User's Manual
RICOH PJ WUL6380/PJ LU8000 Series
1.
2.
3.
4.
Read this manual carefully before you use this machine and keep
it handy for future reference. For safe and correct use, be sure to
read the Precautions in this manual before using the machine.
Introduction
Installation
User Controls
Appendices
Advertisement
Table of Contents
Related Manuals for Ricoh PJ LU8000 Series
Summary of Contents for Ricoh PJ LU8000 Series
- Page 1 RICOH PJ WUL6380/PJ LU8000 Series User’s Manual Introduction Installation User Controls Appendices Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the Precautions in this manual before using the machine.
-
Page 2: Safety Information
Safety Information This chapter describes safety information for this machine. Information Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference. Important Contents of this manual are subject to change without prior notice. -
Page 3: Safety During Operation
Safety Information When using this machine, the following safety precautions should always be followed. Safety During Operation In this manual, the following important symbols are used: WARNING Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property. - Page 4 CAUTION Keep the machine away from humidity and dust. Otherwise a fire or an electric shock might occur. CAUTION Do not place any objects on the machine. Doing so may cause the machine to topple over, possibly resulting in injury. CAUTION ...
- Page 5 CAUTION Do not place the product in a location where air flow is poor. Doing so may cause fire due to internal components becoming overheated. CAUTION Do not place or store the product in a location where direct sunlight or heat generation might occur.
-
Page 6: Handling Power Cords And Power Cord Plugs
Handling power cords and power cord plugs This section explains safety precautions about handling power cords and power cord plugs. WARNING Do not use any power sources other than those that match the specifications shown. Doing so could result in fire or electric shock. WARNING ... - Page 7 WARNING Be sure to disconnect the plug from the wall outlet at least once a year. There are burn marks on the plug. The prongs on the plug are deformed. If any of the above conditions exist, do not use the plug and consult your dealer or service representative.
- Page 8 CAUTION Push the power plug all the way into the power outlet. Do not use a power outlet with a loose connection. Doing so may result in heat buildup. Plug the power cord in the correct direction into the base. If they are not plugged in correctly, it could result in smoke, fire, or electric shock.
-
Page 9: Handling The Main Machine
Handling the main machine This section explains safety precautions about handling the main machine. WARNING If the machine emits smoke or odours, or if it behaves unusually, you must turn off its power immediately. After turning off the power, be sure to disconnect the power cord plug from the wall outlet. - Page 10 WARNING Contact your sales or service representative to clean or replace parts for a projector that is installed on a wall or ceiling. Do not attempt to clean or replace parts for a projector that is installed in a high location on a wall or ceiling.
- Page 11 Handling the machine’s interior This section explains safety precautions about handling the machine’s interior. WARNING Do not remove any covers or screws that are not mentioned in this manual. There are high voltage components inside the product that may cause electric shock.
-
Page 12: About The Batteries
About the batteries Explains things that you should follow in regard to the batteries. WARNING For safe operation, follow the warnings below regarding the batteries used in the remote control. If you use the batteries incorrectly, it may result in fire or injury due to batteries leaking or exploding. - Page 13 About the Laser light source Explains things that you should follow in regard to the laser light source. WARNING Do not look into the lens or vent when the product is on. The bright light may damage your eyes. Be especially careful in an environment with children. CAUTION ...
