BEETLE /iPOS plus SL
User Manual (Edition September 2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEETLE /iPOS plus SL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DIEBOLD NIXDORF BEETLE /iPOS plus SL

Summary of Contents for DIEBOLD NIXDORF BEETLE /iPOS plus SL

  • Page 1 BEETLE /iPOS plus SL User Manual (Edition September 2018)
  • Page 2 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards, Your opinion: Diebold Nixdorf Pte Ltd 151 Lorong Chuan New Tech Park #05-01A/B Singapore 556741 Order No.: 01750307048 B...
  • Page 3 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Diebold Nixdorf The reproduction, transmission or use of this document or its contents is not permitted without express authority. Offenders will be liable for damages.

  • Page 4: Table Of Contents

    Safety Notes ..................7 Supplier’s Declaration of Conformity ..........9 Introduction ................. 10 About this manual ................10 Care of the BEETLE /iPOS plus SL ............. 10 Recycling the BEETLE /iPOS plus SL ..........11 Warranty ..................12 Lithium Battery ................13 Unpacking And Checking the Delivery Unit........
  • Page 5 Planning the installation .............. 23 Dimensions ..................23 Desktop version ................23 Desktop Stand Standard .............. 23 Desktop Stand Enhanced............. 24 Wall mount version ................25 Required operation space ..............25 Installation site requirements ............26 Desktop version ................26 Wall mount version ..............
  • Page 6 Barcode Reader ................59 How to operate................59 Installation ................... 59 Starting Up the System ..............63 Error reporting ................64 POST Code ..................65 Technical Data ................66 AC Power Adapter ................67 NFC Module ..................68 I/O Hub ..................... 69 Appendix ..................

  • Page 7: Manufacturer´s Certification

    RoHS directive 2011/65/EU. Therefore, you will find the CE mark on the device or packaging. In addition, the BEETLE /iPOS plus SL has received the UL symbol and cUL symbol. FCC-Class B Declaration This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 8: Energy Efficiency

    Manufacturer´s Certification Energy Efficiency BEETLE /iPOS plus SL is tested in an accredited test lab and can meet the Eligibility Criteria for Integrated Desktop laid down in ENERGY STAR version 6.0 for Computers. On a request basis, an application can be made to Energy Star for listing.
  • Page 9 Svenska [Swedish]: Diebold Härmed intygar Nixdorf att denna enhet står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 2014/53 /EG. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 10: Contents

    L’exploitation est autorisée aux deux conditions suivantes : 1.L’appareil ne doit pas produire de brouillage; 2.L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 11: Radio Frequency (Rf) Exposure Information

    Ce périphérique a également étéévalué et démontré conforme aux limites d'exposition aux RF d'IC dans des conditions d'exposition à des appareils mobiles(antennes sont supérieures à 20 cm à partir du corps d'une personne). 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 12: Important Notes

    Manufacturer´s Certification Important Notes Diebold Nixdorf is not responsible for any radio and television malfunctions which emerge from unauthorized changes in the device. Make sure that only cables and devices may be connected which are admitted by Diebold Nixdorf. The user is responsible for any malfunctions that emerge from the actions mentioned before.

  • Page 13: Safety Notes

    Manufacturer´s Certification Safety Notes The BEETLE /iPOS plus SL conforms to the current safety standards for data processing equipment.  If this device is taken from a cold environment into the operating room, moisture condensation may form. The device must be absolutely dry before being put into service;...
  • Page 14 Manufacturer´s Certification  Your BEETLE /iPOS plus SL system is the result of modern technical innovation. So please see for according structural and technical surroundings to guarantee a faultless and efficient work of your BEETLE /iPOS plus SL. Therefore, you should connect your...

  • Page 15: Supplier's Declaration Of Conformity

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 16: Introduction

    Introduction Introduction The Beetle /iPOS plus SL is a new generation of the Beetle /iPOS plus family of all-in-one to meet the demands for slim-look and bezel with narrower borders. It features the new Apollo Lake SOC along with other newer technologies such as USB Type C.

