- Page 1 DEEP SEA ELECTRONICS PLC DSE8661 Operator Manual Document Number: 057-204 Author: Ashley Senior DSE8661 Operator Manual ISSUE 1...
- Page 2 Applications for the copyright holder’s written permission to reproduce any part of this publication should be addressed to Deep Sea Electronics Plc at the address above. The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC. Any reference to trademarked product names used within this publication is owned by their respective companies.
-
Page 3: Table Of Contents
3.9.1.3 RS485 PORT ....................21 3.9.1.3.1 CABLE SPECIFICATION ................21 3.9.1.3.2 RECOMMENDED PC RS485 SERIAL PORT ADD-ONS......22 3.9.1.3.3 CONNECTION BETWEEN DSE8661 MODULES ........22 3.9.1.4 ETHERNET PORT ..................23 3.9.1.4.1 DIRECT PC CONNECTION ................. 24 3.9.1.4.2 CONNECTION TO BASIC ETHERNET............25 3.9.1.4.3 CONNECTION TO COMPANY INFRASTRUCTURE ETHERNET .... - Page 4 DSE8661 Operator Manual 3.12.3 WEIGHT ....................33 3.12.4 FIXING CLIPS................... 34 3.12.5 CABLE TIE FIXING POINTS ..............35 3.12.6 SILICON SEALING GASKET..............35 3.12.7 APPLICABLE STANDARDS ..............36 3.12.8 ENCLOSURE CLASSIFICATIONS ............38 3.12.8.1 IP CLASSIFICATIONS ..................38 3.12.8.2 NEMA CLASSIFICATIONS ................39 3.12.8.3...
- Page 5 DSE8661 Operator Manual 5.2.8.1.1 CONNECTED TO AN RS232 TELEPHONE MODEM ........74 5.2.8.1.2 CONNECTED TO AN RS232 GSM MODEM ..........75 5.2.8.1.3 MODEM INITIALISATION SEQUENCE ............76 5.2.8.1.4 MODEM DIAGNOSTICS ................76 5.2.8.1.5 CONNECTED TO AN RS232 MODBUS MASTER ........77 5.2.9...
- Page 6 EDITING A PARAMETER ................109 8.2.4 EXITING THE ‘RUNNING’ CONFIGURATION EDITOR ......110 8.2.5 AVAILABLE PARAMETERS TO BE EDITED ..........110 COMMISSIONING ..................111 DSE 4 STEPS TO SUCCESSFUL SYNCHRONISING ........112 9.1.1 CONTROL ....................112 9.1.2 METERING ....................112 9.1.3 COMMUNICATIONS ..................
-
Page 7: Bibliography
Bibliography 1 BIBLIOGRAPHY This document refers to and is referred to by the following DSE publications which can be obtained from the DSE website: www.deepseaplc.com 1.1 INSTALLATION INSTRUCTIONS Installation instructions are supplied with the product in the box and are intended as a ‘quick start’... -
Page 8: Manuals
Bibliography 1.3 MANUALS Product manuals are downloaded from the DSE website: www.deepseaplc.com DSE Part No Description 057-045 Guide to Synchronising and Load Sharing Part 1 057-046 Guide to Synchronising and Load Sharing Part 2 057-047 Load Share Design and Commissioning Guide... -
Page 9: Introduction
Introduction 2 INTRODUCTION This document details the installation and operation requirements of the DSE8661 module, part of the DSEGenset® range of products. The manual forms part of the product and should be kept for the entire life of the product. If the product is passed or supplied to another party, ensure that this document is passed to them for reference purposes. -
Page 10: Specification
Description DSE8661 -30 ºC to +70 ºC (-22 ºF to +158 ºF) 3.3 TERMINAL SPECIFICATION NOTE: For purchasing additional connector plugs from DSE, please see the section entitled Maintenance, Spares, Repair and Servicing elsewhere in this document. Description Specification Two part connector. - Page 11 Specification...
