  • Page 1 HD-120 e-drum module user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 09.04.2019, ID: 461227...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 9 Safety instructions..........................11 Features............................... 15 Installation..............................16 Connections and controls........................18 Operating..............................23 6.1 Functions............................. 23 6.2 Selecting drum kits.......................... 24 6.3 Playing the drum kit........................
  • Page 4 Table of contents Technical specifications........................34 Plug and connection assignment....................36 Cleaning............................... 38 Protecting the environment......................39 e-drum module...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. HD-120...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...
  • Page 8 General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Cross-references References to other locations in this manual are identified by an arrow and the specified page number.

  • Page 9: Symbols And Signal Words

    General information 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
  • Page 10 General information Warning signs Type of danger Warning – danger zone. e-drum module...

  • Page 11: Safety Instructions

    Safety instructions Safety instructions Intended use Drum modules are intended to be used for converting digital trigger signals from drum pads to various percussion sounds. Use the unit only as described in this manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 12 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
  • Page 13 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
  • Page 14 Safety instructions NOTICE! External power supply The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual cur‐ rent circuit breaker.

  • Page 15: Features

    Features Features Space-saving, complete e-drum set for beginners 12 preprogrammed drum kits Metronome Connections for headphones, AUX, USB and MIDI including drum track, cabling, sticks, stick holders, headphones and seat HD-120...

  • Page 16: Installation

    Installation Installation Setup, connecting pads and Setup and assembly of the pads and pedals are described in detail in the enclosed assembly pedals guide. Finally check that all cables between the pads and the e-drum module have been prop‐ erly connected. Connecting the power adapter Connect the included power adapter to the 9V input of the e-drum module.
  • Page 17 Installation Connecting USB devices Connect external MIDI devices or your computer to the USB port of the drum module. HD-120...

  • Page 18: Connections And Controls

    Connections and controls Connections and controls Front panel e-drum module...
  • Page 19 Connections and controls Display [DC 9V] Connection socket for the power adapter Selects an option or sets a value. Turns the metronome on and off. Selects an option or sets a value. [VOLUME] Volume control. Controls the volume of the drum kits. Pressing turns the device on.
  • Page 20 Connections and controls [OUTPUT] Line output for external audio devices, designed as 3.5 mm jack socket Headphones output, designed as 3.5 mm stereo jack socket. [AUX] Input for external audio devices like MP3 or CD players, designed as 3.5 mm stereo jack socket. [USB] USB MIDI port, designed as USB-B socket e-drum module...
  • Page 21 Connections and controls Rear panel HD-120...
  • Page 22 Connections and controls Holder for attaching the drum module to the drum set Connection socket for connecting cable to the drum set, designed as 25-pin D-sub connector socket e-drum module...

  • Page 23: Operating

    Operating Operating 6.1 Functions Turning on / off Check all cable connections for correct fit before turning on Before switching on, turn the [VOLUME] control to minimum. Press to turn on the drum module. Press and hold to turn off the drum module. Adjusting the volume To adjust the volume, hit a pad and at the same time adjust the volume of the drum module with the [VOLUME] control.

  • Page 24: Selecting Drum Kits

    Operating Reset to factory defaults To reset the drum module to factory settings, turn it off first. Then press and hold simultaneously. The display shows ‘CLr’ . The drum module is reset to factory default settings. 6.2 Selecting drum kits A drum kit is a compilation in which a certain sound (Voice) and several sound parameters are assigned to each pad.
  • Page 25 Operating Selecting a drum kit To select a certain drum kit, proceed as follows: Press to select the desired drum kit. ð The current kit name and kit number are displayed. The following drum sets are available: Number Drum kit Number Drum kit Rock Kit...

  • Page 26: Playing The Drum Kit

    Operating 6.3 Playing the drum kit Like on an acoustic drum kit, the pads respond to different playing techniques and dynamics. All pads are velocity sensitive. Some voices change their timbre depending on the punch used. Bass Drum – Change the sound of the bass drum by striking the pedal with different strength and speed.

  • Page 27: Metronome Function

    Operating Hi-hat Change the sound of the hi-hat by combining pedal and stroke techniques in different ways. – Strike the Hi-hat pad without pressing the pedal. – Strike the Hi-hat pad with fully pressed pedal. – Step on the hi-hat pedal without hitting the hi-hat pad. –...
  • Page 28 Operating To turn off the metronome, press again e-drum module...

  • Page 29: Adjusting The Pedals

    Operating 6.5 Adjusting the pedals Temperature fluctuations or humidity can alter the sensitivity of the pedals. To reset the sensi‐ tivity of the pedals to factory defaults: While the drum set is switched off, simultaneously press and hold ð The display shows ‘bdF’ . Step on the bass drum pedal and hold the pedal in this position.

  • Page 30: Midi Implementation

    Operating 6.6 MIDI implementation Connect the drum module to a synthesizer or PC via the USB-MIDI interface to use the MIDI function. Function Transmitted Recognized Remarks Basic channel Default 1-8, 10-16 Changed Mode Default Mode 3 Messages Altered ******** ******** Note number 0…127 0…127...
  • Page 31 Operating Function Transmitted Recognized Remarks Aftertouch Keys Channels Pitch bend Control change Bank select Modulation Foot control Portamento time Data entry Volume Expression Sustain pedal Portamento ON/OFF HD-120...
  • Page 32 Operating Function Transmitted Recognized Remarks Sostenuto pedal Soft pedal Resonance Release time Attack Time Cut off Reverb program Chorus program Reverb level Chorus level All Sound Off Reset All Controllers All Notes Off e-drum module...
  • Page 33 Operating Function Transmitted Recognized Remarks Program change System exclusive System common Song Position Song Select Tune System real time Clock Command Aux messages Local ON/OFF All Notes OFF Active Sense Reset Mode 1: Omni on, poly. Mode 2: Omni on, mono. Mode 3: Omni off, poly. Mode 4: Omni off, mono.

  • Page 34: Technical Specifications

    Technical specifications Technical specifications Input connections Voltage supply Connector socket for plug-in power supply AUX in 1 × 3.5 mm stereo phone socket Signal transmission drum set 1 × D-sub connector socket, 25-pin Output connections Line out 1 × 3.5 mm jack socket Headphones 1 ×...
  • Page 35 Technical specifications Ambient conditions Temperature range 0 °C…40 °C Relative humidity 50 %, non-condensing Further information Rack included Seat included Bass drum pedal included Headphones included Mesh Head Pads Stereo pads Number of direct outputs HD-120...

  • Page 36: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 37 Plug and connection assignment Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding...

  • Page 38: Cleaning

    Cleaning Cleaning Device components Clean the externally accessible device parts regularly. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the device parts. Clean with a soft dry cloth. Stubborn dirt can be removed with a slightly dampened cloth.

  • Page 39: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 40 Notes e-drum module...
  • Page 41 Notes HD-120...
  • Page 42 Notes e-drum module...
