Password Setup
Point Offset Passcode Protection
Setting the Log/Chart Frequency
m Version 3.11
Defrosts per This field only becomes active if 'Master' is selected in the
Day
Day Night
Control
This option allows you to change the three different levels of passcodes – Main,
Local and User, also the Inhibit Protection can be activated. The Main and Local
Passcode provides access to all the setup screens. The User Passcode only
provides access to the Time/Date setup.
From the Setup Menu, select the Password Setup option.
Use the '↵' to highlight the passcode to be modified. Type in the passcode
using the '
' key to move the cursor left or right respectively. N.B. Local passcode is
numeric only.
You can use the ' ' and ' ' keys together to delete the character before the
cursor and '
' to return to the Setup Menu.
To set the Inhibit Protection, use the '↵' key to highlight the 'Inhibit Protected'
field, then using the '
To set the Point Offset Passcode Disable, use the '↵' key to highlight the 'Pt
Offset Disable' field in the Passcode Setup menu, then using the '
select either 'Yes' or 'No' .
To set the print frequencies, select the Log/Chart Frequency option from the
Setup Menu.
Use the '↵' to highlight the field to be modified. Type in the time required using
the '
move the cursor left or right respectively.
Set the values as follows:
Log Print Interval
Start Print at
Graph Print Interval Set this value to determine the interval
Start Print at
Sampling Rate
Manual RS.8A.N5.0 © Danfoss 10-007
previous field. Enter the amount of defrosts per day
required, then whether the times are to be set 'Manually'
or 'Auotmatically' .
Manual - all defrost times entered manually.
Auto - select the number of defrosts per day, enter
the first defrost time, then the remaining
times will be calculated for a 4 hour period.
Select either 'Yes' or 'No' depending on whether the Day/
Night Control on the controller is to be activated of not.
' or ' ' keys to cycle through the character list and the ' ' or '
' to change case. When the passcode has been set, press '↵' then '
' or ' ' keys to select either 'Yes' or 'No' .
'and ' ' keys to cycle through the character list and the ' ' or ' ' key to
Set this value to determine the interval between
log prints (hours : minutes).
Enter the time in the day in which you require the
printing of the automatic log readings to start. (Only
points that have been set as Timed or ON will be
printed).
between graph prints.
Enter the time in the day that you require the
automatic graph to be printed. (Only points that
have been set as Timed or ON will be printed.)
Set this field to the frequency of sampling
required for the graphs.
' or ' ' keys