-
Page 12: Voltage & Frequency Sensing
±0.05 Hz 3.6 CURRENT SENSING NOTE: CTs with 5 A secondary windings are recommended with DSE modules. 1 A CTs can be used if necessary however, the resolution of the readings is 5 times better when using 5 A CTs. -
Page 13: A Rating Of The Cts
Specification 3.6.1 V A RATING OF THE CTS NOTE: Details for 4 mm² cables are shown for reference only. The connectors on the DSE modules are only suitable for cables up to 2.5 mm². The V A burden of the module on the CTs is 0.5 V A. However depending upon the type and length of cabling between the CTs and the module, CTs with a greater V A rating than the module are required. -
Page 14: Ct Polarity
3.6.3 CT PHASING Take particular care that the CTs are connected to the correct phases. For instance, ensure that the CT on phase 1 is connected to the terminal on the DSE module intended for connection to the CT for phase 1. -
Page 15: Digital Inputs A To K
Specification 3.7 DIGITAL INPUTS A TO K Description Specification Number 11 configurable digital inputs Negative Switching Activation Connect the input terminal to the plant supply negative terminal Low Level Threshold 2.1 V minimum High Level Threshold 6.6 V maximum Maximum Input Voltage +50 V DC with respect to plant supply negative Minimum Input Voltage -24 V DC with respect to plant supply negative... -
Page 16: Communication Ports
Specification 3.9 COMMUNICATION PORTS NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: All communication ports can be used at the same time. Port Specification Type B USB 2.0 USB Slave Port... -
Page 17: Communication Port Use
NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: DSE stock 2 m (6.5 feet) USB type A to type B cable, DSE Part Number: 016-125. Alternatively they are purchased from any PC or IT store. -
Page 18: Rs232 Port
Many PCs are not fitted with an internal RS232 serial port. DSE DOES NOT recommend the use of USB to RS232 convertors but can recommend PC add-ons to provide the computer with an RS232... -
Page 19: Recommended Pc Rs232 Serial Port Add-Ons
Specification 3.9.1.2.1 RECOMMENDED PC RS232 SERIAL PORT ADD-ONS NOTE: DSE have no business tie to Brainboxes. Over many years, our own engineers have used these products and are happy to recommend them. NOTE: For further details of setting up the devices below, refer to the manufacture whose details are below. -
Page 20: Recommended External Modems
For a data connection to a PC running DSE Configuration Suite Software, a ‘special’ CSD (Circuit Switched Data) SIM card is required that enables the modem to answer an incoming data call. -
Page 21: Rs485 Port
Many PCs are not fitted with an internal RS485 serial port. DSE DOES NOT recommend the use of USB to RS485 convertors but can recommend PC add-ons to provide the computer with an RS485port. -
Page 22: Recommended Pc Rs485 Serial Port Add-Ons
This allows both DSE8661 modules to utilise the DSENet® port for localised expansion. 2. Configure one DSE8661 module to use the DSENet® port and the other DSE8661 module to use the RS485 port for communication. This allows the RS485 port on one of the DSE8661s modules... -
Page 23: Ethernet Port
The Ethernet port on the controller supports the Modbus TCP protocol and is for connection for up to five Modbus master devices. The DSE MODBUS register table for the controller is available upon request from the DSE Technical Support Department. -
Page 24: Direct Pc Connection
Specification 3.9.1.4.1 DIRECT PC CONNECTION Requirements Crossover Ethernet cable (see Below) • PC with Ethernet port • Crossover Ethernet Cable For the advanced Crossover Cable Wiring Detail Engineer, a crossover cable is a CAT5 cable Two pairs crossed, two pairs uncrossed with one end terminated 10baseT/100baseT crossover as T568A and the other... -
Page 25: Connection To Basic Ethernet
