With User to Create Better Product
3, Machine Assembly
3.1 Machine Parts
1.Y box
2.Extruder suite
3.X right module
4.X left module
7 Filament break detection
5. Feeding motor module
6.Z motor module
8.Idler module
module
9.Z limited witch seat
10.T Lead Screw
11.2040 aluminium profile
12.2020
aluminium profile-340
13.2020aluminium profile-3
14.Timing belt
15.Feeding pipe（ for
16.Top decoration panel
50
extruder）
8
