3 Using the RIDA

3.1 Switching the device on

To switch the device on, press the ENTER key (3) for around 1 second. The following start
menu is displayed and the device performs an internal test (Figure 3). After this short internal
test the Scan Mode is displayed (Figure 6).
The current status of the power supply is shown beside the battery symbol. "B" stands for
battery operation and "N" means that the device is connected to a mains power supply (the
batteries are being recharged). The batteries are recharged only when the device is switched
on.
Self Test
R-Biopharm
®
RIDA QUICK SCAN
V 1.0.0.8
Figure 5 a
Besides Scan Mode you can also choose between the following modes by pressing the ◄►
keys:
- Setup Mode:
- Memory Mode:
- Calibration Mode:
These modes are described in more detail below. The actually measured temperature is
shown on the display. The tests should be performed at room temperature.

3.2 Evaluate test strip (SCAN MODE)

The test strips are measured in Scan Mode. When you have switched on the reader you must
define or confirm the displayed parameters before you perform the first measurement.
To do this, select the individual entry fields with the cursor keys ▲▼ and then change the
parameters using the ◄► keys.
16 Scan mode
◄
° C
UserID
Method
Cut off0.50
18.01.09 B
Start scan
▼▲
Figure 6
®
QUICK SCAN reader
2009.01.18.
Basic device function settings
Display stored test measurements
Check the Calibration of the reader
User01
DON CutOff
09:00 pm
16
◄
° C
UserID
Method
Cut off0.50
18.01.09
Start scan
▼▲
Figure 5 b (Example: Cut Off)
►
User: Select user
Method: Select test
Cut Off: Define required detection limit.
Scan mode
User01
DON CutOff
B 09:00 pm
►
