3.4 Displaying stored test results (MEMORY MODE)

In MEMORY MODE you can view and print stored measurements.
Delete data records via the "Setup Mode" menu.
The device can store up to 100 measurements. For each measurement 11 data record entries
are stored. Use the ▲▼ keys to scroll within the individual measurement and the ◄► key to
scroll between the different measurements.
"Record No" refers to the data record currently displayed.
The following data records are stored:
◄ Memory Mode
Record No. 07
UserID User01
Method DON CutOff
Date 18.01.09
▲▼ Print Delete
◄ Memory Mode
09:03 pm
Time
Cut off 0.50
Result PASS
Concentr. <0.5ppm
▲▼ Print Delete
Memory Mode
0 1168
Batch No.
Run No. 1102
Serial. No. 0013
CalibStatus OK
▲▼ Print Delete
Figure 15
The meaning of these parameters are as follows:
Record No. The record number is automatically counting from 1 to 100. The internal
memory must be then erased with the delete function or via the RIDA
QUICK Manage Software connected with USB to a PC.
User ID Up to 20 different users may be addressed. In the basic setting the numbers
are 01 to 20, but the names may be changed via the PC software. The device
starts automatically with the last used User ID.
Method The chosen method will be shown.
07/10 ►
0
07/10 ►
0
◄►
►
07/10
0
◄►
®