  • Page 17: Recycling The Beetle /Ipos Plus Sl

    “Environmental conscious product design and development”. The BEETLE /iPOS plus SL system is manufactured without the use of CFC and CHC and is produced mainly from reusable components and materials. Please do not stick labels onto plastic case parts. This would help us to reuse components and material.

  • Page 18: Warranty

    All parts of the product which are subject to wear and tear are not included in the warranty engagement. For detailed warranty arrangements please consult your contract documents. Please order spare parts at the Diebold Nixdorf customer service. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 19: Lithium Battery

    Diebold Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock). 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 20: Basic Settings

    Basic settings Basic settings The BEETLE /iPOS plus SL is configured to your order. Add-on peripheral devices are delivered separately, for example the magnetic swipe card reader. The modules are to be mounted to the system. Components The BEETLE /iPOS plus SL configuration can consist of the following components:...

  • Page 21: Setting Up The Device

    (desktop version), or on the wall (wall mount version) or on a pole. Set up the BEETLE /iPOS plus SL system where it will not be exposed to extreme environmental conditions. Protect the device from vibrations, dust, moisture, heat and strong magnetic fields.
  • Page 22 Permitted range of vision Position the screen within a 0° preferred and permit ted range 40° of vision, so that you can look onto the screen from above. 30° 30° Preferred range of vision 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 23: Overview

    Overview Overview Front View with Stand BEETLE /iPOS plus SL Desktop Stand Touch buttons and Activities Indicator Power status indicator 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 24: Back View With Stand

    Overview Back View with Stand Side-attach peripheral connection cover VESA mount cover Hinge cover Base cover of stand Cable connection cover Side-attach peripheral connection cover 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 25: Ac Power Adapter

    Overview AC Power Adapter AC Power Cord DC Power Out Power Indicator The external power supply is applicable for common line voltage. It automatically adjusts itself to the particular voltage. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 26: Front Panel

    - Power Status Indicator - Power Button • LED White Off : Off/AC • Single Press : On/Off not applied • LED White Dim: Off/AC applied • LED White Blinking: Suspend to RAM 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 27: Projected Capacitive Touch Screen

    With a circular motion of the fingers the element on the display can be rotated. This function must be supported by either the operating system or by the application. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 28: Cleaning Instructions

    Use a soft, fine-meshed cloth to clean the surface. Dampen the cloth slightly and then clean the screen. A wrong maintenance may cause damages to the screen, which are not covered by warranty. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 29: Planning The Installation

    Please refer to the drawings below for dimensions of the desktop and wall mount versions. All dimensions are specified in millimetres. The views of the systems are not drawn to scale. Desktop version Desktop Stand Standard 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 30: Desktop Stand Enhanced

    Planning the installation Desktop Stand Enhanced  For more information about the Desktop Stand, its different versions and features, and its installation method, please refer to the ‘Desktop Stand Installation Manual’ (01750293377). 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 31: Wall Mount Version

    Planning the installation Wall mount version Required operation space Maintain at least 50 mm from the side of the system to ensure proper ventilation during the operation of the system. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 32: Installation Site Requirements

     The system must be mounted to a solid concrete or brick wall with flat smooth surface. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 33: Lnstalling To A Stand

    Torx screwdriver to loosen and tighten the Torx screws. Preparing the display Loosen the 4 Torx screws halfway out. Remove the cable connection cover at the bottom of the display. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 34: Preparing The Stand

    Preparing the stand The stand as seen. Remove the hinge cover from its bottom. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 35 Remove the VESA mount cover from its bottom. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 36: Installing Display To The Stand

    Fit the display to the stand: by hooking the display with the 4 loosened Torx screws onto the 4 U-shaped grooves found on the frame of the stand (1). Then, tighten the screws. Stick on the cable clamps and route cables through these clamps (2). 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 37 Re-attach the hinge cover. And re-attach the VESA mount cover. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 38: Installing The I/O Hub (Option)

