Input Type; Input Number; Y Axis; Y Base - Danfoss m2 Manual

Input Type

Input Number

Y Axis

Y Base

4 - 20 mA Inputs

Pulsed Input Setup

Mode

Pls/kWh

m Version 3.11
Use the '
and the ' ' or ' ' key to move the cursor left or right respectively. Press the '↵'
key to move onto the next field.
Use the '
·
·
·
·
This field is to specify the input number of the (Remote) third party controller or
m+ unit.
Use the '
and the ' ' or ' ' key to move the cursor left or right respectively. Press the '↵'
key to move onto the next field.
This field refers to the overall size of the graph temperature range. Entering
zero selects the auto-scale option. Alternatively, enter the required range. The
range goes from the lowest graph point (Y Base value) to the highest graph
point. Use the '
This field refers to the lowest value the graph will show. This value should be
slightly lower than you expect the temperature to drop to. If auto scale in the Y
axis is selected this value is not used. Use the '
the required value.
These values are used exclusively in conjunction with a standard 4-0 mA input
which can represent pressure, humidity, level, flow rate, or any other variable
which can produce a 4-0 mA output.
The value for the upper and lower limits can therefore represent % (RH), PPM,
bar or psi etc., depending on the medium being measured. A numerical
value for 4 mA (lower limit) and 0 mA (higher limit) is entered, and the m
automatically scales the input for a figure proportional to the measurement.
Use the '
Finally, press '
To setup the pulsed input, from the Point Setup menu select 'PLS' in the Point
Type field. All the remaining fields in 'Screen 1' of the Point Setup are the same
as normal.
In 'Screen ' of the Point Setup there are a couple of extra fields added. These
are as explained below:
This field is to set either the 'Constant' or 'Peak' value to be used as explained
previously.
This field is to set the amount of pulses that is to be recieved from the power
meter per kWh.
Manual RS.8A.N5.0 © Danfoss 10-007
' or ' ' keys to cycle through the character list to the required value
'and ' ' keys to cycle through the valid options as follows:
RESISTOR Resistor input.
CURRENT 4 - 0 mA input.
DIGITAL Normally open or normally closed contacts (Contact).
PT1000 PT1000
' or ' ' keys to cycle through the character list to the required value
' , ' ' , ' ' or '' ' keys to enter the required value.
' , ' ' , ' ' and ' ' keys to enter the required value.
' to return to the Setup Menu.
' , ' ' , ' ' or '' ' keys to enter
19