Specification 3.9.1.4.2 CONNECTION TO BASIC ETHERNET NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively they can be purchased from any PC or IT store. Requirements Ethernet cable (see below) • Working Ethernet (company or home network) •... -
Page 26: Connection To Company Infrastructure Ethernet
Specification 3.9.1.4.3 CONNECTION TO COMPANY INFRASTRUCTURE ETHERNET NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively they can be purchased from any PC or IT store. Requirements DSE module with the ability to connect to Ethernet •... -
Page 27: Connection To The Internet
Specification 3.9.1.4.4 CONNECTION TO THE INTERNET NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively they can be purchased from any PC or IT store. Requirements Ethernet cable (see below) • Working Ethernet (company or home network) •... -
Page 28: Firewall Configuration For Internet Access
DSE8661 Configuration Suite Software Manual. As modems or routers differ enormously in their configuration, it is not possible for DSE to give a complete guide to their use with the module. However it is possible to give a description of the requirements in generic terms. -
Page 29: Dsenet® Port
NOTE: DSE recommend Belden 9841 (or equivalent) cable for DSENet® communication. This is rated to a maximum cable length of 1.2 km. DSE Stock Belden 9841 cable, DSE Part Number: 016-030. NOTE: DSE8661 module does not support the DSE2510 or DSE2520 display modules. -
Page 30: Connection Between Dse8661 Modules
This allows both DSE8661 modules to utilise the DSENet® port for localised expansion. 2. Configure one DSE8661 module to use the DSENet® port and the other DSE8661 module to use the RS485 port for communication. This allows the RS485 port on one of the DSE8661s modules... -
Page 31: Msc Link Port
NOTE: DSE recommend Belden 9841 (or equivalent) cable for the MSC Link communication. This is rated to a maximum cable length of 250 m. DSE Stock Belden 9841 cable, DSE Part Number: 016-030. MSC (Multi Set Communication) Link is the interconnection cable between the DSE synchronising... -
Page 32: Sounder
64 db at 1 m 3.10.1 ADDING AN EXTERNAL SOUNDER Should an external alarm or indicator be required, this can be achieved by using the DSE Configuration Suite PC software to configure an auxiliary output for “Audible Alarm”, and by configuring an auxiliary input for “Alarm Mute”... -
Page 33: Dimensions And Mounting
Specification 3.12 DIMENSIONS AND MOUNTING 3.12.1 DIMENSIONS 240 mm x 181 mm x 42 mm (9.4” x 7.1” x 1.6”) 3.12.2 PANEL CUTOUT 220 mm x 160 mm (8.7” x 6.3”) 3.12.3 WEIGHT 0.7 kg (1.4 lb) -
Page 34: Fixing Clips
Specification 3.12.4 FIXING CLIPS NOTE: In conditions of excessive vibration, mount the module on suitable anti-vibration mountings. The module is held into the panel fascia using the supplied fixing clips. Withdraw the fixing clip screw (turn anticlockwise) until only the pointed end is protruding •... -
Page 35: Cable Tie Fixing Points
With Cable And Tie In Place 3.12.6 SILICON SEALING GASKET NOTE: For purchasing an additional silicon gasket from DSE, please see the section entitled Maintenance, Spares, Repair and Servicing elsewhere in this document. The optional silicon gasket provides improved sealing between module and the panel fascia. -
Page 36: Applicable Standards
Specification 3.12.7 APPLICABLE STANDARDS Standard Description This document conforms to BS4884-1 1992 Specification for BS 4884-1 presentation of essential information. BS 4884-2 This document conforms to BS4884-2 1993 Guide to content BS 4884-3 This document conforms to BS4884-3 1993 Guide to presentation BS EN 60068-2-1 -30 °C (-22 °F) (Minimum temperature) - Page 37 Specification Standard Description Continued 46 – Reverse-Phase Or Phase-Balance Current Relay 48 – Incomplete Sequence Relay 49 – Machine Or Transformer Thermal Relay 50 – Instantaneous overcurrent relay 51 – AC time overcurrent relay 52 – AC circuit breaker 53 – Exciter or DC generator relay IEEE C37.2 54 –...