-
Page 14: Other Information
Other Information Copyrights to Images When projecting images using the projector, be careful not to infringe the copyright of protected materials. The following are examples that may infringe the copyright of protected materials. • Broadcasting images or movies for commercial purposes •... -
Page 15: Safety Labels Of This Machine
Safety Labels of This Machine Positions of WARNING and CAUTION labels This machine has labels for WARNING and CAUTION at the positions shown below. For safety, please follow the instructions and handle the machine as indicated. Main unit Do not look into the lens when the product is on. The bright light may damage your eyes. -
Page 16: Power Switch Symbols
Power Switch Symbols The meanings of the symbols for the switches on this machine are as follows: : STANDBY... -
Page 17: Laws And Regulations
Laws and Regulations User Information on Electrical and Electronic Equipment If you wish to discard this product, please contact your local authorities, the shop where you bought this product, your local dealer or sales/service representatives. -
Page 18: Regulation & Safety Notices
Regulation & Safety Notices This appendix lists the general notices of your Projector. All Users If you wish to discard this product, please contact your local authorities, the shop where you bought this product, your local dealer or sales/service representatives. Laser Notice IEC 60825-1:2014: CLASS 1 LASER PRODUCT - RISK GROUP 2. -
Page 19: Table Of Contents
Table of Contents Safety Information ........2 User Controls Regulation & Safety Notices ....18 Operation ..........43 Introduction OSD Tree ..........44 Product Features ........20 Picture Menu ........51 Package Overview ....... 21 Output Menu ......... 54 Product Overview ......... 22 Setup Menu .......... -
Page 20: Introduction
Introduction Product Features • One panel 0.67”-WUXGA projection system, w/ TI DDP4422 solution • 7,200 ANSI lumens platform • Power Zoom/Focus and full lens shift • Support LAN network control • HDBaseT support network control and video streaming • Support PIP/PBP function •... -
Page 21: Package Overview
Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact our customer service. Projector with lens cover Power Cord VGA Cable Info Mode Auto Input Lens Ring Lens Ring (For Type A3A) (For Type A2, A4, or A5) -
Page 22: Product Overview
Product Overview The product specified in this document is a high brightness, high-resolution video/ graphics 1-chip laser based projector. The projector is available in WUXGA resolution. The projector utilizes Digital Light Processing (DLP ) technology from ® Texas Instruments. It is primarily designed for fixed installation markets. Projector Components Front View Ind. -
Page 23: Rear View
Rear View MENU EXIT INPUT LENS FOCUS ENTER ZOOM Ind. Part Name Description LED Status Indicators Displays the status of the projector. Receives signals from the IR remote. Keep the signal path Top IR Sensor unobstructed for uninterrupted communication with the projector. -
Page 24: Right View
Left and Bottom Views Right View Ind. Part Name Description Keep these vents unobstructed to prevent the projector from Inlet Vent overheating. Keep these vents unobstructed to prevent the projector from Outlet Vent overheating. Things to note when installing projectors •... -
Page 25: Built-In Keypad
Built-in Keypad MENU EXIT INPUT LENS FOCUS ENTER ZOOM Ind. Part Name Description Power Turn the projector on or off. Menu Display menus. Exit Return to previous level or exit menus if at top level. Input Select an input for the main or PIP/PBP image. Enter Confirm a selection. -
Page 26: Input/Output (I/O) Panel
Input/Output (I/O) Panel Ind. Connector Name Ind. Connector Name DVI-D Computer In Remote In Monitor Out PC Control HDMI Out 10 LAN (Ethernet) HDMI In 11 HDBaseT Service 12 3D Sync... -
Page 27: Led Status Indicators
LED Status Indicators The LED status indicators are located on the rear of the projector. Each LED is defined below. Light LED Status LED AV Mute LED Message Green Orange Green Orange Green Orange Standby State Flashing Power on Flashing (Warm up) Power on &... -
Page 28: Remote Control
Remote Control Mode Info Auto Input Enter Menu Exit Gamma Bright Cont. Lens H Focus Lens V Keystone H Zoom Keystone V AV Mute Hot Key Pattern... - Page 29 Ind. Part Name Description Power on Turn projector ON. Number Keys Enter a number, such as a value for an IP address, etc. Info Display source image information. Auto Automatically optimize image. • Select a highlighted menu item. Enter • Change or accept a value.
