CB3064-xxxx
Kabylake
Beckhoff Automation GmbH & Co. KG
Eiserstr. 5
33415 Verl
Germany
Manual
Rev. 1.0
phone:
+49 (0) 52 46/963-0
fax:
+49 (0) 52 46/963-198
email:
info@beckhoff.de
web:
www.beckhoff.de

Advertisement

Table of Contents
loading

Related Manuals for Beckhoff CB3064 Series

Summary of Contents for Beckhoff CB3064 Series

  • Page 1 CB3064-xxxx Manual Rev. 1.0 Kabylake Beckhoff Automation GmbH & Co. KG phone: +49 (0) 52 46/963-0 Eiserstr. 5 fax: +49 (0) 52 46/963-198 33415 Verl email: info@beckhoff.de Germany web: www.beckhoff.de...

  • Page 3: Table Of Contents

    PCI-Express ..........................31 4.12 GPIO ............................33 4.13 Fan Connectors .......................... 34 4.14 System ............................35 State LEDs ............................36 RGB LED ............................ 36 BIOS Settings ............................. 37 General Remarks ........................37 Main ............................38 Beckhoff New Automation Technology CB3064-xxxx page 3...
  • Page 4 Electrical Data ........................... 116 Environmental Conditions ......................116 Thermal Specifications ......................117 Support and Service ........................118 Beckhoff's Branch Offices and Representatives ..............118 Beckhoff Support ........................118 Beckhoff Service ........................118 Beckhoff Headquarters ......................118 Annex: Post-Codes .......................... 120 Annex: Resources ..........................
  • Page 5 Notes on the Documentation Chapter: Document History Beckhoff New Automation Technology CB3064-xxxx page 5...

  • Page 6: Document History

    First released version All company names, brand names, and product names referred to in this manual are registered or unregistered trademarks of their respective holders and are, as such, protected by national and international law. page 6 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 7: Introduction

    The TwinCAT Technology is covered, including but not limited to the following patent applications and patents: EP0851348, US6167425 with corresponding applications or registrations in various other countries.. EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany. 1.1.4 Copyright ©...

  • Page 8: Safety Instructions

    All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. page 8...

  • Page 9: Description Of Safety Symbols

    1.4 FCC Approval for Canada FCC: Canadian Notice This equipment does not exceed the Class A limits for radiated emissions as described in the Radio Interference Regulations of the Canadian Department of Communications. Beckhoff New Automation Technology CB3064-xxxx page 9...

  • Page 10: Essential Safety Measures

    Read the operating instructions All users of the product must have read the operating instructions for the system they work with. System know-how All users must be familiar with all accessible functions of the product. page 10 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 11: Functional Range

    As far as the described motherboard was acquired as an integral component of an Industrial PC from Beckhoff Automation GmbH & Co. KG, this product description shall be applied only in limited scope. Only the contractually agreed specifications of the corresponding Industrial PC from Beckhoff Automation GmbH &...

  • Page 12: Overview

    USB 2.0 USB1-4 USB 3.0 PCA9518PW 8x GPIO SMBus USB11 (I-PEX) USB 3.0 Intel® Q170-PCH PCIe 4x SATA 1.5/3/6 Gb/s PCIe (4 x1 oder 1 x4) LAN1 Intel® i219 Trusted Platform NCT7491MNTXG Module page 12 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 13: Feature List

    CMOS battery BIOS AMI® Aptio V Power Supply 5V / S5V / 3,3V / 12V Format 102 mm x 147 mm The feature list specifies all suitable CPUs. Their actual availability is manufacturer-specific. Notice Beckhoff New Automation Technology CB3064-xxxx page 13...

  • Page 14: Specifications And Documents

     Intel® chip description i210 datasheet www.intel.com  NCT7491MNTXG NCT7491 chip description www.onsemi.com  American Megatrends® Aptio™ Text Setup Environment (TSE) User Manual www.ami.com  American Megatrends® Aptio™ 5.x Status Codes www.ami.com page 14 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 15: Detailed Description

    TXD also can be used for PSU, e.g. the UPS functionality. Communication is carried out via SMBus signaling (SMB_CLK/SMB_DAT). Only for use with Beckhoff-certified PSU! The CB3064 is designated for use with the Beckhoff PSU CA2000-0021 only. Attention 3.2 SUPS Optionally the CB3064 can be equipped with a plug-in SUPS, which can keep the board alive over a short period of time in case of power failure or voltage fluctuation.