-
Page 38: Enclosure Classifications
Specification 3.12.8 ENCLOSURE CLASSIFICATIONS 3.12.8.1 IP CLASSIFICATIONS The modules specification under BS EN 60529 Degrees of protection provided by enclosures IP65 (Front of module when module is installed into the control panel with the optional sealing gasket). IP42 (Front of module when module is installed into the control panel WITHOUT being sealed to the panel) First Digit Second Digit Protection against contact and ingress of solid objects... -
Page 39: Nema Classifications
Specification 3.12.8.2 NEMA CLASSIFICATIONS NOTE: There is no direct equivalence between IP / NEMA ratings. IP figures shown are approximate only. 3.12.8.3 THE MODULES NEMA RATING (APPROXIMATE) 12 (Front of module when module is installed into the control panel with the optional sealing gasket). 2 (Front of module when module is installed into the control panel WITHOUT being sealed to the panel) Provides a degree of protection against contact with the enclosure equipment and against a limited amount of falling dirt. -
Page 40: Installation
Installation 4 INSTALLATION The module is designed to be mounted on the panel fascia. To aid user connection, icons are used on the rear of the module to help identify terminal functions. An example of this is shown below. NOTE: Full details on terminals are given in the section entitled Terminal Description elsewhere in this manual. -
Page 41: Terminal Description
Installation 4.1 TERMINAL DESCRIPTION 4.1.1 DC SUPPLY & DC OUTPUTS NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. Cable Description Notes Size DC Plant Supply Input 2.5 mm² Connect to a good clean earth point. -
Page 42: Dsenet® & Msc
Installation 4.1.3 DSENET® & MSC NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: DO NOT CONNECT terminals 22 to 27 and 34 to 38 as they are not applicable. Cable... -
Page 43: Outputs C & D And V1 Voltage & Frequency Sensing
NOTE: The table below describes connections to a three phase, four wire V1 supply. For alternative wiring topologies, see section entitled Alternative AC Topology Wiring Diagrams elsewhere in this manual. NOTE: For further details on AC connection to the DSE8661 modules, see the section entitled Typical Wiring Diagram elsewhere in this document. Cable... -
Page 44: V2 Voltage & Frequency Sensing
NOTE: The table below describes connections to a three phase, four wire V2 supply. For alternative wiring topologies, see section entitled Alternative AC Topology Wiring Diagrams elsewhere in this manual. NOTE: For further details on AC connection to the DSE8661 modules, see the section entitled Typical Wiring Diagram elsewhere in this document. Cable... -
Page 45: Mains Current Transformers
L is the primary of the CT that ‘points’ towards the Load s1 is the secondary of the CT that connects to the DSE Module’s input for the CT measuring s2 is the secondary of the CT that should be commoned with the s2 connections of all the other CTs and connected to the CT common terminal of the module. -
Page 46: Digital Inputs A To K
Installation 4.1.7 DIGITAL INPUTS A TO K NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. Cable Description Notes Size 0.5 mm² Configurable Digital Input A AWG 20 0.5 mm² Configurable Digital Input B AWG 20 0.5 mm²... -
Page 47: Usb Slave (Pc Configuration) Connector
USB devices to the PC. For further information, consult the PC supplier. NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: The USB connection cable between the PC and the module must not be extended beyond 6 m (20 feet). -
Page 48: Rs232 Connector
Installation 4.1.10 RS232 CONNECTOR NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: For further details on how utilise an RS232 connection, refer to section entitled Communication Port Usage elsewhere in this document. -
Page 49: Rs485 Connector
NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: A 120 Ω termination resistor must be fitted across terminals A and B if the DSE module is the first or last device on the R485 link. -
Page 50: Ethernet Connector
Installation 4.1.12 ETHERNET CONNECTOR NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. Description Cable Notes Socket for connection to PC or network Ethernet Supports Modbus TCP protocol with DSE Configuration Suite Software... -
Page 51: Typical Diagrams
Generator manufacturers and panel builders may use these diagrams as a starting point; however, refer to the completed system diagram provided by the system manufacturer for complete wiring detail. Further wiring suggestions are available in the following DSE publications, available at www.deepseaplc.com to website members. DSE Part No... -
Page 52: Typical System Diagram
Installation 4.2.1 TYPICAL SYSTEM DIAGRAM NOTE: The DSE8661 module does NOT support multiple mains systems. -
