Inhibiting a Point

Point Offset

Single Point Log Printout

m Version 3.11
Note: If a point has a local offset applied to it, this will be indicated by the
presence of the offset icon
When the Detail Scan mode is selected, the display will cycle through all the
activated points in turn pausing for 3 seconds on each one so that the current
status may be read.
Press either the '
key to display the historical graph data.
To inhibit a point so that it cannot create an alarm, select the required point and
press '↵' . The Confirm Inhibit Yes/No message is displayed. Use the '
key to toggle the answer and press '↵' . When a point is inhibited a
displayed alongside the point type. To uninhibit a point repeat the operation.
If the alarm condition is exceeded on an inhibited point (i.e. Pull-down), then
the animated pull-down arrows will be displayed next to the inhibit symbol
The inhibit function can be password protected. This can be configured by
accessing the 'Passcode Setup' screen.
Any points on the m can have an offset applied to the displayed readings to
compensate for cable runs loss etc. These offsets are point specific and may
only be defined from the m keypad, although their value is readable when
accessing the unit remotely. Under normal circumstances these offsets (if
required) will be entered at installation and should only be modified by Danfoss
personnel. Any point which has an offset active will display the offset icon
both the Point Detail and Point Overview screens.
In the Point Detail screen, pressing the '
box. Use the '
to move through each field. Press the '
screen is displayed and the data is sent to the printer.
Manual RS.8A.N5.0 © Danfoss 10-007
This area also displays 'inhibit' , 'defrost' and 'pulldown' icons, if
the point has been setup for 'Local' .
- an inhibited point.
- a point in inhibit pulldown.
- a point in defrost.
- a point in defrost pulldown.
located under the units indicator.
' key or the ' ' key to return to the Main Menu or the '
' key displays the Print Range option
' , ' , ' ' and ' ' keys to enter the required value and the '↵' key
' key and the Printing in Operation
'
' or ' '
symbol is
.
on