-
Page 30: Projector Addressing
Projector Addressing The IR Remote shall allow individual addressing of projectors. Each projector shall be able to have an address set from 1 to 99. 1. ID Code 0 shall be used to address all projectors (default state). 2. ID Codes 1 to 99 shall be used to address projectors set to address 1 to 99 respectively. -
Page 31: Remote Control Battery Installation
Remote Control Battery Installation Remove the battery Install new batteries Replace the cover. Do compartment cover (AAA/R03). Ensure not mix different types as shown in the that you have the of batteries or new and illustration. batteries’ polarity (+/–) old batteries. aligned correctly. -
Page 32: Remote Control Operating Range
Remote Control Operating Range Point the remote control toward the projector (Remote Receiver) when pressing any button. Maximum operating range for the remote control is about 33’ (10m) and ±30° (horizontally) in front of the projector. 33’ (10m) ±30° (front/back) 33’... -
Page 33: Installation
Installation Adjust the Projector Position When you select a position for the projector, consider the size and shape of your screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Follow these general guidelines: •... -
Page 34: Removing And Installing The Lens
Removing and Installing the Lens When handling the projector after lens installation, make sure the front lens cap is placed on the lens to protect the lens surface from potential damage. When carrying or moving the projector, do not handle by the lens. This may damage the lens, the chassis or other mechanical parts within the projector Installation Steps: Center the lens: Ensure that the lens is at or near its center position. -
Page 35: Adjusting The Projected Image
Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator rubber feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projector or counter clockwise to lower it. -
Page 36: Connect To Computer
Connect to Computer Desktop Laptop External Display Ind. Connector Name Ind. Connector Name Ind. Connector Name DVI Cable HDMI Cable VGA out Cable VGA in Cable Mini USB Cable Power Cord RS232 Cable HDMI Cable NOTE: The diagram shows the cables/connectors that may be used to connect to various devices. ™... -
Page 37: Connect To Video Equipment
Connect to Video Equipment Component video output DVD player Video cassette equipment recorder Ind. Connector Name Ind. Connector Name 15-pin to 3 RCA Component/ VGA to RBG SCART HDTV Adapter VGA in Cable HDMI Cable 3 RCA Component Cable NOTE: The diagram shows the cables/connectors that may be used to connect to various devices. -
Page 38: Turn The Projector On
Turn the Projector On Ensure that the power cord and signal cable are securely connected. The Power button on the built in keypad is illuminated. Turn on the projector by pressing “ ” on the remote control or press “ ” on the built-in keypad. -
Page 39: Turn The Projector Off
Turn the Projector Off Press “ ” on the built-in keypad or press “ ” on the remote control to turn off the projector. A warning message will appear on the displayed image. Press “ ” on the built-in keypad or press “ ”... -
Page 40: Projection Lens
Projection Lens Replacement Lens Type A3A is the standard lens for this projector. Replacement Replacement Replacement Replacement Replacement Projection Lens Lens Type A1 Lens Type A2 Lens Type A3A Lens Type A4 Lens Type A5 Focal Length (f) 11.11-14.06 14.03-17.96 18.07-22.59 22.56-42.87 42.60-80.90... - Page 41 Replacement Replacement Replacement Replacement Replacement Projection Lens Lens Type A1 Lens Type A2 Lens Type A3A Lens Type A4 Lens Type A5 A2/A4/A5 lens shift range: Lens shift range Motorized Lens A1/A3A lens shift range: Shift (Lens shift range based on 1/2 screen width and height) Darker...