  • Page 16: Connectors

    Restrictions on maximum cable length are also in place for many high Notice speed interfaces and for power supply. Please refer to the respective specifications and use suitable cables at all times. page 16 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 17: Connector Map

    "Fan Connectors" p. 34 P1001 "PCI-Express", p. 31 P1002 "System" p. 35 P1100 "Serial Interface COM1" p. 30 P1101/3 "USB 3-6" p. 25 P1102/4 "USB2.0 (internal)" p. 26 P1200 "Power Input" p. 15 Beckhoff New Automation Technology CB3064-xxxx page 17...

  • Page 18: Power Input

    5V / 17A 18 VCC 5V / 17A SUSV activity: SUSV 19 GND ground Low (0V) = SUPS inactive High (3.3V) = SUPS active 3.3V / 10A 3.3V 10 20 3.3V 3.3V / 10A page 18 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 19: Memory

    Data lane 14 Ground Ground Data lane 10 DQ10 DQ11 Data lane 11 Ground Ground Data lane 21 DQ21 DQ20 Data lane 20 Ground Ground Data lane 17 DQ17 DQ16 Data lane 16 Ground Ground Beckhoff New Automation Technology CB3064-xxxx page 19...
  • Page 20 Chip Select 0 CS0_n Bank Adress 0 Address lane 14/Write A14/WE_n A16/RAS_n Address lane 16/Row Enable Address Strobe Power supply 1,2V Power supply 1,2V On Die Termination 0 ODT0 A15/CAS_n Address lane 15/Column Address Strobe page 20 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 21 Data lane 58 DQ58 DQ59 Data lane 59 Ground Ground SMBus Clock SMBus Data I²C Power for SPD EEProm VCCSPD SPD address 0 DRAM Activating Power Termination voltage DRAM Activating Power SPD address 1 Beckhoff New Automation Technology CB3064-xxxx page 21...

  • Page 22: Dvi

    HP_DETECT hot plug detect TMDSDAT0# DVI data 0 - TMDSDAT0 DVI data 0 + ground reserved reserved ground TMDS CLK DVI clock + TMDS CLK# DVI clock - reserved reserved reserved reserved ground page 22 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 23: Dvi/Hdmi/Displayport And Usb3.0

    SEL_DVI/DP# DVI-DisplayPort Select DDCK/DPAUX EDID Clock / DP Aux + DDDA/DPAUX# EDID Data / DP Aux - 5V supply ground hot plug detect USBVCC 5V supply for USB USBVCC 5V supply for USB Beckhoff New Automation Technology CB3064-xxxx page 23...
  • Page 24 Super Speed receiver - SSRX Super Speed receiver + USB# USB - USB + SSTX# Super Speed transmitter - SSTX Super Speed transmitter 3.3V 3.3V supply 3.3V 3.3V supply 5V supply 5V supply 5V supply page 24 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 25: Usb 3-6

    Pinout USB3.0 connector for channel X: Name Description 5 volt for USBX USBX# Minus channel USBX USBX Plus channel USBX ground StdA_SSRX- SuperSpeed Receiver - StdA_SSRX+ SuperSpeed Receiver + ground StdA_SSTX- SuperSpeed Transmitter - StdA_SSTX+ SuperSpeed Transmitter + Beckhoff New Automation Technology CB3064-xxxx page 25...

  • Page 26: Usb2.0 (Internal)

    Minus data channell USB11 5V for USB12 5V for USB11 Pinout 2x4-pin USB connector: Description Name Name Description 5V for USB13 5V for USB14 Minus data channel USB13 USB13- USB14- Minus data channel USB14 page 26 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 27 USB2.0 (internal) Chapter: Connectors Description Name Name Description Plus data channel USB13 USB13+ USB14+ Plus data channel USB14 Ground Ground Beckhoff New Automation Technology CB3064-xxxx page 27...

