Mounting and Connecting the Probe

All probes insert directly into the connector on the top of the MDM25.
Align the locating peg with the locating notch and then rotate the knurled thumb wheel
until the probe is securely held in place.
Michell Instruments
Figure 4
WARNING: Do not over-tighten as this could cause damage
Locating Peg
Locating Notch
Probe Connections
to the probe body.
