Mounting and Installation
■Installation
Never mount the product in a location that will be used as a foothold.
●Installing
Install the product (with bracket) using the M4 screws (4 pcs.).
The required tightening torque is 0.69 to 0.83 Nm.
Tightening with excessive force may damage the product.
Refer to the dimension drawing (page 22) for mounting hole dimensions.
-13-
No.PF※※-OMG0006-F