-
Page 42: Adjusting The Projecting Image's Position
Adjusting the Projecting Image’s Position To determine where to position the projector, consider the size and shape of your screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Platform WUXGA (16:10) 0.67"... -
Page 43: User Controls
User Controls Operation The projector has multilingual On-Screen Display (OSD) menus that allow you to make image adjustments and change a variety of settings. • Most of the projector controls are accessed from within the projector menu system. There are several groups of related functions, with each group selectable from the Main menu as shown below. -
Page 44: Osd Tree
OSD Tree Level 1 Level 2 Level 3 Level 4 Level 5 Default Presentation Video Bright REC709 DICOM SIM Display Mode By source set 2D High Speed Blending User Save to User Brightness 0 ~ 100 Contrast 0 ~ 100 Sharpness 0 ~ 4 Color... - Page 45 Level 1 Level 2 Level 3 Level 4 Level 5 Default Magenta H. 0 – 254 Magenta S. 0 – 254 Magenta G. 0 – 254 Yellow H. 0 – 254 Yellow S. 0 – 254 CE1 Parameters Yellow G. 0 –...
- Page 46 Level 1 Level 2 Level 3 Level 4 Level 5 Default REC709 Color Space REC601 Auto RGB Video Auto Red Gain 0 ~ 100 Green Gain 0 ~ 100 Blue Gain 0 ~ 100 Red Offset 0 ~ 100 Color Settings Green Offset 0 ~ 100 Blue Offset...
- Page 47 Level 1 Level 2 Level 3 Level 4 Level 5 Default Top Left Horz Adjust 0 ~ 120 (pixel) Top Left Vert Adjust 0 ~ 80 Top Right Horz 0 ~ 120 Adjust Top Right Vert Adjust 0 ~ 80 Bottom Left Horz 0 ~ 120 Image Warping...
- Page 48 Level 1 Level 2 Level 3 Level 4 Level 5 Default Ceiling Mount Auto Auto Rear Projection Focus in - motor stop Focus in - motor go step Focus in - motor run Focus Focus out - motor stop Focus out - motor go step Focus out - motor run Zoom in - motor stop Zoom in - motor go step...
- Page 49 Level 1 Level 2 Level 3 Level 4 Level 5 Default DHCP by set IP Address by set Subnet Mask by set Default Gateway by set MAC Address by set Apply Projector Name by set Restart Network Network Network Factory SETUP Communications Reset...
- Page 50 Level 1 Level 2 Level 3 Level 4 Level 5 Default 0.5W mode Communication Standby Power Mode Communication mode mode Direct Power On 5 Mins 10 Mins Power Settings Auto Power Off 15 Mins 20 Mins 20 Mins 25 Mins 30 Mins 2 Hours Sleep Timer...
-
Page 51: Picture Menu
Picture Menu PICTURE PICTURE Display Mode Presentation Brightness Contrast OUTPUT Sharpness Color Tint SETUP Phase Frequency Horz Position OPTION Vert Position PICTURE (1/2) PICTURE PICTURE 3D Display HSG Adjustment Advanced OUTPUT SETUP OPTION PICTURE (2/2) Display Mode Optimize the projector for displaying images under certain conditions, such as Presentation, Video, Bright, REC709, DICOM SIM, 2D High Speed, 3D, Blending, and user-definable preset. - Page 52 Sharpness Select the edge clarity of the image. Color Adjust a video image from black and white to fully saturated color. The color setting applies to video sources only. Tint Adjust the red-green color balance in the image of video images. The tint setting applies to video sources only.
- Page 53 HSG Adjustment Configure the color management settings. • Auto Test Pattern: Set to “On” to enable displaying a test pattern for the target color or set to “Off” to disable the auto test pattern. • Red H. / Green H. / Blue H. / Cyan H. / Magenta H. / Yellow H.: Adjust the hue of the red, green, blue, cyan, magenta, or yellow channel of the image.
-
Page 54: Output Menu
Output Menu OUTPUT PICTURE Aspect Ratio Auto Overscan H Digital Zoom OUTPUT V Digital Zoom H Digital Shift V Digital Shift SETUP Image Warping PIP/PBP OPTION Aspect Ratio Display an image with the detected size, or resize the image by maximizing either the height, width or both, or resize to the maximum size possible while keeping the original aspect ratio. - Page 55 H Digital Shift Move the display area horizontally if its size has been changed by the Digital Zoom setting. V Digital Shift Move the display area vertically if its size has been changed by the Digital Zoom setting. Image Warping •...