    Next, remove the bottom housing by pressing onto its 2 latches as indicated by the arrows With the housing loose, slide it away from the base of the stand in the direction of the arrows. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 39 And, now you can tighten the 2 screws on either side of the I/O Hub (see previous figure for indication of the screws). 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 40 The cable loop of this cable connection to the I/O Hub should be 40 mm long. The I/O Hub is installed as seen. Next, route the cables from the I/O Hub through the cable holder as seen. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 41 And connect the cables to USB6 port (1) and 24VIN port (2) of the connector panel located under the display. Re- attach the cable connection cover over the connector panel. Re-attach the bottom housing. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 42 Installing the I/O Hub (option) Re-attach the hinge cover. And re-attach the VESA mount cover. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 43: Connector Panel

    RJ12 (Cash drawer) USB7 USB 2.0 (Type A) Make sure that all additional devices have a CE certificate. Please note that MAX 70W load is allowed for any combination of the interface connectors. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 44: Connecting Cables

    Connector panel Connecting cables All devices belonging to the modular BEETLE /iPOS plus SL that have a separate power cable must be connected to the same electric circuit. Connect the system as described below. Tilt the display to the back, and...

  • Page 45: Disconnecting Cables

    The metal of the plug is visible. To release a RJ12 plug push the latch under the plug to the top. You loosen the USB-A- connector by pushing the covering of the connector. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 46 Manually loosen the knurled screws of the COM or DVI interface connector. To release a RJ45 plug push down the latch (see arrow). 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 47: Storage Media

    First ensure that the device is switched off and the power connector is disconnected. Tilt the display to the back, and remove the cable connection cover to uncover the connector panel. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 48 Remove the display from the stand, and lay it on a flat surface. Remove the screw as illustrated. Then remove the SSD/RAM cover. The SSD is now exposed. Remove the screw on the SSD. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 49 SSD screw previously removed. To close back the RAM cover, place the RAM cover onto the opening before tightening the RAM cover screw. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 50: Replacement Of The Ram

    (illustrated with arrows). The RAM is now unhooked and can be removed and replaced. When fitting in the new RAM, push it downwards until it latches on and a “click” sound is heard. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 51: Lnstalling System To A Wall

    Drill Diameter: 6 mm Min Hole Depth: 60 mm Load per anchor for concrete: 60 kg (Safety factor accounted for) Load per anchor for Solid brick: 30 kg (Safety factor accounted for) 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 52 Recommended Screw for wall is Pan head Wood Screw TGS-C3- 4.8 x 38L Drill Diameter: 6 mm Min Hole Depth: 40 mm Load per anchor for concrete: 40 kg Load per anchor for Solid brick: 30 kg Safety factor: 6 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 53: Mounting Height

    Mounting location Once you have determine the mounting height, with the help of the wall mount back plate, mark the location of the four holes on the wall. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 54: Installation

    After installation, ensure that the screw heads are flushed or below the outer surface of the wall mount back plate. Ensure that the wall mount back plate is firmly and securely attached to the wall. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 55: Fix Wall Mount Front Plate To The System

    Align the 4 mounting holes of the wall mount front plate onto the mounting holes at the back of the display. Secure the wall mount front plate onto the display using the M4 screws provided in the wall mount kit. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 56: Secure The System To The Wall

    Tighten the thumb screw on the top of the wall mount front plate to secure the hooks of the wall mount plates. Dress the cables routing according to the store set up or the overall installation site plan. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 57: Peripherals (Optional)

    USB interface. The readout of the data may be integrated easily in a software application. For guide on software application programming, please refer to BA9x MSR/Waiter Lock Programming Manual. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 58: Installation

    Peripherals Installation The Waiter Lock kit as seen. Containing the Waiter Lock module and two M3x4 screws. Remove the Waiter Lock cover on the other side. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 59 BEETLE /iPOS plus SL. The cover now removed as seen. Insert the Waiter Lock module into the now exposed USB port of the BEETLE /iPOS plus SL. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 60 Now you can attach back the Side-attach peripheral connection cover. The Waiter Lock is now installed. The front view of the BEETLE /iPOS plus SL with the Waiter Lock as seen. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 61: Magnetic Swipe Card Reader (Msr)

