  • Page 1 BEETLE /XS Operator Manual 01750332149A...
  • Page 2 This document and the information contained herein are provided AS IS AND WITHOUT WAR- RANTY. In no event shall Diebold Nixdorf or its suppliers be liable for any special, indirect, or consequential damages of any nature resulting from the use of information in this manual. The in- formation contained in this document is subject to change without notice.
  • Page 3: Table Of Contents

    Battery change ........................ 12-1 M.2 Module ........................13-1 System maintenance ...................... 14-1 Technical Data......................... 15-1 15.1 Interfaces .......................... 15-1 15.2 Total Current Consumption Interfaces ................15-2 15.3 Max. peripheral equipment current consumption.............. 15-2 15.4 Power supply ........................15-3 Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 4 Table of contents Manufacturer´s Certification ..................16-1 Recycling ......................... 17-1 Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 5: Introduction

    1 Introduction The BEETLE /XS is the ideal system platform for customers who desire maximum system availability and lowest operating costs. The fanless and closed system design and the use of innovative M.2 memory technology ensures maximum reliability. The dust-tight, closed housing protects the interior of the system against soiling and foreign objects.
  • Page 6: Section-Specific Warning Notes

    This warning note describes a hazard with a low degree of risk which, if not avoided, could result in slight or minor bodily injury. NOTE This note provides application tips and information that help prevent errors and material damage. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 7: Delivery Package

    • function defects, please inform your contract partner or your Diebold Nixdorf sales outlet immediately. Please specify the delivery note number, the delivery note item number and the serial number of the affected device when doing so.
  • Page 8: Esd

    Place all sub-assemblies with ESD on a suitable anti-static base. • Touch sub-assemblies with ESD only at their edges and do not touch any components. • Do not touch any connector pins or conductor paths on an electrostatic-discharge-sensitive assem- bly. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 9: Disengaging Cables

    Pull all data communications cables out of the plug connections of the data networks. • Disengage all cables at the devices. The Mini-DIN plugs (with Diebold Nixdorf key- boards) are equipped with a locking mechanism against unintended disengagement. To disengage this plug, pull the plastic sleeve away from the socket.
  • Page 10 Disengaging cables The electrically supplied USB plug is disengaged by pressing on the spring marked with the arrow. Interface connector (COM/DVI/VGA) with knurled screw can be disengaged by hand. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 11 Disengaging cables To loosen a RJ45 plug, press the tab above the plug (see arrow) downwards. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 12: Front View

    USB peripherals can be connected to these connections (USB-A), e.g. scanners, scales or magnetic card readers. CAUTION Only devices and cables that are in accordance with the valid USB specifications are per- mitted to be connected to the USB interfaces. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 13: Inside View

    7 Inside view Figure 7-1: Inside view PoweredUSB Hub Motherboard DC/DC converter Battery Cooling element Cooling element/processor M.2 SATA Front USB 2.0 Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 14: Back Panel

    Connect for example a scale with dedicated power supply to the . COM1-COM2 are designed as 9-pin D-sub plugs. If you connect scales to the device which are not supplied by Diebold Nixdorf, then you must acquire a license for the driver software!
  • Page 15 The function (RMT) makes it possible for you to switch on the BEETLE system which is currently in Standby or Hibernation mode. It is also possible to move the system from switched-on status into Standby or Hibernation mode. The settings in the operating system determine which mode is active thereby. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 16: Mm Jack Bush (In/Out/Microphone)

    Various USB peripherals can be connected to these connections (USB-A), e.g. not only scanners, scales or mice, but also dongles or even graphic cards or monitors. USB can provide the required power for de- vices with little wattage such as phones or keyboards. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 17: Rj45 (Lan)

    Right LED 10 MBit Constant green 100 MBit Constant orange 1000 MBit NOTE Only use shielded LAN cables with the markings CAT5, CAT5e or CAT6. They provide a higher protection against disturbances in the network. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 18: Setting Up The Device

    Even if you want to install the device or mount it vertically, it is mandatory that you adhere to the mini- mum distances listed in the illustration. Figure 9-1: Distances for free convection Ensure constant aeration and ventilation. The direct ambient temperature of the system must not exceed 40°C (104°F). Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 19: Wall Mounting

