Ecler VEO-XPT24 User Manual

4k hdbaset extender kit 10.2 gbps
Hide thumbs Also See for VEO-XPT24:
Table of Contents

Advertisement

Quick Links

Download this manual
VEO-XPT24
4K HDBaseT Extender Kit 10.2 GBPS
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEO-XPT24 and is the answer not in the manual?

Questions and answers

Related Manuals for Ecler VEO-XPT24

Summary of Contents for Ecler VEO-XPT24

  • Page 1 VEO-XPT24 4K HDBaseT Extender Kit 10.2 GBPS USER MANUAL...

  • Page 2: Table Of Contents

    INDEX IMPORTANT REMARK ......................3 IMPORTANT SAFETY INSTRUCTIONS ................3 IMPORTANT NOTE ........................ 5 INTRODUCTION ........................5 PACKAGE CONTENTS ......................6 PANEL DESCRIPTION ......................6 6.1. Transmitter ........................... 6 6.1.1. Front Panel ..........................6 6.1.2. Rear Panel ..........................7 6.2. Receiver ............................7 6.2.1.

  • Page 3: Important Remark

    1. IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 4 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.

  • Page 5: Important Note

    3. IMPORTANT NOTE Thank you for choosing our VEO-XPT24 4K HDBaseT extender. It is very important to carefully read this manual and to fully understand its contents before making any connection in order to maximize your use and get the best performance from this equipment.

  • Page 6: Package Contents

    5. PACKAGE CONTENTS  1 x Transmitter Unit  1 x Receiver Unit  1 x 12V DC International power supply (One PSU for both units)  2 x IR Blaster unit (IR emitter and cable, 1 pcs for TX, 1 pcs for RX) ...

  • Page 7: Rear Panel

    6.1.2. Rear Panel 1. RS-232 Function Switch: o Normal: RS-232 Pass-Through o Program: Firmware Upgrade 2. Cat5e/6/7 Output Port 3. HDBaseT Link Indicator 4. RS-232 Port 6.2. Receiver 6.2.1. Front Panel 1. RS-232 Function Switch: o Normal: RS-232 Pass-Through o Program: Firmware Upgrade 2.

  • Page 8: Rear Panel

    7. CONNECTION AND INSTALLATION 1. Connect HDMI signal source (such as PC, Blu-ray player, etc) to HDMI input of VEO-XPT24. 2. Connect Cat5e/6/7 cable from RJ45 output of TX to RJ45 input of RX. 3. Connect HDMI display device (such as 4K or Full HD display) to HDMI output of VEO-XPT24 4.

  • Page 9: Application Diagram

    5. Connect IR Receiver cable to IR-In port of the Transmitter; Connect IR Blaster cable to IR-Out port of the Receiver. 6. Phoenix RS-232 Ports can be connected to DTE-DCE devices for pass-through RS-232 transmission. 7. Connect 12V DC power supply to VEO-XPT24 Transmitter. 8. APPLICATION DIAGRAM...

  • Page 10: Technical Specifications

    9. TECHNICAL SPECIFICATIONS Supported Resolutions 4096x2160@24/25/30/50*/60Hz 3840x2160@24/25/30/50*/60Hz*(UHD), 2048x1080p,1080p@23.98/24/25/29.97/30/50/59 .94/60Hz, 1080i@50/59.94/60Hz,720p@50/59.94/60Hz, 576p, 576i, 480p, 480i VESA 2560x2048, 2560x1600, 2048x1536, 1920x1200, 1680x1050, 1600x1200, 1600x900, 1440x900, 1400x1050, 1366x768, 1360x768, 1280x1024, 1280x800, 1280x768, 1152x864, 1024x768, 800x600, 640x480 Colorspace YCbCr, RGB Chroma Subsampling 4:4:4, 4:2:2, 4:2:0 Color depth 8-bit, 10-bit, 12-bit, 16-bit only @1080p Signal Bandwidth...
  • Page 11 HDMI Distance up to 10 meters (33 ft) with Ecler VEO cables Operating Temperature -5 to +35°C (41 to +95 °F) Humidity 5 to 90 % RH (no condensation) Power Consumption 2.5W (TX), 5W (RX) Maximum Power Supply AC100~240V 50/60Hz Output: DC 12VDC 2A Dimensions H x W x D 105mm ×...
  • Page 12 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 | information@ecler.com www.ecler.com...
