Summary of Contents for Vertiv Liebert APM 300

  • Page 3: User Manual

    APM 300 Integrated UPS Single Module And Parallel System User Manual Version V1.5 Revision date March 10, 2017 31012521 Emerson Network Power provides customers with technical support. Users may contact the nearest Emerson local sales office or service center. Copyright © 2011 by Emerson Network Power Co., Ltd. All rights reserved.
  • Page 4: Product Safety

    Special Declaration Personnel Safety 1. This product must be installed and commissioned by professional engineers of the manufacturer or its authorized agent. Failure to observe this could result in product malfunction or personnel safety risk. 2. Take the time to read this product manual and the safety precaution thoroughly before installing and commissioning this product.
  • Page 5: Safety Precaution

    Safety Precaution Always observe the following safety symbols! Used to alert the user to the risk of death or severe injury should the unit be used improperly. Used to alert the user to the risk of injury or equipment damage should the unit be used improperly. Used to advise the user to carefully read and observe this unit though it may not cause damage.
  • Page 6 Warning: high leakage current Earth connection is essential before connecting the input supply (including the AC mains and battery). The UPS must be earthed in accordance with local electrical codes. Earth leakage current exceeds 3.5mA and is less than 3000mA. Transient and steady state earth leakage currents, which may occur when the equipment is started, should be taken into account when selecting instantaneous RCCB or RCD devices.
  • Page 7 The Manual Covers The Following Equipment Product Model APM 300 Liebert APM 300...
  • Page 8 Revision Information V1.0 (August 17, 2011) Initial release. V1.1 (April 3, 2014) Adopt new manual format with options added; add Hazardous Substances Or Elements Announcement in Appendix 2. V1.2 (October 10, 2014) Change the address of Emerson Network Power Co., Ltd.; add Frequency converter mode, Dual bus (LBS) system mode, and ECO mode in Section 1.5;...
  • Page 10: Table Of Contents

    Contents Chapter 1 Overview ..............................1 1.1 Features................................. 1 1.2 Composition ..............................1 1.3 Design Concept .............................. 2 1.3.1 System Design ............................. 2 1.3.2 Bypass ..............................2 1.3.3 System Control Principle ........................3 1.3.4 UPS Power Supply Switch Configuration ....................4 1.3.5 Battery Circuit Breaker (BCB) .........................
  • Page 11 3.1.5 Power Cable Connecting Terminals .......................18 3.1.6 Protection Ground ..........................18 3.1.7 External Protective Device ........................18 3.1.8 Connecting Power Cables ........................19 3.1.9 Connecting External Power Cables ......................20 3.2 Control Cables And Communication Cables ....................22 3.2.1 Overview ............................22 3.2.2 Input Dry Contact Port .........................23 3.2.3 BCB Port .............................23 3.2.4 Maintenance Bypass Switch And Output Switch State Port ..............24 3.2.5 Output Dry Contact Port ........................24...
  • Page 12 5.7 EPO Procedures .............................43 5.8 UPS Reset Procedures After EPO ........................43 5.9 Automatic Restart ............................44 5.10 Selecting Language .............................44 5.11 Changing The Current Date And Time ......................44 5.12 Command Password ............................44 Chapter 6 Battery ..............................45 6.1 Introduction..............................45 6.2 Safety ................................45 6.3 Power Cable ..............................46 6.3.1 Overview ............................46 6.3.2 Battery Installation ..........................47...
  • Page 13 8.2.4 SIC Card ..............................63 8.2.5 Relay Card............................64 8.2.6 UF-RS485 Card ............................67 8.2.7 Modbus Card ............................68 8.2.8 LBS Cable ............................68 8.2.9 Parallel Cable ............................68 Chapter 9 Communication ............................69 9.1 SNMP Protocol Communication ........................69 9.2 Modbus Protocol Communication ........................69 9.3 Dry Contact Communication..........................69 Chapter 10 Service And Maintenance ........................70 10.1 Safety .................................70 10.2 Service Procedures Of Power Module And Bypass Module ................70...
  • Page 14: Chapter 1 Overview

