7.2

Setup

By default, the parameters of the CM-VABus/TCP and CM-VABus/TCP-2P communication modules are
set up as follows:
Parameters
No. Description
388
Bus Error Behaviour
1432
IP-Address
1433
Netmask
1434
Gateway
1435
DNS Server
1436
DHCP Option
1437
IP Command
1440
Email Function
1441
Email Text (Body)
The parameter settings must be adapted to the actual application.
7.3 TCP/IP address & subnet
For proper identification, each frequency inverter is assigned a TCP/IP address which must be unique
in the system.
7.3.1

Network without DHCP server:

The address is set via parameter
be entered properly for the local network.
Parameters
No. Description
1432 IP address
1433 Netmask
7.3.2

Network with DHCP server:

When a DHCP server is used, manual network configuration is not required. Set
to "1-Enabled" if you wish to use the DHCP function.
DHCP Option 1436
0 - Disabled
1 - Enabled
26
Factory setting
172.22.1.25
255.255.255.0
1432. In addition, the subnet mask
IP-Address
Min.
0.0.0.0
0.0.0.0
Module must be configured manually, no DHCP server is used.
(Factory setting).
The settings are made by a DHCP server.
Agile
VABus/TCP
Settings
1
0.0.0.0
0.0.0.0
0
-
0
-
-Netmask
Settings
Max. Factory setting
255.255.255.255
255.255.255.255 255.255.255.0
DHCP Option
Function
1433 must
172.22.1.25
1436
12/13
