- Page 1 ED3541 Hardened Ethernet Extender FastFind Links Introduction User’s Guide Unpacking and Installation...
- Page 2 Disclaimer of Liability The information contained in this document is subject to change without notice. EtherWAN is not liable for any errors or omissions contained herein or for resulting damage in connection with the information provided in this manual.
-
Page 3: Preface
Document Revision Level This section provides a history of the revision changes to this document. Revision Document Version Date Description Version 2 06/16/2015 Initial release Changes in this Revision This is second version of this document. ED3541 Industrial Ethernet Extender User Guide... -
Page 4: Document Conventions
[ ] square Indicates optional values. brackets { } braces Indicates required or expected values. | vertical bar Indicates that you have a choice between two or more options or arguments. ED3541 Industrial Ethernet Extender User Guide... -
Page 5: Table Of Contents
Connecting to the 10/100 Mbps RJ-45 Port ............16 Connecting to Ethernet Extender Port ............... 16 Checking the Installation ..................16 Applying DC Power ................... 16 3 Troubleshooting....................18 Troubleshooting Chart ..................... 19 Additional Troubleshooting Suggestions ..............20 Configuration ..................... 20 ED3541 Industrial Ethernet Extender User Guide... - Page 6 Hardened Ethernet Extender Integrity ..............20 Auto-Negotiation ....................20 Technology ......................21 Power ........................21 Mechanical ......................21 Interface ........................22 Environment ......................23 Regulatory Approvals ....................23 ED3541 Industrial Ethernet Extender User Guide...
-
Page 7: Introduction
1 Introduction Topics: Congratulations on your purchase of the ED3541 Hardened Ethernet Extender from EtherWAN Systems, Inc. Your EtherWAN Key Features (page 8) Hardened Ethernet Extender is a state-of-the-art IEEE-compliant Quick Start Guide (page 9) network solution designed for users who require high-performance to eliminate bottlenecks and increase productivity. -
Page 8: Key Features
Key Features This section summarizes the key features of the ED3541 Hardened Ethernet Extender. One 10/100Base-TX Ethernet port with RJ-45 connector Auto negotiation of speed and duplex mode on Ethernet port Auto MDIX on Ethernet port Complies with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX standards ... -
Page 9: Quick Start Guide
Wait for the Hardened Ethernet Extender to complete its Power On Self Test. Confirm that the LEDs for ports connected to a device are green. If not, replace the Ethernet cable, and then check the port LED again. ED3541 Industrial Ethernet Extender User Guide... -
Page 10: Unpacking And Installation
2 Unpacking and Installation Topics: This chapter describes how to unpack and install the ED3541 Hardened Ethernet Extender. Unpacking the Hardware (page 11) Hardware Features (page 11) Installing the Hardened Ethernet Extender (page 14) ED3541 Industrial Ethernet Extender User Guide... -
Page 11: Unpacking The Hardware
One CD containing this user’s guide If any item is damaged or missing, notify your authorized EtherWAN representative. Keep the carton, including the original packing material, in case you need to store the product or return Hardware Features The following sections describe the hardware features of the ED3541 Hardened Ethernet Extender. - Page 12 10/100 Mbps RJ-45 Port The ED3541 Hardened Ethernet Extender has one 10/100 Mbps RJ-45 port (see Figure 2-1). This port is auto-sensing, auto-MDIX 10/100 Mbps port. When you insert a cable into an RJ-45 port, the Hardened Ethernet Extender: Determines whether the cable is a straight-through or crossover cable.
-
Page 13: Top Panel
Link speed at 100Mbps. Link speed at 10Mbps. Top Panel The ED3541 top panel has a Termianl Block for connecting the external power supply. Figure 2-2. Top Panel of the ED3541 Hardened Ethernet Extender Side Panels The ED3541 side panel has a product label that shows regulatory compliance, product serial number, and other information. -
Page 14: Installing The Hardened Ethernet Extender
Extender. See page 15. Connecting to the 10/100 Mbps RJ-45 Port. See page 16. Connecting to Ethernet Extender Port. See page 16. Checking the installation. See page 16. Applying DC Power. See page 16. ED3541 Industrial Ethernet Extender User Guide... -
Page 15: Preparing The Site
If installing the Hardened Ethernet Extender on a desktop, shelf, or DIN-Rail, allow sufficient ventilation space between the device and the objects around it. ED3541 Hardened Ethernet Extender Dimensions: 42mm (W) x 90mm (D) x 100mm (H) (1.65” (W) x 3.54” (D) x 3.94” (H)) -
Page 16: Connecting To The 10/100 Mbps Rj-45 Port
All green Link/Activity LEDs blink momentarily. The green Power LED goes ON. The Link/Activity LEDs for every port connected to a device flash, as the Hardened Ethernet Extender conducts a brief Power On Self-Test (POST). ED3541 Industrial Ethernet Extender User Guide... - Page 17 If the Power LED is not ON, check that the power source is plugged in correctly and that the power source is good. If this does not resolve the problem, see Chapter 3, ED3541 Industrial Ethernet Extender User Guide...
-
Page 18: Troubleshooting
Troubleshooting. ED3541 Industrial Ethernet Extender User Guide... -
Page 19: Troubleshooting Chart
3 Troubleshooting Topics: This chapter provides information about troubleshooting the Hardened Ethernet Extender. Troubleshooting Chart (page 19) Additional Troubleshooting Suggestions (page 20) ED3541 Industrial Ethernet Extender User Guide... - Page 20 Break the loop by ensuring that there is only one path from any networked flashing continuously on path) has been created. device to any other networked device. all connected ports and the network is disabled. ED3541 Industrial Ethernet Extender User Guide...
-
Page 21: Additional Troubleshooting Suggestions
Extender’s default setting) and the device at the other end of the link supports auto-negotiation. If the device does not support auto-negotiation, the Hardened Ethernet Extender determines only the speed correctly and the duplex mode defaults to half-duplex. ED3541 Industrial Ethernet Extender User Guide... -
Page 22: Technology
IP30 Dimensions: 42 mm (W) x 90 mm (D) x 100 mm (H) (1.65" (W) x 3.54" (D) x 3.94" (H)) Weight: 410 g (0.9 lb) Installation: DIN-Rail (Top hat type 35 mm) Mounting ED3541 Industrial Ethernet Extender User Guide... -
Page 23: Interface
… … 2600 This distance/data rate information is measured according testing standard in EtherWAN laboratory. The actual installation will be affected by the quality of copper wire and the impact of noise disturbance. The connection speed will be affected. NOTE: After making changes to the position of any DIP switch, the Ethernet Extender must be rebooted for the new settings to take effect. -
Page 24: Environment
EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) Environmental Test IEC60068-2-6 Fc (Vibration Resistance) Compliance IEC60068-2-27 Ea (Shock) FED STD 101C Method 5007.1 (Free fall w/ package) ED3541 Industrial Ethernet Extender User Guide... - Page 25 TEL: +886 -2- 6629-8986 Email: info@etherwan.com.tw EtherWAN has made a good faith effort to ensure the accuracy of the information in this document and disclaims the implied warranties of merchantability and fitness for a particular purpose, and makes no express warranties, except as may be stated in its written agreement with and for its customers.