    Chapter 1 Overview This chapter briefly introduces the features, composition, design concept, parallel system, operation mode, battery management and battery protection of the Liebert APM 300 UPS (UPS for short). 1.1 Features The UPS is connected between a critical load (e.g. a computer) and mains power to provide high quality power for the loads.
  • Page 15: Design Concept

    Chapter 1 Overview Table 1-1 UPS component configuration Component Quantity (pcs) Remark Main power cabinet Standard component Switch cabinet Standard component Bypass module Standard component Power module 1 ~ 10 Mandatory option. Installed at site 1.3 Design Concept 1.3.1 System Design As shown in Figure 1-2, the AC mains source is converted by the rectifier into DC power.
  • Page 16: System Control Principle

    Chapter 1 Overview A manually controlled, maintenance bypass supply is incorporated into the UPS design. It enables the critical load to be powered from the maintenance bypass supply while the UPS is shut down for routine maintenance and repair. Note When the UPS is operating in bypass mode or on maintenance bypass, the connected equipment is not protected from power failures or surges and sags.
  • Page 17: Ups Power Supply Switch Configuration

    Chapter 1 Overview the inverter will shut down. Five minutes later, the inverter will start up automatically. If the short circuit is removed at this point, the load will be transferred back to the inverter. The transfer is determined first of all by the features of the protective device of the system.
  • Page 18: Battery Circuit Breaker (Bcb)

    Chapter 1 Overview 1.3.5 Battery Circuit Breaker (BCB) The external battery shall be connected to the UPS through the BCB. The BCB box is an option, which shall be installed near the battery. The BCB is closed manually or electrically. The BCB has undervoltage tripping coil. Upon the battery undervoltage, the UPS control circuit will send a signal to the coil to trip the BCB.
  • Page 19: Parallel System Requirements

    Chapter 1 Overview 1.4.2 Parallel System Requirements A UPS system consisting of two paralleled UPS modules behave as if it were one large UPS with the advantage of presenting higher reliability. To ensure that all modules are equally used and to comply with relevant wiring rules, the following requirements apply: 1.
  • Page 20 Chapter 1 Overview Rectifier Inverter Automatic inverter switch Rectifier Inverter Automatic inverter switch UPS output UPS output Output switch Output switch Battery Battery Figure 1-6 Schematic diagram of battery mode Note: Battery start function is available for switching the UPS on into Battery (charged) mode directly during mains failure.
  • Page 21 Chapter 1 Overview ECO mode As shown in Figure 1-9, in ECO mode, except for the maintenance bypass switch, all power switches and the BCB are closed, the system prefers to put the load on the bypass mains to save energy. When the bypass frequency and voltage are in normal range (settable), the load is supplied by the bypass, with the inverter on standby.
  • Page 22: Battery Management (Set By Commissioning Engineer)

    Chapter 1 Overview Common battery mode Common battery function means that in UPS paralleling, the UPS modules can share a battery string to save cost and space and improve efficiency. Note Batteries of different manufacturers, models or used time cannot be used together. Frequency converter mode The UPS can be programmed into frequency converter mode for either 50Hz or 60Hz stable output frequency.
  • Page 23: Battery Temperature Compensation

    Chapter 1 Overview Trigger: manually through the command of Battery Maintenance Test on LCD or automatically. Interval: 30 days ~ 360 days (default setting: 60 days). 1.6.3 Battery Temperature Compensation The UPS system has battery charge temperature compensation function. When the ambient temperature is increased, the DC bus voltage (which charges the battery) will be reduced correspondingly to provide optimal charging voltage for the battery, thus prolonging the battery service life time.
  • Page 24: Chapter 2 Mechanical Installation

    Chapter 2 Mechanical Installation Chapter 2 Mechanical Installation This chapter introduces the installation of the UPS, including the notes, preliminary check, environmental considerations, mechanical considerations, and installation drawings. 2.1 Notes This chapter describes the requirements that must be taken into account when installing the UPS equipment. Because each site has its particular characteristics, this chapter does not provide the detailed installation steps, it only acts as a guide for the general procedures and practices that should be observed by the installing engineer, so that they can properly handle the specific situation of the site.
  • Page 25: Battery Location

    Chapter 2 Mechanical Installation Enough space to easily work on the UPS  Sufficient air exchange to dispel heat produced by UPS  Protection against atmospheric agents  Protection against excessive humidity and high heat sources  Protection against dust ...
  • Page 26: Positioning