Page 53: Typical Wiring Diagram (3 Phase, 4 Wire Star)
Installation 4.2.2 TYPICAL WIRING DIAGRAM (3 PHASE, 4 WIRE STAR) 4.2.2.1 MODULE INTER-CONNECTION RS485 TO RS485... -
Page 54: Module Inter-Connection Dsenet® To Rs485
Installation 4.2.2.2 MODULE INTER-CONNECTION DSENET® TO RS485... -
Page 55: Alternate Topologies
Installation 4.2.3 ALTERNATE TOPOLOGIES 4.2.3.1 SINGLE PHASE, 2 WIRE... -
Page 56: Phase (L1 & L2), 3 Wire Delta
Installation 4.2.3.2 2 PHASE (L1 & L2), 3 WIRE DELTA... -
Page 57: Phase (L1 & L3), 3 Wire Delta
Installation 4.2.3.3 2 PHASE (L1 & L3), 3 WIRE DELTA... -
Page 58: Phase, 3 Wire Delta
Installation 4.2.3.4 3 PHASE, 3 WIRE DELTA... -
Page 59: Phase, 4 Wire Delta
Installation 4.2.3.5 3 PHASE, 4 WIRE DELTA... -
Page 60: Earth Systems
(the battery negative connects to Earth) 4.2.4.2 POSITIVE EARTH When using a DSE module with a Positive Earth System (the battery positive connects to Earth), the following points must be followed: Follow the typical wiring diagram as normal for all sections EXCEPT the earth points •... -
Page 61: Typical Arrangement Of Dsenet
NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: A maximum of 20 DSENet® expansion modules can be connected to the DSE host module, made up of the following devices :... -
Page 62: Typical Arrangement Of Msc Link
Installation 4.4 TYPICAL ARRANGEMENT OF MSC LINK NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. NOTE: A maximum of 40 DSE8xxx series modules can be connected on the MSC link, made up of the following devices :... -
Page 63: Description Of Controls
Description Of Controls 5 DESCRIPTION OF CONTROLS CAUTION: The module may instruct a generator start event due to external influences. Therefore, it is possible for the generator to start at any time without warning. Prior to performing any maintenance on the system, it is recommended that steps are taken to remove the battery and isolate supplies. -
Page 64: Control Push-Buttons
Description Of Controls 5.1 CONTROL PUSH-BUTTONS NOTE: For further details, see section entitled ‘Operation’ elsewhere in this manual. Icon Description Stop / Reset Mode This button places the module into its Stop/Reset Mode . This clears any alarm conditions for which the triggering criteria have been removed. If the generator is running on load and the module is put into Stop/Reset Mode , the module automatically opens the generator bus breaker (‘Close Bus’... - Page 65 Description Of Controls NOTE: For further details, see section entitled ‘Operation’ elsewhere in this manual. Icon Description Auto Mode This button places the module into its Auto Mode . This mode allows the module to control the function of the system automatically. The module monitors various Start Signals and once a start request is made, sends a start request to the DSE8x10 module over the MSC Link.
- Page 66 Description Of Controls NOTE: For further details, see section entitled ‘Operation’ elsewhere in this manual. Icon Description Transfer to Mains The Transfer to Mains button control the operation of the mains load switching and is only active in Manual Mode once the generator bus is available.
- Page 67 Description Of Controls NOTE: For further details, see section entitled ‘Operation’ elsewhere in this manual. Icon Description Transfer to Generator Bus The Transfer to Generator Bus button control the operation of the mains load switching and is only active in Manual Mode once the generator bus is available.
-
Page 68: Viewing The Instrument
If no buttons are pressed upon entering an instrumentation page, the instruments displayed are automatically subject to the setting of the LCD Scroll Timer. The LCD Page and LCD Scroll timers are configurable using the DSE Configuration Suite Software or by using the Front Panel Editor. -
Page 69: Status
Auto Mode The contents of this display may vary depending upon configuration by the Generator manufacturer or supplier. The display above is achieved with the factory settings, shown below in the DSE Configuration suite software: ‘Stop Mode’ etc is displayed on the... -
Page 70: Mains
Description Of Controls 5.2.2 MAINS Contains electrical values of the mains (utility), measured or derived from the module’s (that controls the mains (utility) switch) voltage and current inputs. Press the Instrumentation Scroll buttons scroll through the Mains parameters. Mains Voltage (ph-N) •... -
Page 71: Bus
5.2.5 EXPANSION NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. Contains measured values from various input expansion modules that are connected to the DSE module. Press the Instrumentation Scroll buttons scroll through the Expansion parameters if configured. -
Page 72: Mains And Bus Alarms
