User’s Guide Gilson, Inc. | PO Box 620027 | Middleton, WI 53562-0027 | Tel: 608-836-1551 OR 800-445-7661 | Fax: 608-831-4451 Gilson S.A.S. | 19, avenue des Entrepreneurs | BP 145, F-95400 Villiers-le-bel, FRANCE www.gilson.com | sales@gilson.com | service@gilson.com | training@gilson.com LT310210-01...
Page 2
Description EXTRACTMAN® leverages proprietary Exclusion-based Sample Preparation (ESP™) technology to gently and quickly target proteins from a variety of samples, including weakly-bound protein complexes that traditional isolation techniques leave behind . The sliding handle processes up to four samples simultaneously in as few as 30 seconds .
Page 3
Figure 10: Input, Wash, and Output Well Locations Fill each subsequent well with wash or reagent solution . Wells should have prominent menisci to ensure proper NOTE contact with the bead capture strip . Figure 11: Prominent Menisci on the 4-Row Microplate User’s Guide EXTRACTMAN®...
Page 4
Smaller paramagnetic beads exert less magnetic force than larger beads, resulting in a slower time to pellet . This dynamic may result in longer capture times . Gilson recommends waiting a few moments after the bead discoloration in the wells has cleared before advancing to the next well column .
