If operation mode "Control via remote contacts" is used, controller release must be
turned on at STOA (Terminal X11.3) and STOB (Terminal X13.3) and Bit 0 of the control
word must be set in order to be able to start the drive.
The frequency inverters support an external 24 V power supply for the frequency invert-
er control electronics. Even when mains voltage is disconnected, communication between
the controller (PLC) and the frequency inverter is still possible.
Bit 4 "Power supply – enabled" of the status word shows the current mains power supply
status:
Bit 4 "Power supply – enabled" = 0 signals "No mains voltage", starting of drive not pos-
sible.
Bit 4 "Power supply – enabled" = 1 signals "Mains voltage on", drive ready for starting.
12/13
Status word
8 7 6 5 4 3 2
Agile
VABus/TCP
1 0 Bit
0 Ready to switch on
1 Switched on
2 Operation enabled
3 Fault
4
Voltage enabled
5
Quick stop (Low active)
6 Switch on disabled
7 Warning
8 -
9
Remote
10
Target reached
11
Internal limit active
12 -
13 -
•
14 -
15 Warning 2