Description Of Controls 5.2.6 MAINS AND BUS ALARMS NOTE: The Mains Alarms page displays alarms active in the module that controls the mains breaker. The Bus Alarms page displays alarms active in the module that controls the bus breaker. When an alarm is active, the Internal Audible Alarm sounds and the Common Alarm LED, if configured, illuminates. -
Page 73: Mains And Bus Event Logs
At the time of writing, the modules log is capable of storing the last 250 log entries. Under default factory settings, the event log is configured to include all possible options; however, this is configurable by the system designer using the DSE Configuration Suite software. Example showing the possible... -
Page 74: Serial Port
Description Of Controls 5.2.8 SERIAL PORT 5.2.8.1 RS232 SERIAL PORT This section is included to give information about the RS232 serial port and external modem (if connected). The items displayed on this page change depending upon configuration of the module. Refer to the system supplier for further details. -
Page 75: Connected To An Rs232 Gsm Modem
This is often a different number than the ‘voice number’ and is often called Circuit Switched Data (CSD) by the SIM provider. If the GSM modem is not purchased from DSE, ensure that it has been correctly set to operate at 9600 baud. -
Page 76: Modem Initialisation Sequence
Description Of Controls 5.2.8.1.3 MODEM INITIALISATION SEQUENCE 1) The modem attempts to communicate to the module 2) If the Modem and module communicate successfully: 3) In case of communication failure between the modem and module, the modem is automatically reset and initialisation is attempted once more: In the case of a module that is unable to communicate with the modem, the display continuously cycles between ‘Modem Reset’... -
Page 77: Connected To An Rs232 Modbus Master
2 seconds The DSE MODBUS document containing register mappings inside the DSE module is available upon request from support@deepseaplc.com. Email the request along with the serial number of the DSE... -
Page 78: Rs485 Serial Port
2 seconds. The DSE MODBUS document containing register mappings inside the DSE module is available upon request from support@deepseaplc.com. Email the request along with the serial number of the DSE module to ensure the correct information is sent. -
Page 79: About
Description Of Controls 5.2.10 ABOUT 5.2.10.1 MODULE INFORMATION Contains important information about the module and the firmware versions. This information may be asked for when contacting DSE Technical Support Department for advice. Variant (8661) • About Application Version – The version of the module’s •... -
Page 80: Ethernet
Whilst in the ‘ABOUT’ section, press the Scroll Down button to access more information about the network settings. Network settings change be configured using DSE Configuration Suite Software. The module must be rebooted for the changes to take effect. Network IP Address –... -
Page 81: Data Logging
Description Of Controls 5.2.10.3 DATA LOGGING Whilst in the ‘ABOUT’ section, press Scroll Down button to access more information about the data logging settings. Location of logged data. Displays either internal module memory or external USB memory. Data Logging Log to internal memory If data logging is active or inactive Logging active No USB drive present... -
Page 82: User Configurable Indicators
Description Of Controls 5.2.11 USER CONFIGURABLE INDICATORS These LEDs are configured by the user to indicate any one of 100+ different functions based around the following:- • Indications - Monitoring of a digital input and indicating associated functioning user’s equipment - Such as Battery Charger On, etc. -
Page 83: Operation
Operation OPERATION NOTE: The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to the configuration for the exact sequences and timers observed by any particular module in the field. 6.1 QUICKSTART GUIDE This section provides a quick start guide to the module’s operation. -
Page 84: Stopping The Generator
Operation 6.1.2 STOPPING THE GENERATOR Select Stop/Reset mode. The generator is requested to stop... -
Page 85: Stop/Reset Mode
MSC Link. When the Stop/Reset Mode , it is possible to send configuration files to the module from DSE Configuration Suite PC software and to enter the Front Panel Editor to change parameters. Any latched alarms that have been cleared are reset when Stop/Reset Mode is entered. -
Page 86: Manual Mode
6.3.1 STARTING SEQUENCE NOTE: There is no Start Delay in this mode of operation. NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. The starting sequence is controlled in the DSE8x10 module. -
Page 87: Loading Generator Bus
BUS MODE In this mode, the generator bus is used to provide a Fixed amount of active power (kW). This is set using the DSE Configuration Suite Software in SCADA | Bus | MSC Link | Load Parallel Power parameter. -
Page 88: Unloading Generator Bus