- Page 56 • 4-Corner: Allow the image to be squeezed to fit an area defined by moving each of the four corners’ x and y position. PIP/PBP • PIP/PBP Enable: Toggle between displaying two sources at once (Main and PIP/PBP images) or one source only. •...
- Page 57 PIP/PBP Size PIP/PBP Layout Small Medium Large PIP-Bottom Right PIP-Bottom Left PIP-Top Left PIP-Top Right...
-
Page 58: Setup Menu
Setup Menu SETUP PICTURE Language English Ceiling Mount Auto Rear Projection OUTPUT Lens Function Menu Preferences Keypad LED Settings SETUP Communications OPTION Language This item allows you to select an available language for the OSD display. Ceiling Mount Turn the image upside down for ceiling-mounted projection. Rear Projection Reverse the image so you can project from behind a translucent screen. - Page 59 • PIN Protect: The PIN (personal identification number) feature allows you to password protect your projector. Once you enable the PIN feature, you must enter the PIN before you can project an image. (PIN Default : 12345) • Change PIN: This item allows you to change the PIN. Communications •...
-
Page 60: Option Menu
Option Menu OPTION PICTURE Auto Source High Altitude Test Pattern OUTPUT Background Color Logo Hot-Key settings Blank Screen Power Settings SETUP Light Source Settings Light Sensor Information OPTION Factory Reset OPTION (1/2) OPTION PICTURE Service OUTPUT SETUP OPTION OPTION (2/2) Auto Source •... -
Page 61: Background Color
Background Color Use this feature to display a “Logo”, “Blue”, “Black” or “White” screen when no signal is available. Hot-Key settings Assign a different function to the hot-key on the remote control by highlighting the function in the list and pressing ENTER. Choose a function that does not already have a dedicated button, and assign the hot-key to that function, allowing you to quickly and easily use the chosen function. - Page 62 • Calibrated: Yes: Light Sensor has been calibrated. No: Light Sensor has not been calibrated. Information Display the projector information for source, resolution, and software version on the screen. Factory Reset Restore all settings to their default value. It will not reset network. Service Service only.
-
Page 63: Appendices
Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image Problems No image appears on-screen ` Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”... - Page 64 2. Click Display. 3. Click General Settings on the left side, and select the corresponding display. 4. Configure the following settings: Resolution: select a screen resolution (ex: 1920 x 1080) that you want for the display. Refresh Rate: select a refresh rate (ex: 60p Hz) that you want for the display.
- Page 65 ` If you are using a Notebook: First, follow the steps above to adjust resolution of the computer. Press the toggle output settings. example: [Fn]+[F4] Notebook Brand Function Keys Acer [Fn]+[F5] Asus [Fn]+[F8] Dell [Fn]+[F8] Gateway [Fn]+[F4] IBM/Lenovo [Fn]+[F7] HP/Compaq [Fn]+[F4] [Fn]+[F3] Toshiba...
- Page 66 The image is stretched when displaying 16:9 DVD title ` When you play anamorphic DVD or 16:9 DVD, the projector will show the best image when the projector display mode is set to Auto in the OSD. ` If you play 4:3 format DVD titles, please change the format to 4:3 in the projector OSD.
-
Page 67: Projector Problems
Projector Problems The projector stops responding to all controls ` If possible, turn off the projector, then unplug the power cord and wait at least 60 seconds before reconnecting power. If the remote control does not work ` Check if the operating angle of the remote control is within ±30° both horizontally and vertically on one of the IR receivers on the projector. - Page 68 Step 4: On the General tab, under This connection use the following items, click Internet Protocol(TCP/IP), and then click “Properties”. Step 5: Click Use the following IP address, and type in as below: 1) IP address: 192.168.0.101 2) Subnet mask: 255.255.255.0 3) Default gateway: 192.168.0.254...