    Chapter 2 Mechanical Installation 2.4 Positioning 2.4.1 Moving The Cabinet Warning 1. Ensure that any equipment used to move the UPS has sufficient lifting capacity. For the UPS weight, refer to Table 11-3. 2. The UPS is fitted with casters. Take care to prevent the cabinet from moving when unbolting the cabinet from the shipping pallet.
  • Page 27: Mechanical Connection Between Cabinets

    Chapter 2 Mechanical Installation 1100 1100 Main power Switch cabinet Main power Switch cabinet cabinet cabinet Front view Side view Front view Side view Back door Back door 1200 1200 Cover Cover Cover Cover Main power Switch Main power Switch cabinet cabinet cabinet...
  • Page 28: Installing Power Module

    Chapter 2 Mechanical Installation positions of each beam, there are also two screw holes for cabinet connection. Use the accessory M8 × 20 screws to connect the two cabinets through these screws holes, and tighten the connections to 13N.m. Screw hole for cabinet connection Beam Figure 2-2 Screw holes for cabinet connection on main power cabinet 2.5.3 Installing Power Module...
  • Page 29 Chapter 2 Mechanical Installation 1. Use the DIP switch on the front panel of the module to set the module address. The setting range is from 1 to 10. The module address should be exclusive. The setting method is shown in Table 2-1. Table 2-1 DIP switch setting method DIP switch setting Module address...
  • Page 30: Chapter 3 Electrical Installation

    Chapter 3 Electrical Installation Chapter 3 Electrical Installation This chapter introduces the electrical installation of the UPS, including the procedures or methods for power cabling and control cabling, the distance from floor to connection point, and the connection of cabinets. The UPS requires both power cabling and control cabling once it has been mechanically installed.
  • Page 31: Distance From Floor To Ups Connection Point

    Chapter 3 Electrical Installation 1. Rectifier and bypass input mains current. 2. Non-linear loads (switch mode power supplies) affect the design of the output and bypass neutral cables. The current circulating in the neutral cable may exceed the nominal phase current. A typical value is 1.732 times the rated current. 3.1.3 Distance From Floor To UPS Connection Point Table 3-2 provides the distances from the floor to the UPS connection points.
  • Page 32: Connecting Power Cables

    Chapter 3 Electrical Installation for the installation engineer. The qualified installation engineer should have the knowledge of the local wiring regulations on the equipment to be installed. Rectifier and bypass input supply of the UPS 1. Overcurrent Install suitable protective devices in the distribution of the incoming mains supply, considering the power cable current-carrying capacity and overload capacity of the system (see Table 11-6, Table 11-7).
  • Page 33: Connecting External Power Cables

    Chapter 3 Electrical Installation 4. Use a multimeter to measure and confirm that the connections are correct and no inter-phase short circuit exists. 5. Bind the parallel power cables. 6. Replace the cover and left side panel of the main power cabinet removed in step 1 and the cover at the front of the switch cabinet removed in the procedures in 2.5.2 Mechanical Connection Between Cabinets.
  • Page 34 Chapter 3 Electrical Installation Rectifier input terminal Rectifier input terminal mA mB mC mN mA mB mC mN A Amplified view A amplified view bA bB bC bA bB Bypass input terminal Bypass input terminal oA oB oC oA oB oC Output terminal Output terminal B Amplified view...
  • Page 35: Control Cables And Communication Cables

    Chapter 3 Electrical Installation 6. Connect the system output cables between the UPS output terminals (oA-oB-oC-oN) and the critical load, and tighten the connections to 50N.m. Ensure correct phase rotation. Warning If the load is not ready to accept power on the arrival of the commissioning engineer, ensure that the system output cables are safely isolated at their ends.
  • Page 36: Input Dry Contact Port

    Chapter 3 Electrical Installation 3.2.2 Input Dry Contact Port The input dry contact ports J7 and J8 provide battery room environment, battery ground fault and battery temperature signals. The ports are shown in Figure 3-4 and described in Table 3-3. Figure 3-4 Input dry contact ports J7 and J8 Table 3-3 Description of input dry contact ports J7 and J8 Position...
  • Page 37: Maintenance Bypass Switch And Output Switch State Port