  • Page 28: Lan

    LAN channel 0 minus LAN-1 LAN channel 1 plus LAN-2 LAN channel 2 plus LAN-2# LAN channel 2 minus LAN-1# LAN channel 1 minus LAN-3 LAN channel 3 plus LAN-3# LAN channel 3 minus page 28 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 29: Sata Interfaces

    SATA connector and supports RAID 0/1/5/10. The required settings are made in the BIOS setup. Pinout SATA: Name Description ground SATATX SATA transmit + SATATX# SATA transmit - ground SATARX SATA receive - SATARX# SATA receive + ground Beckhoff New Automation Technology CB3064-xxxx page 29...

  • Page 30: Serial Interface Com1

    The port address and the interrupt are set via the BIOS setup. Pinout serial port (DSUB connector): Description Name Name Description data carrier detect data set ready receive data request to send transmit data clear to send data terminal ready ring indicator ground page 30 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 31: Pci-Express

    3.3 volt supply 3.3V 12 volt supply 3.3 volt power supply S3.3V reserved reserved reserved reserved ground ground reserved reserved reserved reserved ground Beckhoff New Automation Technology CB3064-xxxx page 31...
  • Page 32 3.3 volt supply 3.3V 12 supply 3.3 volt supply S3.3V reserved reserved reserved reserved ground ground reserved reserved reserved reserved ground ground reserved reserved reserved reserved ground page 32 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 33: Gpio

    GP input/output 10 GPIO10 GPIO14 GP input/output 14 GP input/output 11 GPIO11 GPIO15 GP input/output 15 GP input/output 12 GPIO12 GPIO16 GP input/output 16 GP input/output 13 GPIO13 GPIO17 GP input/output 17 ground ground Beckhoff New Automation Technology CB3064-xxxx page 33...

  • Page 34: Fan Connectors

    98424-G52-10LF 90311-010LF Pinout 2x5-pin connector: Description Name Name Description FAN 1 ON FANON1 FANON2 FAN 2 ON FAN1 control FANCTRL1 FANCTRL2 Fan 2 control FANCTRL3 Fan 3 control FAN 3 ON FANON3 ground page 34 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 35: System

    SMBALERT# SMB alert SMB clock SMBCLKEX 7 SMBDATEXT SMB data Speaker SPEAKER SVCC Standby power supply 5V Not connected Not connected Ground Power supply 5V Ground Power supply 5V Ground Power supply 5V Beckhoff New Automation Technology CB3064-xxxx page 35...

  • Page 36: State Leds

    PCI104-Express "stacking error". Such an error could occur when the stack contains a peripheral card which has the wrong type of connector Notice (PCI104-Express Type 1 instead of Type 2 or vice versa). page 36 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 37: Bios Settings

    They do not represent the recommended settings or the default settings. Determination of the appropriate settings is dependent upon the particular application scenario in which the board is used. Notice Beckhoff New Automation Technology CB3064-xxxx page 37...

  • Page 38: Main

    Options: none  Name Options: none  Type Options: none  Speed Options: none  ID Options: none  Stepping Options: none  Number of Processors Options: none  Microcode Revision Options: none page 38 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 39  Total Memory Options: none  Memory Frequency Options: none  System Date Options: The system date can be adjusted here.  System Time Options: The system time can be adjusted here. Beckhoff New Automation Technology CB3064-xxxx page 39...

  • Page 40: Advanced

     ACPI Settings Sub menu: see "ACPI Settings" (page 58)  H/W Monitor Sub menu: see "H/W Monitor" (page 59)  Serial Port Console Redirection Sub menu: see "Serial Port Console Redirection" (page 61) page 40 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 41  USB Configuration Sub menu: see "USB Configuration" (page 69)  SATA and RST Configuration Sub menu: see "SATA and RST Configuration" (page 70)  AMT Configuration Sub menu: see "AMT Configuration" (page 74) Beckhoff New Automation Technology CB3064-xxxx page 41...