Operation 6.3.3 UNLOADING GENERATOR BUS Once the generator bus has been placed on load, it is not automatically removed. To manually remove the load either: Press the Transfer to Mains button • Press the Auto Mode button to return to automatic mode. The module observes all •... -
Page 89: Test Mode
6.4.1 STARTING SEQUENCE NOTE: There is no Start Delay in this mode of operation. NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. The starting sequence is then controlled in the DSE8x10 module. -
Page 90: Loading Generator Bus
BUS MODE In this mode, the generator bus is used to provide a Fixed amount of active power (kW). This is set using the DSE Configuration Suite Software in SCADA | Bus | MSC Link | Load Parallel Power parameter. -
Page 91: Unloading Generator Bus
Operation 6.4.3 UNLOADING GENERATOR BUS The generator bus load switch is not automatically opened. To manually open the generator bus load switch: Press the Manual Mode button followed by the Transfer to Mains button • Press the Auto Mode button. The module observes all Auto Mode start requests •... -
Page 92: Automatic Mode
Operation 6.5 AUTOMATIC MODE NOTE: If a digital input configured to Panel Lock is active on either module, changing modes on both modules is not possible. Viewing the instruments and event logs is NOT affected by panel lock. Auto Mode is activated by pressing the Auto Mode button. -
Page 93: Generator Bus Available
BUS MODE In this mode, the generator bus is used to provide a Fixed amount of active power (kW). This is set using the DSE Configuration Suite Software in SCADA | Bus | MSC Link | Load Parallel Power parameter. -
Page 94: Unloading Generator Bus
Operation 6.5.4 UNLOADING GENERATOR BUS The generator bus load switch is automatically opened. To manually open the generator bus load switch: Press the Auto Mode button. The module observes all Auto Mode start requests • and stopping timers before beginning the Auto Mode Stopping Sequence. Press the Manual Mode button followed by the Transfer to Mains button... -
Page 95: Scheduler
Up to 16 scheduled start/stop sequences can be configured to repeat on a 7-day or 28-day cycle. Scheduled runs may be island, off load or parallel depending upon module configuration. Example Screen capture from DSE Configuration Suite Software showing the configuration of the Exercise Scheduler. -
Page 96: Test Mode
Operation 6.6.3 TEST MODE Scheduled runs do not occur when the module is in Test Mode waiting for a start • request. If a scheduled run configured to ‘Island’ begins when the module is in Manual Mode • generator bus is available and in constant parallel, the generator bus is placed in island mode operation. -
Page 97: Multiple Mains Operation
Operation 6.7 MULTIPLE MAINS OPERATION NOTE: The DSE8661 module does NOT support multiple mains systems. -
Page 98: Protections
Protections 7 PROTECTIONS NOTE: The Mains Alarms page displays alarms active in the module that controls the mains breaker. The Bus Alarms page displays alarms active in the module that controls the bus breaker. When an alarm is active, the Internal Audible Alarm sounds and the Common Alarm LED, if configured, illuminates. -
Page 99: Indications
Protections 7.1 INDICATIONS Indications are non-critical and often status conditions. They do not appear on the LCD of the module as a text message. However, an output or LED indicator is configured to draw the operator’s attention to the event. Example Input configured for •... -
Page 100: Warning Alarms
Protections 7.2 WARNING ALARMS NOTE: For further details of module configuration, refer to DSE Publication: 057-215 DSE8661 Configuration Suite Software Manual. Warnings are non-critical alarm conditions and do not affect the operation of the system, they serve to draw the operators attention to an undesirable condition. - Page 101 Minimum Sets Not Reached before the end of the timer, the LCD indicates Minimum Number of Sets Not Reached. If the data link between the two DSE8661 modules breaks, then the Module Comms Fail LCD indicates Module Comms Fail If an input has been configured as MSC Alarms Inhibit and is active, MSC Alarms Inhibited the LCD indicates MSC Alarms Inhibit.
-
Page 102: Electrical Trip Alarms
Protections 7.3 ELECTRICAL TRIP ALARMS NOTE: The alarm condition must be rectified before a reset takes place. If the alarm condition remains, it is not possible to reset the unit. Electrical Trip alarms are latching and stop the generator bus but in a controlled manner. On initiation of the Electrical Trip condition the module de-energises all the Close Bus output to remove the load from the generator bus. - Page 103 MSC Failure If the MSC link breaks, the LCD indicates MSC Failure If the module detects that there is one or more DSE controller MSC Old Version Unit On connected to the MSC link that are not compatible with the module (for...
