EventBAR 100IR
Description of the device
Features
The
EventBAR 100IR
is a LED bar from Showtec. It is a very versatile and inexpensive batten effect for all
sorts of locations and applications.
• LEDs: 240 RGB high intensity 10mm LEDs (Red 96, Green 72, Blue 72)
• Beam angle: 30 º
• Compact and lightweight
• Long battery life
• Built-in battery charger and protection
• 8 sections
• Output: Red: 110 Lux@2m
Green: 234 Lux@2m
Blue: 250 Lux@2m
Full On: 490 Lux@2m
• Colormixing: RGB
• Colour range: 16,7 million additive colors
• Power Supply: 100-240V AC, 50/60Hz
• Control Mode: DMX512
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Consumption Power: 42 Watt
• 3 pin female XLR socket and 3 pin male XLR socket
• IEC Power In
• Linkable via 3-pin XLR cable
• Built-in microphone
• Power coated aluminum and steel
• LED display
• Fuse: T1AL / 250V
• Cooling: convection
• IP rating: IP-20
• Built-in programs mode, Auto running mode, DMX mode, slave mode, static color mode and sound-
activated mode.
• DMX controlled
• Selectable 2, 3, 5, 7 and 24 DMX channel operation
• Dimensions: 1070 x 70 x 135 mm (LXWXH) (incl. brackets)
• Weight: 3,38 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
44002
UR-5 Universal IR Remote
Ordercode: 44100
8