  • Page 42: Platform Misc Configuration Configuration

    Disabled / Enabled  Wake up hour Options: 0..23  Wake up minute Options: 0..59  Wake up second Options: 0..59  ACPI Debug Options: Disabled / Enabled  ACPI Memory Buffer Address Options: none page 42 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 43  PEP Constraints Configuration Sub menu: see "PEP Constraints Configuration" (page 44)  Lpit Recidency Counter Options: SLP S0 / C10  PCI Delay Optimization Options: Disabled / Enabled  ZpODD Support Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 43...
  • Page 44  PEP I2C1 Options: Disabled / Enabled  PEP I2C2 Options: Disabled / Enabled  PEP I2C3 Options: Disabled / Enabled  PEP I2C4 Options: Disabled / Enabled  PEP I2C5 Options: Disabled / Enabled page 44 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 45  PEP SPI Options: Disabled / Enabled  PEP XHCI Options: Disabled / Enabled  PEP Audio Options: Disabled / Enabled  PEP EMMC Options: Disabled / Enabled  PEP SDXC Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 45...

  • Page 46: Cpu Configuration

     L2 Cache Options: none  L3 Cache Options: none  L4 Cache Options: none  VMX Options: none  SMX/TXT Options: none  SW Guard Extensions (SGX) Options: Software Controlled / Enabled / Disabled page 46 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 47  Active Processor Cores Options:  Hyper-threading Options: Enabled / Disabled  CPU AES Options: Disabled / Enabled  CPU - Power Management Control Sub menu: see "CPU - Power Management Control" (page 48) Beckhoff New Automation Technology CB3064-xxxx page 47...
  • Page 48 Disabled / Enabled  Turbo Mode Options: Disabled / Enabled  View/Configure Turbo Options Sub menu: see "View/Configure Turbo Options" (page 49)  Config TDP Configurations Sub menu: see "Config TDP Configurations" (page 50) page 48 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 49  x-core Turbo Ratio Options: none  Energy Efficient P-state Options: Enabled / Disabled  Package Power Limit MSR Lock Options: Disabled / Enabled  Energy Efficient Turbo Options: Enabled / Disabled Beckhoff New Automation Technology CB3064-xxxx page 49...
  • Page 50 Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Configurable TDP Boot Mode Options: Nominal / Down / Deactivate  Configurable TDP Lock Options: Enabled / Disabled  Configurable CTDP BIOS control Options: Enabled / Disabled page 50 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 51: Intel(R) I210 Gigabit Network Connection

     Chip Type Options: none  PCI Device ID Options: none  PCI Address Options: none  Link Status Options: none  MAC Address Options: none  Virtual MAC Address Options: none Beckhoff New Automation Technology CB3064-xxxx page 51...
  • Page 52 Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Link Speed Options: Auto Negotiated / 10Mbps Half / 10Mbps full / 100Mbps Half / 100Mbps Full  Wake On LAN Options: Enabled / Disabled page 52 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 53: Intel(R) Ethernet Connection I219-Lm

    Options: none  Adapter PBA Options: none  Chip Type Options: none  PCI Device ID Options: none  PCI Address Options: none  Link Status Options: none  MAC Address Options: none Beckhoff New Automation Technology CB3064-xxxx page 53...

  • Page 54: Driver Health

    Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Intel(R) Gigabit 0.0.16 Sub menu: see "Intel(R) Gigabit 0.0.16" (page 54)  Intel(R) PRO/1000 7.3.20 PCI-E Sub menu: see "Intel(R) PRO/1000 7.3.20" (page 56) page 54 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 55 │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Controller 899dd918 Child 0 Healthy Options: none Beckhoff New Automation Technology CB3064-xxxx page 55...
  • Page 56 │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Controller 899de498 Child 0 Healthy Options: none  Intel(R) I210 Gigabit Network Connection Options: none page 56 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 57: Trusted Computing

    │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Security Device Support Options: Enable / Disable Beckhoff New Automation Technology CB3064-xxxx page 57...