    Chapter 3 Electrical Installation AUx-N.O. AUx-N.O. AUx-N.O. AUx-N.O. Figure 3-6 Connection between BCB port and BCB 3.2.4 Maintenance Bypass Switch And Output Switch State Port J9 is the maintenance bypass switch and output switch state port. The port is shown in Figure 3-7 and described in Table 3-5.
  • Page 38: Remote Epo Input Port

    Chapter 3 Electrical Installation Table 3-6 Description of output dry contact port Position Name Description J5.2 BFP_O Bypass feedback protection relay (normally open), closed when bypass SCR is shorted J5.3 BFP_S Bypass feedback protection relay center J5.4 BFP_C Bypass feedback protection relay (normally closed), open when bypass SCR is shorted 3.2.6 Remote EPO Input Port The UPS has the EPO function that operates by a switch on the operator control and display panel of the UPS or by a remote contact provided by the user.
  • Page 39: Chapter 4 Operator Control And Display Panel

    Chapter 4 Operator Control And Display Panel Chapter 4 Operator Control And Display Panel This chapter expounds the functions and use of the components on the operator control and display panel of the UPS, and provides LCD display information, including the LCD screen types, detailed menu messages, prompt windows and alarm list.
  • Page 40: Audible Alarm (Buzzer)

    Chapter 4 Operator Control And Display Panel Table 4-2 Description of indicators Indicator State Description Solid green Rectifiers in normal operation Flashing green Mains input normal, but rectifiers not operating Rectifier indicator Solid red Rectifiers failed Rectifiers not operating, mains input abnormal Solid green Load on battery Flashing green...
  • Page 41: Lcd And Menu Keys

    Chapter 4 Operator Control And Display Panel 4.1.4 LCD And Menu Keys The operator control and display panel provides an LCD and five menu keys (F1, F2, F3, F4, and F5). The menu keys are described in Table 4-5. Table 4-5 Description of menu keys Function 1 Function 1 HOME...
  • Page 42: Default Screen

    Chapter 4 Operator Control And Display Panel APM 300 System information window 12: 30: 36 L 1-N/L2 L2-N/L 3 L 3-N/L1 L-N voltage (V) 220.6 220.0 220.0 L-N current (A) Frequency (HZ) 50.1 50.1 50.1 Data window L-L voltage (V) 381.5 381.0 381.5...
  • Page 43: Detailed Description Of Menu Items

    Chapter 4 Operator Control And Display Panel Figure 4-5 Default screen 4.3 Detailed Description Of Menu Items The description that follows refers to the LCD primary screen shown on Figure 4-3. System information window The system information window displays the current time and UPS name. This window requires no user operation.
  • Page 44 Chapter 4 Operator Control And Display Panel Menu Item Explanation Sout (kVA) Sout: apparent power Pout (kW) Pout: active power Load Qout (kVAR) Qout: reactive power Load level (%) The percentage of the UPS rating load Crest factor Output current crest factor Sout (kVA) Sout: apparent power System...
  • Page 45: Prompt Window

    Chapter 4 Operator Control And Display Panel Menu Item Explanation Battery maintenance This test performs a partial discharge of the battery to obtain a rough test estimate of the battery capacity. Load must be between 20% and 100% Command This test performs a full discharge of the battery to obtain a precise (initiate, stop Battery capacity test measure of the battery capacity.
  • Page 46 Chapter 4 Operator Control And Display Panel Table 4-9 Alarm list Alarm Explanation Comm. fail The communication of the internal monitor with the rectifier, inverter or bypass failed The communication between the inverters of each UPS in the parallel system failed. 1.
  • Page 47 Chapter 4 Operator Control And Display Panel Alarm Explanation This alarm is triggered by an inverter software routine when the inverter and bypass waveforms are misaligned by more than six degrees in phase. The amplitude threshold is fixed for ±10% rating. This alarm resets automatically once the condition is no longer Inverter Asynchronous true.
  • Page 48 Chapter 4 Operator Control And Display Panel Alarm Explanation A transfer to bypass occurred due to a large step load. The UPS can recover automatically. Load Impact Transfer Turn on the load equipment in stages to reduce the load impact on the inverter The load remains on bypass power owing to excessive number of transfers that occurred Transfer Time-out within the last hour.
  • Page 49 Chapter 4 Operator Control And Display Panel Alarm Explanation Battery Maintenance The user initiated a maintenance test (20% capacity discharge) Testing Inverter in Setting The inverter starts up and is in synchronization Rectifier in Setting The rectifier starts up and is in synchronization Battery room alarm The temperature in the battery room is high and needs to be attended BCB open...
  • Page 50: Chapter 5 Operating Instructions

