- Page 1 ED3501 Industrial Ethernet Extender FastFind Links Introduction User’s Guide Unpacking and Installation...
- Page 2 Disclaimer of Liability The information contained in this document is subject to change without notice. EtherWAN is not liable for any errors or omissions contained herein or for resulting damage in connection with the information provided in this manual.
-
Page 3: Preface
This section provides a history of the revision changes to this document. Revision Document Version Date Description Version 1 08/06/2015 Initial release Changes in this Revision N/A - this is first version of this document. ED3501 Industrial Ethernet Extender User Guide... -
Page 4: Document Conventions
[ ] square Indicates optional values. brackets { } braces Indicates required or expected values. | vertical bar Indicates that you have a choice between two or more options or arguments. ED3501 Industrial Ethernet Extender User Guide... -
Page 5: Table Of Contents
Connecting to the 10/100 Mbps RJ-45 Port ............17 Connecting to Ethernet Extender Port ............... 17 Checking the Installation ..................17 Applying AC Power .................... 17 3 Troubleshooting....................20 Troubleshooting Chart ..................... 21 Additional Troubleshooting Suggestions ..............22 Configuration ..................... 22 ED3501 Industrial Ethernet Extender User Guide... - Page 6 Industrial Ethernet Extender Integrity ..............22 Auto-Negotiation ....................22 Technology ......................23 Power ........................23 Mechanical ......................23 Interface ........................24 Environment ......................25 Regulatory Approvals ....................25 ED3501 Industrial Ethernet Extender User Guide...
-
Page 7: Introduction
1 Introduction Topics: Congratulations on your purchase of the ED3501 Industrial Ethernet Extender from EtherWAN Systems, Inc. Your EtherWAN Key Features (page 8) Industrial Ethernet Extender is a state-of-the-art IEEE-compliant Quick Start Guide (page 9) network solution designed for users who require high-performance to eliminate bottlenecks and increase productivity. -
Page 8: Key Features
Key Features This section summarizes the key features of the ED3501 Industrial Ethernet Extender. One 10/100Base-TX Ethernet port with RJ-45 connector Auto negotiation of speed and duplex mode on Ethernet port Auto MDIX on Ethernet port Complies with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX standards ... -
Page 9: Quick Start Guide
Wait for the Industrial Ethernet Extender to complete its Power On Self Test. Confirm that the LEDs for ports connected to a device are green. If not, replace the Ethernet cable, and then check the port LED again. ED3501 Industrial Ethernet Extender User Guide... -
Page 10: Unpacking And Installation
2 Unpacking and Installation Topics: This chapter describes how to unpack and install the ED3501 Industrial Ethernet Extender. Unpacking the Hardware (page 11) Hardware Features (page 11) Installing the Industrial Ethernet Extender (page 15) ED3501 Industrial Ethernet Extender User Guide... -
Page 11: Unpacking The Hardware
Figure 2-1. Front Panel of the ED3501 Industrial Ethernet Extender 10/100 Mbps RJ-45 Port The ED3501 Industrial Ethernet Extender has one 10/100 Mbps RJ-45 port (see Figure 2-1). This port is auto-sensing, auto-MDIX 10/100 Mbps port. When you insert a cable into an RJ-45 port, the Industrial Ethernet Extender: Determines whether the cable is a straight-through or crossover cable. - Page 12 Ethernet Extender Port The ED3501 Industrial Ethernet Extender has one Ethernet Extender port (RJ-11 connector or Terminal Block, see Figure 2-1). Insert the voice grade copper wire between one pair of Ethernet Extenders via Ethernet Extender port (RJ-11 connector or Terminal Block).
- Page 13 LEDs The ED3501 front panel LEDs show power and link/activity status. Table 2-1 summarizes the LEDs on the Industrial Ethernet Extender. Ethernet Extender Connection The RJ-11 and Terminal Block port pinouts Pin 3: Tip, Pin 4: Ring. Use a telephone line to connect two RJ-11 or Terminal Block ports between two Hardened Ethernet Extenders.
-
Page 14: Rear Panel
Link speed at 10Mbps. Rear Panel The ED3501 rear panel has a receptacle for connecting the supplied external power adapter. Use only the external power adapter supplied with the Industrial Ethernet Extender. Figure 2-2. Rear Panel of the ED3501 Industrial Ethernet Extender... -
Page 15: Bottom Panels
Bottom Panels The ED3501 bottom panel has a product label that shows regulatory compliance, product serial number, and other information. Installing the Industrial Ethernet Extender Industrial Ethernet Extender installation involves the following steps: Preparing the site. See page 16 Installing the Industrial Ethernet Extender. -
Page 16: Preparing The Site
If installing the Industrial Ethernet Extender on a desktop, shelf, DIN-Rail, or wall, allow sufficient ventilation space between the device and the objects around it. ED3501 Industrial Ethernet Extender Dimensions: 80.3mm (W) x 109.2mm (D) x 23.8mm (H) (3.16” (W) x 4.3” (D) x 0.94” (H)) -
Page 17: Connecting To The 10/100 Mbps Rj-45 Port
Industrial Ethernet Extender. 2. Connect the 3-pronged end of the AC power adapter cable to a grounded 3-pronged AC outlet. When you apply power: All green Link/Activity LEDs blink momentarily. ED3501 Industrial Ethernet Extender User Guide... - Page 18 If the Power LED is not ON, check that the power adapter is plugged in correctly, and that the power source is good and not controlled by a wall switch. If this does not resolve the problem, see Chapter 3, ED3501 Industrial Ethernet Extender User Guide...
- Page 19 Troubleshooting. ED3501 Industrial Ethernet Extender User Guide...
-
Page 20: Troubleshooting
3 Troubleshooting Topics: This chapter provides information about troubleshooting the Industrial Ethernet Extender. Troubleshooting Chart (page 21) Additional Troubleshooting Suggestions (page 22) ED3501 Industrial Ethernet Extender User Guide... -
Page 21: Troubleshooting Chart
Break the loop by ensuring that there is only one path from any networked flashing continuously on path) has been created. device to any other networked device. all connected ports and the network is disabled. ED3501 Industrial Ethernet Extender User Guide... -
Page 22: Additional Troubleshooting Suggestions
If the device does not support auto-negotiation, the Industrial Ethernet Extender determines only the speed correctly and the duplex mode defaults to half-duplex. ED3501 Industrial Ethernet Extender User Guide... -
Page 23: Technology
80.3 mm (W) x 109.2 mm (D) x 23.8 mm (H) (3.16" (W) x 4.3" (D) x 0.94" (H)) Weight: 150 g (0.33 lb) Installation: DIN-Rail (Top hat type 35 mm) or Wall Mounting ED3501 Industrial Ethernet Extender User Guide... -
Page 24: Interface
Data Rate (Mbps) 2600 This distance/data rate information is measured according testing standard in EtherWAN laboratory. The actual installation will be affected by the quality of copper wire and the impact of noise disturbance. The connection speed will be affected. -
Page 25: Environment
EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) Environmental Test IEC60068-2-6 Fc (Vibration Resistance) Compliance IEC60068-2-27 Ea (Shock) FED STD 101C Method 5007.1 (Free fall w/ package) ED3501 Industrial Ethernet Extender User Guide... - Page 26 TEL: +886 -2- 6629-8986 Email: info@etherwan.com.tw EtherWAN has made a good faith effort to ensure the accuracy of the information in this document and disclaims the implied warranties of merchantability and fitness for a particular purpose, and makes no express warranties, except as may be stated in its written agreement with and for its customers.