  • Page 58: Acpi Settings

     Enable ACPI Auto Configuration Options: Enabled / Disabled  Enable Hibernation Options: Enabled / Disabled  ACPI Sleep State Options: Suspend Disabled / S1 (CPU Stop Clock)  Lock Legacy Resources Options: Enabled / Disabled page 58 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 59: H/W Monitor

    Options: none  12V Options: none  VBATT Options: none  3.3V Options: none  SIO Temp Options: none  1.00V Options: none  Memory VDD Options: none  FAN 1 Options: none Beckhoff New Automation Technology CB3064-xxxx page 59...
  • Page 60 Chapter: BIOS Settings Advanced  FAN 2 Options: none  FAN 3 Options: none  MB Temp Options: none  Memory Temp Options: none  PwrCtrlTemp Options: none  PwrCtrlVCC Options: none page 60 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 61: Serial Port Console Redirection

    │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Console Redirection Options: Enabled / Disabled  Console Redirection Settings Options: none Beckhoff New Automation Technology CB3064-xxxx page 61...

  • Page 62: Pci Subsystem Settings

     PERR# Generation Options: Disabled / Enabled  SERR# Generation Options: Disabled / Enabled  Above 4G Decoding Options: Enabled / Disabled  PCI Hot-Plug Settings Sub menu: see "PCI Hot-Plug Settings" (page 63) page 62 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 63 Disabled / 4 K / 8 K / 16 K / 32 K  PFMMIO 32 bit Resources Options: Disabled / 1 M / 2 M / 4 M / 8 M / 16 M / 32 M / 64 M / 64 M Beckhoff New Automation Technology CB3064-xxxx page 63...

  • Page 64: Network Stack Configuration

    Options: Disabled / Enabled  IPv6 HTTP Support Options: Disabled / Enabled  IPv6 Configuration Policy Options: Automatic / Manual  PXE boot wait time Options: 0..5  Media detect count Options: 0..50 page 64 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 65: Power Controller Options

    Options: none  ext. USB-Port Voltage Options: Off in S3-5 / by SVCC  int. USB-Port Voltage Options: Off in S3-5 / by SVCC  WatchDogTimer Mode Options: Normal Mode / Compatibility Mode Beckhoff New Automation Technology CB3064-xxxx page 65...
  • Page 66 Chapter: BIOS Settings Advanced  WDT OSBoot Timeout Options: Disabled / 45 Seconds ... 255 Seconds page 66 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 67: Compatibility Support Module Configuration

    Do not launch / UEFI only / Legacy only  Video Options: Do not launch / UEFI only / Legacy only  Other PCI devices Options: Do not launch / UEFI / Legacy Beckhoff New Automation Technology CB3064-xxxx page 67...

  • Page 68: Nvme Controller And Drive Information

    │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  NVMe controller and Drive information Options: none page 68 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 69: Usb Configuration

    5 sec / 10 sec / 20 sec  USB transfer time-out Options: 10 sec / 20 sec / 30 sec / 40 sec  Device power-up delay Options: Auto / Manual  Device power-up delay in seconds Options: 1..40 Beckhoff New Automation Technology CB3064-xxxx page 69...

  • Page 70: Sata And Rst Configuration

    Default / Gen1 / Gen2 / Gen3  Serial ATA Port X Options: none  Software Preserve Options: none  Port X Options: Enabled / Disabled  Hot Plug Options: Enabled / Disabled page 70 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 71 Unknown / ISATA / Direct Connect / Flex / M2  SATA Port X DevSlp Options: Disabled / Enabled  DITO Configuration Options: Disabled / Enabled  DITO Value Options: 0..1023  DM Value Options: 0..15 Beckhoff New Automation Technology CB3064-xxxx page 71...
  • Page 72 Enabled / Disabled  IRRT Only on eSATA Options: Enabled / Disabled  Smart Response Technology Options: Enabled / Disabled  OROM UI Normal Delay Options: 2 / 4 / 6 / 8 Seconds page 72 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 73 Advanced Chapter: BIOS Settings  RST Force Form Options: Enabled / Disabled Beckhoff New Automation Technology CB3064-xxxx page 73...