    Chapter 5 Operating Instructions Chapter 5 Operating Instructions This chapter provides detailed operating procedures of the UPS. 5.1 Brief Introduction 5.1.1 Precautions Important The user can conduct relative operation only after the authorized engineer carries out the first power on and test. Warning: hazardous mains and/or battery voltage 1.
  • Page 51: Ups Start-Up Procedures

    Chapter 5 Operating Instructions Rectifier input switch Bypass input switch Maintenance bypass switch Output switch Figure 5-1 Positions of power switches 5.2 UPS Start-Up Procedures Before startup, the UPS must be fully installed and commissioned, and the external input switch must be closed.
  • Page 52: Start-Up Procedures Into Battery Mode (Battery Cold Start)

    Chapter 5 Operating Instructions Indicator State Status indicator Yellow 2. Press and hold the INVERTER ON key for two seconds. Note You must close the UPS output switch first, then close the bypass input switch and rectifier input switch, and finally turn on the inverters.
  • Page 53: Procedures For Transfer Between Operation Modes

    Chapter 5 Operating Instructions 3. Press and hole the INVERTER ON key for two seconds, and the UPS operates in battery mode. 5.3 Procedures For Transfer Between Operation Modes 5.3.1 Transfer From Normal Mode To Battery Mode Open the rectifier input switch to cut off the mains input, and the UPS enters battery mode. To return to normal mode, wait a few seconds and close the rectifier input switch to connect the mains power to the UPS.
  • Page 54: Battery Test Mode Procedures

    Chapter 5 Operating Instructions Caution 1. The load is not protected from normal supply aberrations when the UPS is operating in maintenance mode. 2. After the UPS is transferred to maintenance bypass, the power modules and bypass module are inoperative and the LCD has no display, only the green indicator of the input SPD shows the UPS has mains input, but the output terminals corresponding to closed output distribution switches and the neutral bars are energized.
  • Page 55: System Test Procedure

    Chapter 5 Operating Instructions 5.5 System Test Procedure The UPS test procedure checks the control functions of the UPS, the mimic flow chart LEDs and the audible alarm. This self-test is password controlled and menu driven. It can be carried out from the operator control and display panel by the operator and takes 5 seconds.
  • Page 56: Procedures For Completely Powering Down Ups While Maintaining Power To Load

    Chapter 5 Operating Instructions 5.6.2 Procedures For Completely Powering Down UPS While Maintaining Power To Load Caution Ensure that the UPS has been installed with an external maintenance bypass cabinet before carrying out these procedures. The following procedures are applicable for completely powering down the UPS and still keeping the power supply to the load.
  • Page 57: Automatic Restart

    Chapter 5 Operating Instructions 5.9 Automatic Restart In the case of a mains failure, the UPS draws power from the battery system to supply the load until the batteries are depleted. When the UPS reaches its end of EOD threshold, it will shut down. The UPS will automatically restart and enable output power: After the mains power is restored ...
  • Page 58: Chapter 6 Battery

    Chapter 6 Battery Chapter 6 Battery This chapter introduces the relevant information of the battery, including the introduction, safety, power cables, maintenance, recycling, reference current and connection of external BCB. 6.1 Introduction The UPS battery string consists of batteries connected in series to provide rated DC input voltage for the UPS inverters.
  • Page 59: Power Cable

    Chapter 6 Battery Warning: battery hazard inspected and tightened at least once a year. Failure to observe this may cause fire! b) Inspect the battery appearance before accepting and using the battery. If there exist any package damage, dirty battery terminal, terminal erosion, rust, or enclosure crack, deformation or electrolyte leakage, replace it with new product.
  • Page 60: Battery Installation

