Setting the Log Action

Setting the Graph Action

Point Setup (Screen 2)

Input Source

Remote Addr

18
Log printouts are available for selected points on a timed or demand basis
via the print menu. When a log is printed only points with the log action field
appropriately set will be output. The available settings are:
Off
Timed
Manual
On
Repeatedly press '↵' to cycle through the fields until the Log field is highlighted.
Use the '
cursor onto the next field.
Graph printouts are available for selected points on a timed or demand basis via
the print menu. When a graph is printed only points with the graph action field
appropriately set will be output. The available settings are:
Off
Timed
Manual
On
Repeatedly press '↵' to cycle through the fields until the Graph field is
highlighted. Use the '
With the Graph field highlighted, press and hold down the '↵' key until the
second Point Setup screen is displayed or press the ' ' in the point type field.
The point number and name are the same as those described in first Point Setup
screen and cannot be edited here.
Use this field to specify whether the input is connected directly to the m
master unit (Local), via a m+ or third party controller (T-Party) or (Remote) via
a EKC controller (Echelon). The input source can be set by pressing the '
' keys to the required option. By default the first 16 points are programmed
to use the 16 local inputs. This configuration is not fixed and may be changed.
Press the '↵' key to move onto the next field.
If 'T-Party' has been specified for the Input Source, then this field is used to
specify the remote address (refer to relavent controller manual or the m
Instructions RI.8B.M for the m+ units). If 'Echelon' has been specified for the
Input Source, then this field is not accessible as it is set from the EKC controller.
Manual RS.8A.N5.0 © Danfoss 10-007
Set this point to OFF if you do not want this point to be
shown on any log printouts.
The point will be automatically logged after a specified
time delay.
The point will be logged on demand only.
Set this option to ON if you require this point to be
shown on the timed log printouts and also on log on
demand printouts.
' or ' ' keys to set the required log action and press '↵' to move the
Set this option to OFF if you do not want this point
graph to be shown on any graph printouts.
The graph for this point will be automatically printed
after a the time specified in the Log/Graph Setup screen.
The graph for the point will be printed on demand
only.
Set this option to ON if you require a graph for this
point to be printed after the time specified in the Log/Graph
Setup screen and also on 'graph on demand' printouts.
' or ' ' keys to set the required graph action.
' or '