  • Page 74: Amt Configuration

     Secure Erase Configuration Sub menu: see "Secure Erase Configuration" (page 77)  OEM Flags Settings Sub menu: see "OEM Flags Configuration" (page 78)  MEBx Resolution Settings Sub menu: see "MEBx Resolution Settings" (page 79) page 74 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 75 │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Activate Remote Assistance Process Options: Enabled / Disabled  CIRA Timeout Options: 0..255 Beckhoff New Automation Technology CB3064-xxxx page 75...
  • Page 76 │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  PET Progress Options: Enabled / Disabled  WatchDog Options: Enabled / Disabled  OS Timer Options: 0..65535  BIOS Timer Options: 0..65535 page 76 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 77 │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Secure Erase mode Options: Simulated / Real  Force Secure Erase Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 77...
  • Page 78  MEBx Selection Screen Options: Disabled / Enabled  Hide Unconfigure ME Confirmation Prompt Options: Disabled / Enabled  MEBx OEM Debug Menu Enable Options: Disabled / Enabled  Unconfigure ME Options: Disabled / Enabled page 78 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 79 Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Non-UI Mode Resolution Options: Auto / 80x25 / 100x31  UI Mode Resolution Options: Auto / 80x25 / 100x31  Graphics Mode Resolution Options: Auto / 640x480 / 800x600 / 1024x768 Beckhoff New Automation Technology CB3064-xxxx page 79...

  • Page 80: Chipset

    └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  System Agent (SA) Configuration Sub menu: see "System Agent (SA) Configuration" (page 81)  PCH-IO Configuration Sub menu: see "PCH-IO Configuration" (page 86) page 80 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 81: System Agent (Sa) Configuration

     Thermal Device (B0:D4:F0) Options: Disabled / Enabled  GMM Device (B0:D8:F0) Options: Disabled / Enabled  CRID Support Options: Disabled / Enabled  Above 4GB MMIO BIOS assignment Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 81...
  • Page 82  DVMT Pre-Allocated Options: 32M / 64M ... 480M / 512M / 1024M  DVMT Total Gfx Mem Options: 128M / 256M / MAX  Gfx Low Power Mode Options: Disabled / Enabled page 82 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 83  Cd Clock Frequency Options: 337.5 Mhz / 450 Mhz / 540 Mhz / 675 Mhz  IUER Button Enable Options: Enabled / Disabled  LCD Control Sub menu: see "LCD Control" (page 85) Beckhoff New Automation Technology CB3064-xxxx page 83...
  • Page 84 │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Primary PEG Options: Auto / PEG11 / PEG 12  Primary PCIE Options: Auto / PCIE1 / PCIE2 / ... / PCIE7 page 84 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 85  Backlight Control Options: PWM Inverted / PWM Normal  Active LFP Options: No eDP / eDP Port-A  Panel Color Depth Options: 18 Bit / 24 Bit  Backlight Brightness Options: 0..255 Beckhoff New Automation Technology CB3064-xxxx page 85...