-
Page 104: Mains Decoupling Alarms
Protections 7.4 MAINS DECOUPLING ALARMS NOTE: These protections only operate only when the mains and generator bus are in parallel, it is disabled at all other times. When the mains (utility) and the generator bus supplies are in parallel, the module monitors for a Mains failure by detecting ROCOF or Vector Shift fault which are set in the module’s configuration. -
Page 105: Front Panel Configuration
This configuration mode allows the operator to fully configure the module through its display without the use of the DSE Configuration Suite PC Software. Use the module’s facia buttons to traverse the menu and make value changes to the parameters:... -
Page 106: Main Configuration Editor
8.1.2 ENTERING PIN NOTE: The PIN is not set by DSE when the module leaves the factory. If the module has a PIN code set, this has been affected by the panel supplier who should be contacted if the code is required. -
Page 107: Editing A Parameter
Front Panel Configuration 8.1.3 EDITING A PARAMETER NOTE: Pressing and holding the Instrumentation Scroll buttons gives an auto- repeat functionality. Values can be changed quickly by holding the navigation buttons for a prolonged period of time. Press the Next or Previous Page buttons to cycle to the section which is required to be •... -
Page 108: Available Parameters To Be Edited
Front Panel Configuration 8.1.5 AVAILABLE PARAMETERS TO BE EDITED Functionality in DSE8661 ‘Bus Breaker’ and ‘Mains Breaker’ controller Functionality in DSE8661 ‘Bus Breaker’ controller only Functionality in DSE8661 ‘Mains Breaker’ controller only Section Parameter As Shown On Display Setting Display... -
Page 109: Running' Configuration Editor
• 8.2.2 ENTERING PIN NOTE: The PIN is not set by DSE when the module leaves the factory. If the module has a PIN code set, this has been affected by the panel supplier who should be contacted if the code is required. -
Page 110: Exiting The 'Running' Configuration Editor
• 8.2.5 AVAILABLE PARAMETERS TO BE EDITED Functionality in DSE8661 ‘Bus Breaker’ and ‘Mains Breaker’ controller Functionality in DSE8661 ‘Bus Breaker’ controller only Functionality in DSE8661 ‘Mains Breaker’ controller only Section... -
Page 111: Commissioning
Mains controller and the other as the Bus controller. Use the DSE Configuration Suite to check this in the SCADA | STATUS page. Check the operation of the MSC Link. Use the DSE Configuration Suite to check this in the •... -
Page 112: Dse 4 Steps To Successful Synchronising
NOTE: Failure of these steps results in serious damage to the system (breakers, bus bars, alternators, engines etc) Check each phase across the breakers controlled by the DSE8661 and DSE8x10 modules are wired correctly: Use the Built in Sync Scope to Determine Correct Phase Wiring •... -
Page 113: Fault Finding
Signal is on “Remote Start” input. Confirm correct • Generator fail to start on configuration of input is configured to be used as “Remote receipt of Remote Start Start”. signal. MSC link operation • The DSE8661 and DSE8x10 modules are in Auto Mode •... -
Page 114: Instruments
Fault Finding 10.2 INSTRUMENTS Symptom Possible Remedy Check: That the CT primary, CT secondary and VT ratio settings are • correct for the application. That the CTs are wired correctly with regards to the direction • of current flow (p1,p2 and s1,s2) and additionally ensure that CTs are connected to the correct phase (errors occur if CT1 is connected to phase 2). -
Page 115: Communications
Ethernet comms direct to PC Direct to PC connection requires a CROSSOVER cable. • inoperative Check the IP address of the DSE controller is correct • Check the PC is not set to obtain IP address automatically • Check PC firewall allows traffic on the configured port. -
Page 116: Miscellaneous
Fault Finding 10.5 MISCELLANEOUS Symptom Possible Remedy When editing a configuration using the PC software it is vital that the configuration is first ‘read’ from the controller before editing it. This edited configuration must then be “written” back to the controller for the changes to take effect. -
Page 117: Maintenance, Spares, Repair And Servicing
The controller is Fit and Forget. As such, there are no user serviceable parts within the controller. In the case of malfunction, contact the original equipment manufacturer (OEM). 11.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE If additional plugs are required from DSE, please contact our Sales department using the part numbers below. 11.1.1 PACK OF PLUGS... -
Page 118: Purchasing Additional Sealing Gasket From Dse
11.4 DSENET® EXPANSION MODULES NOTE: DSE recommend Belden 9841 (or equivalent) cable for DSENet® communication. This is rated to a maximum cable length of 1.2 km. DSE Stock Belden 9841 cable, DSE Part Number: 016-030. NOTE: A maximum of 20 DSENet® expansion modules can be connected to the DSE host... -
Page 119: Warranty
Warranty & Disposal 12 WARRANTY DSE provides limited warranty to the equipment purchaser at the point of sale. For full details of any applicable warranty, refer to the original equipment supplier (OEM). 13 DISPOSAL 13.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT) If you use electrical and electronic equipment you must store, collect, treat, recycle and dispose of WEEE separately from your other waste. - Page 120 This Page is Intentionally Left Blank...
Need help?
Do you have a question about the DSE8661 and is the answer not in the manual?
Questions and answers