    Chapter 6 Battery 6.3.2 Battery Installation 1. Before installation, check the battery appearance to ensure that there is no damage, inspect and count the accessories, and carefully read this manual and the user manual or installation instruction provided by the battery manufacturer.
  • Page 61: Reference Current And Connection Of External Bcb

    Chapter 6 Battery 6.4 Reference Current And Connection Of External BCB Table 6-1 provides the maximum battery discharge current at full load and the reference BCB rated current. Refer to IEC60950-1 Table 3B and follow the local electrical regulations to select the CSA. Table 6-1 Maximum battery discharge current at full load and reference BCB rated current UPS rated power (kVA) Item...
  • Page 62 Chapter 6 Battery Figure 6-2 Connections between battery, BCB and UPS (4 wires at battery side) Figure 6-3 Connections between battery, BCB and UPS (3 wires at battery side, battery consisting of 30 to 34 cells) Figure 6-4 Connections between battery, BCB and UPS (3 wire at battery side, battery consisting of 36 to 40 cells) If you select the BCB box (containing a BCB and a BCB control board) made by Emerson, you need to modify the BCB box and connect the BCB box with the battery and UPS according to Figure 6-5.
  • Page 63: Battery Maintenance

    Chapter 6 Battery Temp sensor TPM2 X100 X103 OUT-P 220Vdc Battery OUT-N X104 AUX1 X105 AUX2 X106 Auxiliary Bypass module contactor BCB control board UHW241C2 X101 X108 X102 +12V +12V BAT-T BAT-T GND2 GND1 Figure 6-5 Connections between UPS, BCB and BCB control board 6.5 Battery Maintenance For the battery maintenance and maintenance precautions, refer to IEEE-Std-1188-2005 and the relevant manuals provided by the battery manufacturer.
  • Page 64 Chapter 6 Battery According to the relevant national regulations, the disused lead-acid storage battery must be recycled and shall not be disposed of with other methods. Random discard or any other improper disposal of the disused lead-acid storage battery may cause severe environment pollution and the relevant person will be investigated of corresponding legal responsibilities.
  • Page 65: Chapter 7 Parallel System And Dual Bus System

    Chapter 7 Parallel System And Dual Bus System Chapter 7 Parallel System And Dual Bus System This chapter details the installation and wiring of the parallel system and dual bus system. 7.1 Overview Two UPSs can be connected in parallel to form a 1 + 1 parallel system (parallel system for short). 7.2 System Installation Procedures The basic installation procedure of a parallel system comprising two or more UPS modules is the same as that of single module system.
  • Page 66: External Protective Device

    Chapter 7 Parallel System And Dual Bus System Supplied by others Input mains supply Input mains supply L1,L2,L3,N L1,L2,L3,N UPS1 UPS2 Rectifier Rectifier Fuse Fuse Charger Charger Battery1 Inverter Battery2 Inverter L1,L2,L3,N L1,L2,L3,N Q2EXT Q1EXT QUPS QBYP Output distribution To load Figure 7-1 Schematic diag.
  • Page 67: Remote Epo

    Chapter 7 Parallel System And Dual Bus System UPS 2 UPS 1 UPS 2 UPS 1 Parallel control cable Parallel control cable Parallel control cable Parallel control cable Figure 7-2 Connection of parallel control cables of parallel system Figure 7-3 Locations of ports J2, J3 and J4 on bypass module 7.2.6 Remote EPO In addition to the EPO switch provided on the operator control and display panel of each UPS module for controlling the EPO of each module respectively, the parallel system also provides remote EPO function for...
  • Page 68: Operation Procedures For Parallel System

    Chapter 7 Parallel System And Dual Bus System UPS1 UPS1 J10:3 J10:3 J10:4 Bypass module Bypass module J10:4 UPS2 UPS2 J10:3 J10:3 Bypass module Bypass module J10:4 J10:4 J10:3 J10:3 J10:4 J10:4 UPS1 UPS1 Bypass module Bypass module Figure 7-4 EPO circuit diagram 7.3 Operation Procedures For Parallel System Warning If UPS input uses RCD, differential switch is only used in the system's bypass mains supply.
  • Page 69: Maintenance Bypass Procedures