  • Page 86: Pch-Io Configuration

    Options: Disabled / Enabled in S4-S5  LAN Wake From DeepSx Options: Disabled / Enabled  Wake on LAN Options: Disabled / Enabled  SLP_LAN# Low on DC Power Options: Disabled / Enabled page 86 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 87 S0 State / S5 State  Compatible Revision ID Options: Disabled / Enabled  PCH Cross Throttling Options: Disabled / Enabled  PCIe Pll SSC Options: Auto / 0.0% / 0.1% / 0.2% / ... / 2.0% Beckhoff New Automation Technology CB3064-xxxx page 87...
  • Page 88 Disabled / Enabled  PCI Express Gen3 Eq Lanes Sub menu: see "PCI Express Gen3 Eq Lanes" (page 89)  PCI Express Root Port X Sub menu: see "PCI Express Root Port" (page 90) page 88 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 89 │ │ PCIE12 Cp ░│ │ │ PCIE13 Cm ░│ │ │ ▼│ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  PCIEX Cm Options: 0..63  PCIEX Cp Options: 0..63 Beckhoff New Automation Technology CB3064-xxxx page 89...
  • Page 90 Hardware / Static Coeff. / Software Search  UPTP Options: 0..10  DPTP Options: 0..10  ACS Options: Enabled / Disabled  URR Options: Enabled / Disabled  FER Options: Enabled / Disabled  NFER Options: Enabled / Disabled page 90 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 91  Snoop Latency Value Options: 0..1023  Snoop Latency Multiplier Options: 1 / 32 / 1024 / 32768 / 1048576 / 33554432 ns  Non Snoop Latency Override Options: Disabled / Manual / Auto Beckhoff New Automation Technology CB3064-xxxx page 91...
  • Page 92  PCIE1 LTR Lock Options: Disabled / Enabled  PCIE1 CLKREQ Mapping Override Options: Default / No CLKREQ / Custom Number  CLKREQ Number Options: 0..15  Extra Options Sub menu: see "Extra Options" (page 93) page 92 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 93 Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Detect Non-Compliance Device Options: Disabled / Enabled  Prefetchable Memory Options: 1..20  Reserved memory Alignment Options: 1..31  Prefetchable Memory Alignment Options: 1..31 Beckhoff New Automation Technology CB3064-xxxx page 93...
  • Page 94  USB Port Disable Override Options: Disabled / Select Per-Pin  USB SS Physical Connector #x Options: Disabled / Disabled  USB HS Physical Connector #x Options: Disabled / Disabled  USB Precondition Options: Disabled / Enabled page 94 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 95  HD Audio Options: Disabled / Enabled / Auto  HDA-Link Codec Select Options: Platform Onboard / External Kit  iDisplay Audio Disconnect Options: Disabled / Enabled  PME Enable Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 95...
  • Page 96  GPIO Controller Options: Disabled / Enabled  Serial IO UART0 Settings Sub menu: see "Serial IO UART0 Settings" (page 98)  Serial IO UART1 Settings Sub menu: see "Serial IO UART1 Settings" (page 99) page 96 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 97 Disabled / Enabled - UART0 / Enabled - UART1 / Enabled - UART2  Additional Serial IO devices Options: Disabled / Enabled  Serial IO timing parameters Sub menu: see "Serial IO Timing Parameters" (page 102)  UCSI/UCMC device Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 97...
  • Page 98 Disabled / Intel Snowfield Peak / Broadcom BRCM 43241  BT Interrupt Mode Options: GPIO Interrupt / APIC Interrupt  Wireless Charging Mode Options: WC Disabled / WC Enabled  Hardware Flow Control Options: Disabled / Enabled page 98 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 99 │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Hardware Flow Control Options: Disabled / Enabled Beckhoff New Automation Technology CB3064-xxxx page 99...
  • Page 100 │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Hardware Flow Control Options: Disabled / Enabled page 100 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 101 │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  GPIO IRQ Route Options: IRQ14 / IRQ15 Beckhoff New Automation Technology CB3064-xxxx page 101...
  • Page 102  FastSpeedPlus SCL High for I2C1 Options: 0..65535  FastSpeedPlus SCL Low for I2C1 Options: 0..65535  FastSpeedPlus SDA Hold for I2C1 Options: 0..65535  D0->D3 idle timeout for I2C1 (screen off) Options: 0..10000 page 102 Beckhoff New Automation Technology CB3064-xxxx...
  • Page 103  D0->D3 idle timeout for SPI1 (screen off) Options: 0..10000  D0->D3 idle timeout for SPI1 (screen on) Options: 0..10000  D0->D3 idle timeout for UART1 (screen off) Options: 0..10000  D0->D3 idle timeout for UART1 (screen on) Options: 0..10000 Beckhoff New Automation Technology CB3064-xxxx page 103...

  • Page 104: Security

    │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Administrator Password Options: Press [Enter]  Secure Boot menu Sub menu: see "Secure Boot Menu" (page 105) page 104 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 105: Secure Boot Menu

    Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Secure Boot Support Options: Disabled / Enabled  Secure Boot Mode Options: Standard / Custom  Key Management Sub menu: see "Key Management" (page 106) Beckhoff New Automation Technology CB3064-xxxx page 105...
  • Page 106 Set New Key / Append Key  Forbidden Signatures Options: Set New Key / Append Key  Authorized TimeStamps Options: Set New Key / Append Key  OsRecovery Signatures Options: Set New / Append page 106 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 107: Boot

    Options: Disabled / Enabled  NetWork Stack Driver Support Options: Disabled / Enabled  Redirection Support Options: Disabled / Enabled  New Boot Option Policy Options: Default / Place First / Place Last Beckhoff New Automation Technology CB3064-xxxx page 107...
  • Page 108 Legacy / UEFI / DUAL  Fixed Boot Order Priorities Options: Review or change the sequence of available boot devices  Advanced Fixed Boot Order Parameters Sub menu: see "Fixed Boot Order Priority" (page 109) page 108 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 109: Fixed Boot Order Priority

    │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.  Max. CFast/SSD capacity (GB) Options: 1..16384  Max. USB Stick capacity (GB) Options: 1..16384 Beckhoff New Automation Technology CB3064-xxxx page 109...

