Alarm Action Setup

When an alarm occurs, a number of settings will determine which func-
tions are to be activated.
The definition of each point includes assigning an action number from
1 to 15.
The latter menu display is used to determine which functions will be
activated by the action number in question.
Pressing "Mute" results in alarm reset
Action- Pressing "Mute" results in alarm reset and alarm reset for AKM
number
As above, but also transmits alarm status 0 to AKM, if the alarm turns itself
off
Action number for use in setting the trigger
Relay 1
Relay
Siren
Lamp
Flash
Function
Dial O. 1
Dial O.
Dial O. 3
Dial O. 4
Dial O. 5
Print
The lines Dial Out 1 to 5 will
only be visible if "Modem" is
selected in the menu "AK Com-
munication Setup".
Modem Dial Out Settings
Device:
Relay :
34
Settings
Trigger: 000000000
Manual RS.8A.N5.0 © Danfoss 10-007
1 2
9 10
1
1 1
1 1
1 1
1 1
1 D
1 D
1 D
1 D
1 D
1 1
The trigger settings shown are factory settings,
but these can be changed as required.
Settings have the following function:
0: No action
1: Action
D: Action, but only for the day period
N: Action, but only for the night period
The day and night definition is set using the
display "SYSTEM TIME SETUP".
Description
Enables modem power control
