- Page 1 VEO-XPS15 FULL HD EXTENDER Full HD single Cat5e/6 Extender Kit USER MANUAL...
-
Page 2: Table Of Contents
INDEX IMPORTANT REMARK ......................3 IMPORTANT SAFETY INSTRUCTIONS ................3 IMPORTANT NOTE ........................ 5 INTRODUCTION ........................5 PACKAGE CONTENTS ......................5 PANEL DESCRIPTION ......................6 6.1. Transmitter Front and Rear Panel ..................6 6.2. Receiver Front and Rear Panel....................6 CONNECTION AND INSTALLATION ................. -
Page 3: Important Remark
1. IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 4 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
-
Page 5: Important Note
3. IMPORTANT NOTE Thank you for choosing our VEO-XPS15 Full HD extender Kit. It is very important to carefully read this manual and to fully understand its contents before making any connection in order to maximize your use and get the best performance from this equipment. -
Page 6: Panel Description
6. PANEL DESCRIPTION 6.1. Transmitter Front and Rear Panel 1. HDMI Input Port 2. EDID Function Selector: o Right position: extender will copy HDMI loop Output display EDID information o Left position: extender will copy Receiver display EDID information 3. HDMI Output Port 4. -
Page 7: Connection And Installation
3. Check the EQ switcher settings, according to the cable length, as reported in the following table: 4. Connect HDMI display device (Full HD display) to HDMI output of VEO-XPS15. 5. Connect IR Blaster cable into IR-Out port of the Transmitter; Connect IR Receiver cable into IR-In port of the Receiver. -
Page 8: Application Diagram
8. APPLICATION DIAGRAM... -
Page 9: Technical Specifications
176.4kHz, 192kHz Bitrate up to 24-bit Distance up to 50 meters (165 ft) HDMI Distance up to 10 meters (33 ft) with Ecler VEO cables Operating Temperature 0 - 40°C (32 - 104°F) Humidity 20 - 90% RH (no condensation) Power Consumption TX: 1.5W;... - Page 10 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 | information@ecler.com www.ecler.com...