- Page 69 Step 6: To open Internet Options, click IE web browser, click Internet Options, click the Connections tab and click “LAN Setting…”. Step 7: All items in the Local Area Network (LAN) Setting window must unchecked. Then click “OK” button twice. Step 8: Connect a cat5 Ethernet cross-over cable between the projector and the computer.
-
Page 70: On Screen Messages
On Screen Messages y Power off confirm... -
Page 71: Compatibility Modes
Compatibility Modes Inputs Signal Frequency H. Frame rate Resolution HDMI HDBaseT Type (kHz) (Hz) 640x480 640x480 37.861 640x480 37.500 640x480 43.269 640x480 35.000 66.6 720x400 31.469 800x600 37.9 800x600 48.1 800x600 46.9 800x600 53.7 800x600 77.285 832x624 848x480 24.621 848x480 29.829 848x480 37.683... - Page 72 Signal Frequency H. Frame rate Resolution HDMI HDBaseT Type (kHz) (Hz) 1280x800 71.554 1280x960 49.404 1280x960 59.699 1280x960 75.231 1280x960 85.792 1280x1024 52.678 1280x1024 1280x1024 1280x1024 91.1 1360x768 39.564 1360x768 47.719 1360x768 60.287 1360x768 68.667 1366x768 1400x1050 54.112 1400x1050 65.316 1400x1050 82.278 1440x900...
-
Page 73: 3D Timing Table
Signal Frequency H. Frame rate Resolution HDMI HDBaseT Type (kHz) (Hz) 1080p 33.716 1080p 33.75 HDTV 1080p 56.25 1080p 67.433 1080p 67.5 Frame Packing 1080p Frame Packing 720p Frame Packing 720p Side by Side 1080i Mandatory Side by Side 1080i Top and Bottom 720p Top and Bottom... -
Page 74: Rs232 Pin Assignments
RS232 Pin Assignments Pin No. PC Side Projector Side (RS232 Terminal) Setup Information RS-232 protocol Baud Rate 9600 bps (default) Data Length 8 bit Parity Check None Stop Bit 1 bit Flow Control None RS232 shell is grounded. RS232 interface need use swap pin for RS232 communication. ... -
Page 75: Specifications
Specifications Technology “TI” 0.67” WUXGA DMD, Type A, DC3 ASIC DDP4422 + PW392 Native Resolution WUXGA (1920x1200) Support Resolution Up to WUXGA@60Hz (Reduced Blanking) & UXGA@60Hz Computer IBM PC Compatible, support HDTV (1080i/p, 720p, 576i/p, 480i/p) compatibility Video compatibility HDTV 720p (50/60Hz), 1080i/p (50/60Hz), 1080p (24/25/30/50/60Hz), SDTV 480i/p, 576i/p Horizontal scan rate 15.734KHz to 97.55KHz... - Page 76 Standard package Remote control x 1 contents AAA batteries x 2 AC power cord x 1 VGA cable x 1 Lens rings x 2 (Small size: Compatible with A2, A4, or A5 lens; Large size: Compatible with A3A lens) User's Manual CD x 1 Read this first (Paper) x 1 Warranty Card x 1 Design and specifications are subject to change without prior notice.
-
Page 77: Cabinet Dimension
Cabinet dimension Unit: mm Screw type: M6 x 4 Maximum screw length: 10mm... -
Page 78: Trademarks
Trademarks y DLP is trademark or registered trademark of Texas Instruments. y IBM is a trademark or registered trademark of Interna tional Business Machines Corporation. y Macintosh, Mac OS X, iMac, and PowerBook are trade marks of Apple Inc., registered in the U.S. and other countries. y Microsoft, Windows, Windows Vista, Internet Explorer and PowerPoint are either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. - Page 79 Y0BD-6221...