    In order to guarantee good reading results, the swipe card reader should be cleaned from time to time. This is carried out by using a special cleaning card that can be purchased from Diebold Nixdorf. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 62: Installation

    Peripherals Installation The MSR kit as seen. Containing the MSR module and two M3x4 screws. Remove the cover of the MSR module found on the other side. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 63 Peripherals Remove either Side-attach peripheral connection cover of the BEETLE /iPOS plus SL. Insert the MSR module into the now exposed USB port of the BEETLE /iPOS plus SL. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 64 M3x4 screws. Now you can attach back the Side-attach peripheral connec- tion cover. The MSR is now installed. The front view of the BEETLE /iPOS plus SL with the MSR as seen. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 65: Barcode Reader

    Installation The Barcode Reader kit as seen. Containing the Barcode Reader module and two M3x4 screws. Remove the cover on the Barcode Reader module as illustrated. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 66 Peripherals Remove either Side-attach peripheral connection cover of the BEETLE /iPOS plus SL. Insert the Barcode Reader module into the now exposed USB port of the BEETLE /iPOS plus SL. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 67 Peripherals Then put on and tighten two M3x4 screws. Attach back the cover on the Barcode Reader module. 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 68 Peripherals The front view of the BEETLE /iPOS plus SL with the Barcode Reader as seen. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 69: Starting Up The System

    Starting up the system Starting Up the System After installing the BEETLE /iPOS plus SL, switch on the system by using the Power button on the front panel. The system first performs an automatic self-test to test its basic functions.

  • Page 70: Error Reporting

    LED. Decode by counting the number of blinks in a train and check against the error code table below. Number of pulses Error description M.2 SSD failed Processor Hot Capacitive Sense board is faulty PCH Hot 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 71: Post Code

    POST code will be emitted in a sequence of 8 long/short blinks of the amber LED at the front panel. A long blink represents logic ‘1’ and a short blink logic ‘0’. Record the 8 bits code. 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 72: Technical Data

    Viewing Angle 80/89° User Accessible I/O PLINK2/DVI-D, 2x USB 2.0, 2x USB 3.0, 1x 24V Powered USB, 1x 24V DC Input, Cash drawer, LAN, USB-C (Q170 version only) PD: 5V/3A, 12V/3A 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 73: Ac Power Adapter

    24V ± 5% Rated output current 5.0A Max. output power 120W at ambient of 45 degree C, 100W at ambient of 55 degree C Approvals and Certification UL Listed, TÜV-GS, CE 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 74: Nfc Module

    5 ºC to 40 ºC Device Firmware Upgrade Middleware support Operating Systems Windows 7, Linux Certification EN 50364 Height x Width x Depth 16mm x 40mm x 4.15mm (module only) Weight 1.8g (module only) 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 75: I/O Hub

    Appendix I/O Hub The I/O Hub (illustration on next page) is an accessory for the BEETLE /iPOS plus SL, to extend the number of I/O ports. Power input DC24V IN 24V DC (connect to 24V power supply) User interface COM5...
  • Page 76 Appendix 01750307048 B BEETLE /iPOS plus SL – User Manual...

  • Page 77: Appendix

    Appendix Appendix Approved Printers List The following are the approved printers that are allowed to be connected to the BEETLE /iPOS plus SL+24Vdc Powered USB port: Model Manufacturer TH200i series Diebold Nixdorf TH210 series Diebold Nixdorf TH230 series Diebold Nixdorf...

  • Page 78: Abbreviations

    Light Emitting Diode Protective Earth Neutral Conductor Random Access Memory Solid State Disk (flash medium) TN-S Terre Neutre- Separé Underwriters Laboratory (standards) Universal Serial Bus Video Graphics Adapter VESA Video Electronics Standards Association 01750307048 B BEETLE /iPOS plus SL – User Manual...
  • Page 79 Diebold Nixdorf Pte Ltd 151 Lorong Chuan New Tech Park #05-01A/B Singapore 556741 Order No.: 01750307048 B...
