Installation Guide
For models:
AK52BNK4L
AK52EB4L
4007498
APPROVED FOR USE
IN DAMP LOCATIONS
net weight of fan: 16.31 lb (7.4 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 5
Warranty. pg. 8
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AK52BNK4L and is the answer not in the manual?

Questions and answers

Related Manuals for Litex AK52BNK4L

Summary of Contents for Litex AK52BNK4L

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For models: AK52BNK4L AK52EB4L Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (76cm) (2.13m) clearance of 7ft. (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. set screw If you wish to extend the hanging length of set screw hole stop pin your fan, you must remove the hanging ball from the downrod provided to use with an extended downrod (sold separately). [If you wish to use the downrod provided, please proceed to instructions following the dotted line below.] hanging ball...

  • Page 6: Wiring

    5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through hanging bracket tab opening in hanging bracket and let hanging ball rest on the hanging bracket.

  • Page 7: Canopy Assembly

    7. Canopy Assembly. hanging bracket Temporarily raise canopy to hanging bracket to screw determine which 2 screws in hanging bracket align with slotted holes in canopy, and then lower canopy and partially loosen these 2 screws. Remove the other 2 screws and lock washers and set aside. Now, lift canopy to hanging bracket again, aligning canopy slotted holes in the canopy with loosened screws in...

  • Page 8: Light Kit Assembly

    9. Light Kit Assembly. Install 2 medium base 6.5 watt LED bulbs, (included). IMPORTANT: When replacing bulbs, please allow bulbs and glass shade to cool down before touching. Align grooves on glass shade with nodules on inside edge of motor housing and push up gently on glass shade.

  • Page 9: Troubleshooting

    Service at 1-800-527-1292 to arrange for return of fan. 2. Verify that reverse switch is set completely in Return fan, shipping prepaid, to Litex Industries, Ltd. We will either direction. repair or ship you a replacement fan, and we will pay the 3.