    Setting up the device Wall mounting 9.2.1 9.2.1 Wall holders The Kit BEETLE /XS-Wandhalterung (01750330877) contains two angle bracket_XS (01750310537) and 4 screws: Figure 9-2: Wall holders with 4 screws 9.2.1.1 9.2.1.1 Dimensions Figure 9-3: Dimensions of wall holders Copyright 2019 Diebold Nixdorf...
  • Page 20 Setting up the device 9.2.2 9.2.2 Dimensions Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 21: Installation

    Due to variations in walls/ceilings, it is necessary to check the compatibility of the screws, wall plugs, and the wall/ceiling material, including the substructure, at the construction site. The wall/ceiling and the mounting material used must be able to support a weight of at least 8 kg. Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 22: Wall Holders Mounted

    Setting up the device 9.2.4 9.2.4 Wall holders mounted Figure 9-4: Wall holder mounted Copyright 2019 Diebold Nixdorf 01750332149A...
  • Page 23 Copyright 2019 Diebold Nixdorf 10-1 01750332149A...
  • Page 24: Removing The Housing Cover

    Loosen the two knurled screws by rotating them to the left. Figure 11-1: Loosening knurled screws. Pull the housing cover a bit towards yourself and remove it in an upwards direction. Figure 11-2: Removing the cover Mount the housing cover following the steps in reverse order. Copyright 2019 Diebold Nixdorf 11-1 01750332149A...
  • Page 25: Battery Change

    Switch the device off and pull the power plug. Remove the housing cover. Press it against the latching mechanism until the battery is released. Figure 12-1: Battery change Insert the new battery (Type BR2032). Reassemble the device following the steps in reverse order. Copyright 2019 Diebold Nixdorf 12-1 01750332149A...
  • Page 26: Module

    Switch the device off and pull the power plug. Remove the housing cover. Remove screw with which the M.2 module is fastened. Figure 13-1: M2_Module Pull out the module and replace it. Assemble in reverse order and close the payout unit. Copyright 2019 Diebold Nixdorf 13-1 01750332149A...
  • Page 27: System Maintenance

    10 are not recommended. Cleaning with water and isopropyl alcohol is possible as well. Do not use solvents containing acetic acid. The items listed below can be ordered from the local branch of Diebold Nixdorf or from your Diebold Nixdorf sales partner.
  • Page 28: Technical Data

    O1: Max. 3 displays for simultaneous connection In, Out, Mic Ports for microphone, headset, loudspeaker PS/2 1 (keyboard and mouse via Y-cable) RJ 12 Cash Drawer RJ45/LAN 10/100/1000 Mbit/s Serial ATA 1 x SATA III KeyM 2280, 1 x SATA Copyright 2019 Diebold Nixdorf 15-1 01750332149A...
  • Page 29: Total Current Consumption Interfaces

    The 24 V PoweredUSB interface is provided for the operation of retail thermal printers. The peak load is configured accordingly. 15.3 15.3 Max. peripheral equipment current consumption PUSB/USB/COM* 24 V 3 A 12 V 3 A The maximum power consumption for all peripherals must not exceed 100 W. Copyright 2019 Diebold Nixdorf 15-2 01750332149A...
  • Page 30: Power Supply

    Technical Data 15.4 15.4 Power supply Only use power supply units (PSU) released or approved by Diebold Nixdorf. The power supply unit must comply with the following minimal requirements and common standards: Rated input voltage 100 – 240 VAC Rated input current 2.0 A...
  • Page 31: Manufacturer´s Certification

    This class A digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe A est conforme à la norme NMB-003 du Canada. (2) this device must accept any interference received, including interference that may cause undesired operation Copyright 2019 Diebold Nixdorf 16-1 01750332149A...
  • Page 32 You are helping us with the recycling if you do not attach any labels to the device. For materials which currently cannot be used for a new purpose, Diebold Nixdorf offers environmentally friendly disposal at a recycling center that is certified in accordance with ISO 9001 and ISO 14001.