    Chapter 7 Parallel System And Dual Bus System 7.3.2 Maintenance Bypass Procedures Warning If the UPS system is composed of more than 2 parallel UPS modules, and the load capacity exceeds the single module capacity, do not use the internal maintenance bypass switch. This operation will make the load transfer from UPS power supply protection state to direct connection with AC input bypass state.
  • Page 70: Procedures For Completely Powering Down Ups

    Chapter 7 Parallel System And Dual Bus System 7.3.5 Procedures For Completely Powering Down UPS Complete UPS shutdown and load power-off should follow this procedure. All power switches, isolating switches and breakers are disconnected, and then UPS no longer supplies power to the load. Caution The following procedures will cut off the load power, making the load completely power off.
  • Page 71: External Protective Device

    Chapter 7 Parallel System And Dual Bus System The dual bus system uses the LBS to keep the output of the two independent UPS systems (or parallel systems) in synchronization. One system is designated as the master, the other is designated as the slave. The operation modes of the parallel system comprise master and/or slave operation in normal or bypass mode.
  • Page 72 Chapter 7 Parallel System And Dual Bus System UPS 2 UPS 1 UPS 1 UPS 2 Bypass module Bypass module Bypass module Bypass module Figure 7-8 Connection of typical dual bus system of two single UPSs with redundancy LBS cable APM 300 Integrated UPS Single Module And Parallel System User Manual...
  • Page 73: Chapter 8 Options

    Chapter 8 Options Chapter 8 Options This chapter provides the UPS option list, and introduces the functions, installation and configuration of each option. 8.1 Option List Table 8-1 lists all of the UPS options. Table 8-1 Option list Option Model Part No.
  • Page 74 Chapter 8 Options Checking installation materials Check that all installation materials are present and complete, including three bypass load sharing inductors LA, LB and LC; cables W63, W64, W65, W66, W67 and W68; six M10 × 30 screws; six flat washers; six spring washers;...
  • Page 75: Battery Temperature Sensor

    Chapter 8 Options Base plate Base plate Back view Back view Figure 8-2 Installation positions of inductors Connections 1. Connect the cables W63, W64 W65, W66, W67 and W68 between the copper bars Q2-A, Q2-B, Q2-C, ZA, ZB, ZC and the inductors LA, LB and LC, as shown in Figure 8-3. Use six M10 × 30 screws, six flat washers, six spring washers and six M10 nuts to connect the cables to the inductors, and use the screws and nuts removed in step 4 to connect the cables to the copper bars.
  • Page 76: Air Filter

    Chapter 8 Options 2. Check that all installation materials are present and complete, including a battery temperature sensor. Procedures Warning 1. Connect the cables strictly following the instructions. Failure to observe this may cause damage to the UPS and the battery.
  • Page 77: Relay Card

    Chapter 8 Options 1. Remove the cover of Intellislot port. Note to reserve the removed screws and take care of the cover for future use. 2. Insert the SIC card (along two sides of the Intellislot port) into the port position recommended in Table 8-1, and then fasten the screws.
  • Page 78 Chapter 8 Options Pin No. Pin name Description Pin 9 RXD_PC, for communication to PC, receive terminal Reserved, for factory commissioning Pin 21 TXD_PC, for communication to PC, send terminal Reserved, for factory commissioning Power GND, dry contact signal input Pin 13 GND, common GND common GND...
  • Page 79 Chapter 8 Options Figure 8-7 Appearance and wiring schematic of cable 3 (UFDRY21SL3) Installation procedures Note Some electronic components on the relay card are sensitive to static electricity. To prevent static electricity from damaging the relay card, do not touch its electronic components or circuits, also avoid their contact with live objects. Please hold the side edges of the relay card when moving or installing it.
  • Page 80: Uf-Rs485 Card

    Chapter 8 Options b) Align the relay card with the Intellislot port, insert the relay card into the port along the grooves on both sides of the port. c) Fix the relay card through the fixing holes on the relay card panel with the screws obtained in step 1. 3.
  • Page 81: Modbus Card

    Chapter 8 Options 1. Insert the UF-RS485 card into the UPS. a) Remove the Intellislot port cover on the front panel of the bypass module. Save the screws. b) Align the UF-RS485 card with the Intellislot port, insert the card into the port along the grooves on both sides of the port.
  • Page 82: Chapter 9 Communication

