Full Load Current setting:
This setting is applicable only for the Extended
versions of DMS and refers to the ETR function. It
may not be used for current limitation.
Calibrate the DMS for the connected motor
nameplate Full Load Current (FLC).
FLC setting table :
DIP Switch bits
2 (B2)
3 (B3)
4 (B4)
5 (B5)
6 (B6)
Note:0.1 Amps is added internally to the value
read from DIP switches.
Completing the installation:
To complete installation, fit the DMS Electronics
module to the DMS Installation box and secure with
the screws provided. Recommended tightening torque
for the screws is between 2.5 and 3 Nm.
MG.05.A2.02 - VLT is a registered Danfoss trademark
Value (Amps)
3.2
1.6
0.8
0.4
0.2
6.3 Amps, when B2-B6
are all On
DMS Manual
Use the five (5) DIP switches B2-B6 to add up to motor
nameplate FLC minus 0.1 Amps. (0.1 Amps is added
internally to the FLC amps. read from the DIP switches)
Please note that switch B1 is not used.
Example-1 for setting
FLC=4.3 Amps
On
Off
On
Off
On
0.1+3.2+0+0.8+0+0.2
= 4.3
See remark
Example-2 for setting
FLC=2.9 Amps
Off
On
On
On
Off
0.1+0+1.6+0.8+0.4+0
=2.9
See remark
11
