INTRODUCTION
1.1

Description

1.1.1

Controls and Indicators

The controls and indicators associated with the MDM25 hygrometer are located on the
front panel.
The probe connection to the MDM25 hygrometer is made to the top panel, and the
battery charger cover is located on the rear of the instrument.
Figure 1 shows the layout of the controls.
2
1
2
3
4
1 Display
2 Left and Exit Key
3 Enter Key
4 Down Key
5 Up Key
6 Power Key
Controls and Indicators
Figure 1
