurs.

  • Page 45: Specifications

    UPS Characteristics § § Item Standard or Performance Notes Model A11J103U002T Type A11J103A002TU N units setting 10 kVA/9 kW Selectable Output capacity Default: N units setting N+1 units setting 5 kVA/4.5 kW Cooling system Forced air cooling Input terminals Terminal block M6 Number of phases Single-phase 2-wire Selectable.

  • Page 46: Warranty

    This warranty is void in the event of any modifications or changes to the product supplied by SANYO DENKI. This warranty is void in the event of any improper use of the product supplied by SANYO DENKI, or failure to use the product as specified in this Instruction Manual.