  • Page 110: Save & Exit

     Restore Defaults Options: Press [Enter]  Save as User Defaults Options: Press [Enter]  Restore User Defaults Options: Press [Enter]  Boot Override Options: Press [Enter]  IBA GE Slot 00C8 v1381 Options: none page 110 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 111: Bios Update

    BIOS file which was issued for the exact board and exact board revision that you wish to update. If you try to update the BIOS using the wrong file the board will not start up again. Beckhoff New Automation Technology CB3064-xxxx page 111...

  • Page 112: Mechanical Drawings

    Chapter: Mechanical Drawings PCB: Mounting Holes 7 Mechanical Drawings All dimensions are in mil (1 mil = 0,0254 mm). Notice 7.1 PCB: Mounting Holes 3858 1102 page 112 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 113: Pcb: Pin 1 Dimensions

    PCB: Pin 1 Dimensions Chapter: Mechanical Drawings 7.2 PCB: Pin 1 Dimensions 3956 3695 1193 1428 1508 3330 3569 Beckhoff New Automation Technology CB3064-xxxx page 113...

  • Page 114: Pcb: Die Center

    Chapter: Mechanical Drawings PCB: DIE Center 7.3 PCB: DIE Center 1590 1213 1080 page 114 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 115: Pcb: Outlines

    PCB: Outlines Chapter: Mechanical Drawings 7.4 PCB: Outlines 4016 Beckhoff New Automation Technology CB3064-xxxx page 115...

  • Page 116: Technical Data

    9 up to 500Hz, 10m/s , for packaged boards Shock and vibration Shock and vibration figures pertain to the motherboard alone and do not include additional components such as heat sinks, memory modules, cables etc. Notice page 116 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 117: Thermal Specifications

    100°C. Permanent overheating may destroy the board! CAUTION In case the temperature exceeds 100°C the environmental temperature must be reduced. Under certain circumstances sufficient air circulation must be provided. Beckhoff New Automation Technology CB3064-xxxx page 117...

  • Page 118: Support And Service

    Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products. The addresses of Beckhoff's branch offices and representatives around the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there.
  • Page 119 Annex: Post-Codes Beckhoff New Automation Technology CB3064-xxxx page 119...

  • Page 120: I Annex: Post-Codes

    (POST code card). The meaning of these codes is described in the document "Aptio™ 4.x Status Codes" by American Megatrends®, which can be downloaded from their website http://www.ami.com. The following additional OEM POST codes are generated: Code Description BIOS-API started PCA9535 started PWRCTRL-Firmware started page 120 Beckhoff New Automation Technology CB3064-xxxx...

  • Page 121: Annex: Resources

    SATA (AHCI 1.0) IDA102 PCI Bridge (0-1)x0 (x4) IDA110 PCI Bridge (0-2)x1 (x1) IDA115 Other DPIO Module IDA127 ISA Bridge IDA146 Memory Controller IDA121 SMBus Controller IDA123 Ethernet Controller ID15B7 Ethernet Controller x1 (x1) Beckhoff New Automation Technology CB3064-xxxx page 121...

  • Page 122: Resources: Smb-Devices

    Reserved 40-41 GPIO 5C-5D NCT7491 60-6F Reserved for DDR4 70-73 POST-Code output 88-89 BIOS-defined slave address 92-93 i210 default A0-A7 Reserved for DDR4 B0-B3 Power-Controller (access by BIOS-API) B8-BB Power-Controller (access by BIOS-API) page 122 Beckhoff New Automation Technology CB3064-xxxx...
