Addi-Data APCI-3000 Technical Description page 45

APCI-3xxx
Functionality
b_ADDIDATA_EnableDisableAnalogInputSoftwareTrigger
Available parameters:
- Action:
b_ADDIDATA_GetAnalogInputSoftwareTriggerStatus
b_ADDIDATA_GetNumberOfAnalogInputs
b_ADDIDATA_GetNumberOfAnalogInputModules
Analog
b_ADDIDATA_GetNumberOfAnalogInputsForTheModule
inputs
b_ADDIDATA_GetAnalogInputModuleNumber
(APCI-3000,
b_ADDIDATA_GetAnalogInputModuleGeneralInformation
APCI-3100)
b_ADDIDATA_GetAnalogInputModuleSingleAcquisitionInformation
b_ADDIDATA_GetAnalogInputModuleSCANInformation
- Available gains:
- Hardware /software trigger available
- No hardware gate
- Single SCAN cycle mode available
- X SCAN cycle mode available
- Continuous SCAN cyclus mode available
- Delay available
- Available delay timing:
- Resolution conversion time:
b_ADDIDATA_InitAnalogInput
Availabe parameters:
- Gain:
- Polarity:
- Offset range: Not used
- Coupling
b_ADDIDATA_ReleaseAnalogInput
SCAN
One shot
Single cycle
x cycles
Return:
- Resolution:
- Unipolar/bipolar configurable
- Available conversion timing:
- Conversion resolution:
- Min. conversion time:
Return:
- Interrupt available
- Available gains:
- No hardware /software trigger
- No hardware gate
Return:
1, 2, 5, 10
Unipolar/bipolar
DC
Function name
12-bit
µs, ms
16-bit
10 µs
1, 2, 5, 10
µs, ms
16-bit
Standardsoftware
1, 2, 5, 10
45