    Chapter 9 Communication Chapter 9 Communication The UPS supports SNMP communication, Modbus protocol communication and dry contact communication. This chapter provides information relevant to these types of communication. 9.1 SNMP Protocol Communication In order to monitor the UPS through web network, user needs to select the SIC card. It is a network management card which supports SNMP protocol.
  • Page 83: Chapter 10 Service And Maintenance

    Chapter 10 Service And Maintenance Chapter 10 Service And Maintenance The UPS system (including battery) needs regular service and maintenance in long-term operation. This chapter elaborates on the advice on the service life, regular inspection, maintenance and replacement of the UPS key components.
  • Page 84: Standard Default Procedure (When Load Transfer To Bypass Is Allowed) For Service The Bypass Module

    Chapter 10 Service And Maintenance 4. After servicing the module, check that the address of this module is different from those of other modules and that the address is in the range 1 ~ 5. Check that the ready switch is in unready state. 5.
  • Page 85: Replacement Procedures Of Air Filter

    Chapter 10 Service And Maintenance 10.3 Replacement Procedures Of Air Filter The UPS provides four air filters on the back of the front doors of the main power cabinet and switch cabinet respectively. Each air filter is fixed by a fixing bar on either side. The replacement procedures of each air filter are the same.
  • Page 86: Chapter 11 Specifications

    Chapter 11 Specifications Chapter 11 Specifications The chapter provides the UPS specifications. 11.1 Conformity And Standards The UPS has been designed to conform to the European and international standards listed in Table 11-1. Table 11-1 European and international standards Item Specifications General and safety requirements for UPS EN62040-1/IEC62040-1/AS62040-1...
  • Page 87: Electrical Characteristics (Input Rectifier)

    Chapter 11 Specifications 11.4 Electrical Characteristics (Input Rectifier) Table 11-4 Rectifier AC input (mains) Rated power (kVA) Item Unit 30 ~ 300 380/400/415 (3-phase and sharing neutral with the bypass Rated AC input voltage input) Input voltage tolerance 305 ~ 477; 304 ~ 228 (output derated below 80%) Frequency 50/60 (tolerance: 40Hz ~ 70Hz) kW/kVA, full load (half...
  • Page 88: Electrical Characteristics (Inverter Output)

    Chapter 11 Specifications Rated power (kVA) Item Unit 2.4V/cell (selectable from 2.3V/cell to 2.4V/cell) Battery charge V/cell Constant current and constant voltage charge mode Programmable automatic trigger or inhibit of boost mode Battery 13.5 22.5 31.5 40.5 charging power maximum current (adjustable) 1.
  • Page 89: Electrical Characteristics (Bypass Mains Input)

    Chapter 11 Specifications 11.7 Electrical Characteristics (Bypass Mains Input) Table 11-7 Bypass mains input Rated power (kVA) Item Unit 30 ~ 300 380/400/415 (three-phase four-wire, sharing neutral with the rectifier Rated AC voltage input and providing neutral reference to the output) Rated current 500A, long term Overload...
  • Page 90: Appendix 1 Glossary

    Appendix 1 Glossary Appendix 1 Glossary Alternating current Battery circuit breaker Cross sectional area Center tap Direct current Dual in-line package Digital signal processor Electromagnetic compatibility Electromagnetic interference End-of-discharge Emergency power off Load bus synchronizer Liquid crystal display MCCB Moulded-case circuit breaker Protective earth Pulse width modulation RCCB...
  • Page 91: Appendix 2 Hazardous Substances And Content

    Appendix 2 Hazardous Substances And Content Appendix 2 Hazardous Substances And Content Hazardous substances Plumbum Hydrargyru Cadmium Chrome PBDE Parts (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) Hex copper stud × ○ ○ ○ ○ ○ PCBA × ○ ○ ○...
  • Page 92 | Emerson Network Power Limited, George Curl Way, Southampton, SO18 2RY, VAT Number: GB188146827 © 2017 Vertiv Co. All rights reserved. Vertiv, the Vertiv logo and Vertiv Liebert DSE are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
