Coding Transmitters; Setting Transmitters Codes; To Erase Programmed Codes - Automatic Technology DOMINATOR EasyRoller Instruction Manual

6.10 Coding Transmitters

6.10.1 Setting Transmitters Codes

The opener can only operated from remote control transmitters that
have been programmed into its memory. Up to 64 codes can be stored
in the memory.
a. Press and hold the DOOR CODE button
b. Press Button 1 on the transmitter for two seconds. Release and
pause for two seconds. Press the Button 1 again for two seconds.
c. Release the DOOR CODE button. The transmitter button is now
coded, press to test.
Function DOOR CODE
Button presses
Vacation Mode
Enable AUX Output
PET (pedestrian) Mode
Courtesy Light Press & hold LIGHT CODE and code as per 6.6.1.

6.10.2 To Erase Programmed Codes

If the DOOR CODE button is pressed and held on for 6 seconds, the LED will
blink rapidly for one second to indicate that all programmed codes have been
erased (Fig 6.10.2).
WARNING! The manufacturer is not responsible for any radio
or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's
authority to operate the equipment.
AVERTISSEMENT! Le fabricant n'est pas responsable des
éventuelles interférences avec la réception de la radio ou de
la TV due à une modification de cet équipement effectuée
sans autorisation. De telles modifications peuvent invalider
le droit à utiliser l'équipement.
18
Dominator EasyRoller Instruction Manual
(Fig 6.10.1).
twice (2) Opener will beep 2 times on second press
three (3) Opener will beep 3 times on third press
four (4) Opener will beep 4 times on the fourth press
Select one of the four
OPENER
buttons that you wish
to use to control the
door
Press DOOR CODE
button once
Fig.6.10.1
Fig.6.10.2
